CS101 Introduction to Computing

Lecture 15

More on Interactive Forms

(Web Development Lecture 5)

Focus of the last lecture was on Interactive Forms

• We looked at the utility of forms on Web pages
• We found out about the various components that are used in a form
• We became able to build a simple, interactive form

In Today’s Lecture …

• We will learn ways of adding more interactivity to forms
• We will get our first taste of JavaScript – the object-based language that we will be employing throughout the rest of the Web development part of this course
• Last time we mentioned server-side scripts; today we will write (simple) client-side scripts in JavaScript

But first lets review the tags that are

used in forms

<FORM

name=“name”

method=“get” or “post”

action=“URL”

>

Elements of the form

Single-Line Text Input Field

<INPUT

type=“text”

name=“name”

size=“widthInCharacters”

maxlength=“limitInCharacters”

value=“initialDefaultValue”

>

Password Input Field

<INPUT

type=“password”

name=“name”

size=“widthInCharacters”

maxlength=“limitInCharacters”

value=“initialDefaultValue”

>

Hidden Input

<INPUT

type=“hidden”

name=“name”

value=“value”

>

Checkbox Input Element

<INPUT

type=“checkbox”

name=“name”

checked

value=“checkedValue”

>

Radio Button Input Element

<INPUT

type=“radio”

name=“name”

checked

value=“selectedValue”

>

File Upload Input Element

<INPUT

type=“file”

name=“name”

value=“nameOfSelectedFile”

enctype=“fileEncodingType”

>

Reset Button Input Element

<INPUT

type=“reset”

value=“buttonLabel”

>

Submit Button Input

<INPUT

type=“submit”

name=“name”

value=“buttonLabel”

>

8 Possible Values for the “type” Attribute

of tag

1. text
2. password
3. hidden
4. checkbox
5. radio
6. file
7. reset
8. submit

Multi-Line Text Input Area

<TEXTAREA

name=“areaName”

cols=“width”

rows=“lines”

>

initial default value

Select from a (Drop Down) List

<SELECT name=“name” size=“numberOfDisplayedChoices” multiple

text text text … …

(^) Docsity.com 16

End of the Review of Tags Used in Forms

Now let’s take a look at a form that we constructed last time, and see how we can make it better

Let’s now review what happens when I enter all the required info and press the “Send eMail” button?

22

Info contained in the form

Message to the receiver’s eMail address

User’s Computer

Web Server

Server-Side Script

Browser

This is what happens when the form is filled correctly. What if

the form is filled incorrectly?

• What if the users leaves one of the essential fields, blank?
• What if the user enters an illegal eMail address? Examples: - altaf2vu.edu.pk - [email protected] - bhola@yahoo

A Reasonable Scenario

• When the “Send eMail” button is clicked, the browser sends the data collected through the form to a script running on the Web server
• That server-side script:
  • receives that data
  • analyzes it
  • discovers the missing or incorrect data
  • sends a message back to the user’s browser stating the problem and asks the user to re-send

This process …

• That is the process of user:
  • Filling the incomplete/incorrect data
  • Sending it to the server
  • Receiving the response back from the server
  • Correcting and resending is quite time-consuming and uses the server’s resources to help the user correct his mistakes
• It can really bog down the server if a large number of users are using that Web server
