New Era University
College of Computer Studies
Information Technology Department
Abalos, Zandra Lee P.
Alip, Alaysa R.
Along, Kristine G.
Arcalas, Lauren Kate S.
Bernal, Mary Joyce B.
Gaston, Eduardo Luigie S.
Peralta, Ian Jefferson F.
(Wednesday, 10:00am – 1:00pm)
March 27, 2019
Network Topology Layout/Explanation
Message Status Screenshots
Web Design (Screenshots of web)
B10 192.168.0.13 255.255.255.0 0.0.0.
C1 192.168.0.1 255.255.255.0 0.0.0.
C2 192.168.0.2 255.255.255.0 0.0.0.
C3 192.168.0.3 255.255.255.0 0.0.0.
C4 192.168.0.4 255.255.255.0 0.0.0.
C5 192.168.0.5 255.255.255.0 0.0.0.
C6 192.168.0.6 255.255.255.0 0.0.0.
C7 192.168.0.7 255.255.255.0 0.0.0.
C8 192.168.0.8 255.255.255.0 0.0.0.
C9 192.168.0.9 255.255.255.0 0.0.0.
C10 192.168.0.13 255.255.255.0 0.0.0.
Conclusion
In making the connection of the PCs, we use star topology to
connect the PC’s and every node connects to a central network device, like
switch, The central network device acts as a server and the peripheral
devices act as clients and this case we connect it to Swtich and then
Server To make the web works the IP address must be fit to each other in
that way the network would be fully strong connected into the server and to
the switch.
