Power system protection

Lecturer: SEAN Piseth

Students:

VORN Rithy e

YA Phalkun e

YAV Leakhena e

YORN Thort e

2015~

Institute of Technology of Cambodia

Department Electrical and Energy Engineering

1

  • (^) Introduction
  • (^) Generator protection
  • (^) Transformer protection

Bus protection

Transmission line

Conclusion

Content

Introduction

Objective

The important protection systems are:

Protection for Generators

Protection for transformers

Protection for transmission line

Protection for bus

Stator protection

Stator earth fault protection: using inverse time relay

The time of operation depends

upon the magnitude of actuating

quantity. If the magnitude of

actuating quantity is very high,

the relay operation is very fast.

8

Stator protection

Differential protection: using 6 CT’s

The secondaries of all CT’s

are connected in star and

other winding of each CT’s

set are connected through

cable called pilot cable. Three

coil are connected in pilot

cable. They are connected in

an equipotential point of pilot

cable.

Stator protection

Biased circulating current protection (percentage differential relay protection)

11

Negative sequence relay:

Negative phase sequence

relays can identify negative

phase sequence condition and

trip the machine.

Overcurrent relay: the fact

that in the event of fault the

current would increase to a

value several times greater

than maximum load current.

Stator protection

Unbalanced stator loading protection: using negative sequence relay with

overcurrent relay

Sensitive relay: The relay

is free from over travel,

thus permitting close

coordination with other

protective devices.

Rotor earth fault protection

Potentiometer method: using sensitive relay

 Rotor earth fault

protection

AC injection method
This scheme has an
advantage over the
potentiometer method in that
there is no blind spot in the
supervision of the field
system.

Differential relay:

Protection against such faults

can be afforded by a relay

which compare the magnitudes

of two currents in each phase

and closed its contacted

whenever the ratio of the larger

to the smaller exceeds some

predetermined value.

Abnormal condition protection

Restricted or balanced earth fault protection: using differential relay

Abnormal condition protection

Over voltage protection: using over voltage relay

Over voltage may be caused due to-

Transient over voltage in the transmission line due to

lightening.

  • (^) Defective operation of the voltage regulator.
  • (^) Sudden loss of load due to line tripping.

Abnormal condition protection

Under/over frequency protection:

Over frequency protection: it can easily be corrected by reduction in the

power outputs with the help of the governor or manual control.

Under frequency protection: using frequency relay

Present by : YAV Leakhena
