CMSC 132:

Object-Oriented Programming II

Graphical User Interface

(GUI)

Department of Computer Science

University of Maryland, College Park

Graphical User Interface (GUI)

User interface

Interface between user and computer Both input and output Affects usability of computer

Interface improving with better hardware

Switches & light bulbs Punch cards & teletype (typewriter) Keyboard & black/white monitor (text) Mouse & color monitor (graphics)

MVC Model of GUI Design

Model

Should perform actual work Should be independent of the GUI But can provide access methods

Controller

Lets user control what work the program is doing Design of controller depends on model

View

Lets user see what the program is doing Should not display what controller thinks is happening (base display on model, not controller)

Programming Models

Normal (control flow-based) Programming

Approach Start at main() Continue until end of program or exit()

Event-driven Programming

Event - Action or condition occurring outside normal flow of control of program (e.g., mouse clicks, keyboard input, etc.) Unable to predict time & occurrence of event Approach Start with main() Define system elements and register event listeners Await events (& perform associated computation)

7

GUI

Event Handlers

User events invoke event handlers

GUIs are Event-Driven Software

E (^3) E 2 E 1 E 4

E 5

User Events

changeFontSizeActionPerformed (java.awt.event.ActionEvent evt)

newDocActionPerformed (java.awt.event.ActionEvent evt)

fileSaveActionPerformed (java.awt.event.ActionEvent evt)

GUIs in Java

Java Application

Swing

Java Runtime Environment

AWT Java 2D

Desktop Java Graphics APIs: From “Filthy Rich Clients” by Chet Haase and Romain Guy, Chap1, Page 12 ISBN-978-0-13-241393- Book Web Site: http://www.filthyrichclients.org/

Steps for Creating a GUI in Java

1. Define a container to hold components

Examples: JFrame, JApplet…

2. Add GUI components to the container

Examples: JButton, JTextField, JScrollBar… Use layout manager to determine positions

3. Add actions to GUI

Add event listeners to GUI components

4. Schedule the GUI processing in the EDT

(Event-Dispatching Thread)

Step 1 (Define Container)

Container Definition

Abstractions occupying space in GUI

Properties

Usually contain one or more widgets widget - actual item user can see Can be nested in other containers

Container Examples

JFrame, JDialog, JPanel, JScrollPane

Step 3 (Set Event Listeners)

Implementation Implement event listeners for each event Usually one event listener class per widget Inner class usually utilized to implement listener Register (add) listener object with widget object

At run time Java generates event object when events occur Java then passes event object to event listener

Example of Java listeners & Actions Causing Event ActionListener  clicking button in GUI CaretListener  selecting portion of text in GUI FocusListener  component gains / loses focus KeyListener  pressing key MouseListener  mouse clicked WindowListener closing a window

Step 4 (Schedule GUI Processing in EDT)

What is a thread? Event Dispatching Thread (EDT) EDT is a background thread to process events These events are mainly updates that Cause components to redraw themselves Represent input events Swing uses a single-threaded painting model Event Dispatching thread is the only valid thread for updating GUI components Avoid updating GUI components from other threads A source of common bugs

Additional Resources

Javadoc from the JDK

Swing tutorial -

http://java.sun.com/docs/books/tutorial/uiswing/components/

Filthy Rich Clients

http://filthyrichclients.org/
