19&20-
• Know how to declare pointer variables.
• Understand the & (address) and *(indirection)
operators.
• Dynamic Memory Allocation
• Related Chapter: FER Chapter 12.1, 12.2, 19.1,
19&20-
Pointer variables are variables that store memory addresses.
Pointers variables are useful in passing storage addresses in function calls (call-by-reference) and for applications involving dynamic data structures (e.g., linked lists)
Example: int *intPtr;
float *floatPtr;
declares intPtr to be a pointer variable to an object of type
integer. and floatPtr to be a pointer variable to an object of
type float.
19&20-
We can write the pointer variable declaration
as int* intPtr;
or as int * intPtr;
Note that when we declare more than two pointer variables in one line each pointer name requires an asterisk:
int *ptr1, *ptr2;
otherwise we are just declaring a regular variable , not a pointer variable.
19&20-
There are two C operators that are necessary when using pointer variables.
& - the address operator returns the address of a variable
x
ptrX^1000
ptrX holds the address of x.
We say ptrX “points” to x.
We will apply the & operator only to variables, e.g. &77 or &(x+1) are not valid.
The declaration of ptrX initializes the variable ptrX = &x;
Example:
int x = 3;
int * ptrX = &x;
19&20-
Example:
int x; int * pt; pt = &x; /* another way to assign an address to a pointer variable */
Suppose the address of the variable x is 9640
Then, the effect of pt = &x; will be:
x pt
Address
19&20-
int x; int * pt; pt = &x; To assign the value “3” to the variable x in C: x = 3; We can use the “ * ” operator to indirectly reference x. We can assign “3” to x by:
*pt = 3;
Here we use the fact that “pt” points to integer values.
x pt
Address
9640^3^9640
* - means "a pointer to" and is called an indirection operator or
dereferencing operator, since a pointer "indirectly" references a value in a storage location. Example:
19&20-
double *ptr;
ptr = NULL;
Assigning a NULL value (zero) to a pointer
A null pointer points to nothing. We often depict it as
ptr
/called a null pointer/
19&20-
x
y
Main Memory while executing swap , after *ptrY = temp;
but before return;
ptrX 1000
ptrY 10043004
temp 1
19&20-
1. Problem Definition Write a program that reads a list of
real numbers into an array from the keyboard (or a file
using Unix redirection). The array can be of arbitrary
length but the user must first specify the length of the
array. The program then calculates the average value,
and then prints a list of differences. The differences
are computed by taking the original values in the list
minus the average.
2. Refine, Generalize, Decompose the problem definition
(i.e., identify sub-problems, I/O, etc.)
Input = Since the length of the array is specified at run-
time we must use Dynamic Memory Allocation. This is
accomplished in C by the use of the built-in function
calloc (or malloc). Use data-type double to hold the
values.
Output= The average and the list of differences.
#include <stdio.h> #include <stdlib.h>
void main(void) { int k,num; double * datValptr; /* pointer used in DMA / double datAve; double sum = 0.0; / prompt the user for the number of array elements / printf("Please enter the number of array elements:"); scanf("%i",&num); / use calloc to allocate a block of memory / datValptr = calloc(num,sizeof(double)); / verify that calloc was successful */ if (datValptr = = NULL) { printf("Memory not allocated!\n"); return; } (continued on next slide)
/* read the values and compute the average */
k = 0; for(k=0;k<num;++k) {
scanf("%lf", &datValptr[k]);/* use pointer as array name */ sum += datValptr[k]; }
/* compute the average */
datAve = sum /num;
printf("The average is:%f \n", datAve); /* compute and print the diff list */ for(k=0;k<num;++k) {
printf("%f\n", datValptr[k]-datAve); } /* end of for*/
/* free up any memory that was dynamically allocated */ free(datValptr);
} /* end of main */
19&20-
dclsn75> ./a.out
Please enter the number of array elements:
The average is:3.
dclsn75>
19&20-
The array name in C is assigned the address of the first element of the array.
The following code will assign the address of x[0] to
xPtr :
float x[50];
float * xPtr;
xPtr = x;
The assignment statement above is equivalent to:
xPtr = &x[0];
19&20-
In C, we can dynamically allocate storage with either of
the following two functions (both are in <stdlib.h>).
• malloc(numberOfBytes)
• calloc(numberOfItems, itemSize)
Both functions return a pointer to the address of the block
of storage that has been allocated. If no memory is
available, a NULL value will be returned.
Function calloc returns a contiguous block of
locations that are initialized to 0 and that can be
referenced as array locations, using pointer operations.
19&20-
In both cases above (calloc or malloc) return memory
locations to the system ("memory manager") with:
free (ptr);
Example: Declare ptr as a pointer variable to data-
type double and use dynamic memory allocation
(calloc or malloc) to allocate 100 elements of data-
type double.
double * ptr;
ptr = calloc(100,sizeof(double));
or
ptr = malloc(100*sizeof(double));
