These are the lab notes of Botany. Key important points are: Osmosis, Solvent Molecules, Higher Solute Concentration, Solute Concentrations, Physical Process, Semi Permeable Membrane, Different Concentrations, Documented Observation, Nitric Oxide, Tonicity
Typology: Study notes
1 / 5
This page cannot be seen from the preview
Don't miss anything!




permeable membrane into a region of higher solute concentration, aiming to equalize the solute concentrations on the two sides. The term osmosis may also be used to describe a physical process in which any solvent moves, without input of energy, across a semi-permeable membrane (permeable to the solvent, but not the solute) separating two solutions of different concentrations. Although osmosis does not require input of energy, it does use kinetic energy and can be made to do work. The first documented observation of osmosis was made by Jean-Antoine Nollet (19th November 1700 – 25th April 1770) in 1748, who was a French clergyman and physicist. Osmosis is essential in biological systems, as biological membranes are semipermeable. In general, these membranes are impermeable to large and polar molecules, such as ions, proteins, and polysaccharides, while being permeable to non- polar and/or hydrophobic molecules like lipids as well as to small molecules like oxygen, carbon dioxide, nitrogen, nitric oxide.
Solute is any dissolved substance in a solution, such as sugars and salts. The term Tonicity is commonly used when describing the response of cells immersed in an external solution. Like osmotic pressure, tonicity is influenced only by solutes that cannot cross the membrane, as only these exert an osmotic pressure. Solutes able to freely cross the membrane do not affect tonicity because they will always be in equal concentrations on both sides of the membrane.
placed in this solution will give up water (osmosis) and shrink.
placed in this solution will take up water (osmosis) and expand.
An Isotonic solution has just the right amount of solute for the cell. A cell placed in this solution will stay the same.
An example of the effects of each of these osmotic environments on a typical plant cell is shown in Figure 1.
that the shape of the cell becomes distorted and wrinkled, a state known as crenation.
away from the rigid cell wall, but remains joined to the cell wall at points called plasmodesmata. The cell takes on the appearance of a pincushion, and the plasmodesmata almost cease to function because they become constricted — a condition known as plasmolysis.
Figure 1 The effect on plant cells under different osmotic environments.
Put these amounts in table below and calculate amounts of stock solution and dH needed to dilute to 0.1M and 0.05M solutions.
0.2 M NaCl dH 20 dH 20 0 ml 10 ml 0.2 M 10 ml 0 ml 0.15 M 7.5 ml 2.5 ml 0.10 M 0.05 M 0.0 25 M
a. Using a cork borer cut cylinders from a single potato (the cuts are made parallel). b. A razor blade is used to cut the ends of the potato cylinders square (all cylinders are equal in length). A length of about 30 mm gives good data. c: All cylinders of potato must be equal in length, width, and appearance. d. Measure and record the length and weight of each potato cylinder. All measurements must be similar. e. Place a potato cylinder into a test tubes.
f. Each of the test tubes is labeled and filled about 2/3 full with a different one of the salt solutions.
g. Weigh the potato cylinders after 10 mins and every 10 mins up to about 1 ½ hours. Then remove the potato cylinders from the test tubes.
dH20 0.2M 0.15M 0.10M 0.05M 0.025M 1 2 3 4 5 6
Average
Things to define:
What else would govern osmosis movement in an environment?
Hand in a plan for your group experiment at the end of today’s lab. What other parameters will you be investigating, and how. Do you want to use a different plant material and why
As a lab group: Mini PowerPoint presentation on osmosis in plant cells. Have a print out of your presentation and this lab brief to hand in then.
