PALAWAN STATE UNIVERSITY
DEPARTMENT OF CIVIL ENGINEERING
COLLEGE OF ENGINEERING, ARCHITECTURE, AND TECHNOLOGY
ED 1/L ENGINEERING DRAWING AND PLANS INSTRUCTOR: ENGR. NOVELETTE D. ESCARCHA
PLATE #1: FREEHAND LETTERING (PENCIL)
PLATE #2: FREEHAND LETTERING (TECHNICAL PEN)
GRIDLINES
PLATES 1 & 2 WILL BE NEEDING GRIDLINES WITH THE DIMENSION OF 0.5 x 0.5 CENTIMETERS AS SHOWN. USE
SOFT PENCIL.
GUIDELINES:
PLATE 1:
1. USE A SOFT/LIGHT PENCIL (H, etc.) FOR THE GRIDLINES.
2. USE A HARD/DARKER PENCIL (4B, etc.) FOR THE LETTERS.
3. 1 GRID SPACE MUST BE USED BETWEEN THE UPPER CASE AND SMALLER CASE OF THE LETTER. (EX.
A□a)
4. 2 GRID SPACES MUST BE USED FROM ONE LETTER TO THE NEXT. (EX. a□□B)
A□a□□B□b□□C□c□□….
PLATE 2:
1. USE A SOFT/LIGHT PENCIL (H, etc.) FOR THE GRIDLINES.
2. USE A 0.5 TECHNICAL PEN FOR THE LETTERS.
3. 1 GRID SPACE MUST BE USED BETWEEN THE UPPER CASE AND SMALLER CASE OF THE LETTER. (EX.
A□a)
4. 2 GRID SPACES MUST BE USED FROM ONE LETTER TO THE NEXT. (EX. a□□B)
THE LETTERS ARE TO BE WRITTEN IN FREEHAND, DO NOT USE A RULER AND A COMPASS.
