Presentation layout
Introduction Position analysis Free body diagram Design of load pins Design of boom Summary
1
NEED 2 To design the boom of hydraulic digger for:
Bucket capacity =0.25m^3
Digging force =20kN
Max reach =3.5m
Position analysis
A digger can be analyzed by taking its components
as rigid links
And piston cylinders
As crank and slider
Then it becomes a 16 bar linkage mechanism.
4
Position analysis 5
Position analysis
Position analysis 8
P 14
Q 14
R 14
θp (^14) θq 14
θ 14
10
11
Position analysis 13
14
MATLAB PROGRAM FOR POSITION ANALYSIS
Five inputs are needed for the calculation of position of joint at any time.
Boom position Θ 1 Θ 3 Θ 4 Cylinder lengths R7 (Arm Cylinder) R11 (Bucket Cylinder)
16
FREE BODY DIGRAM 17
Fdx
FREE BODY DIGRAM 19
Force analysis
The program can also calculate the joint forces In this case inputs:-
Digging Force Tangent angle of bucket wrt ground (horizontal Axis)
Angle is measured from – ve x-axis.
20
