University of California, Berkeley College of Engineering Computer Science Division ⎯ EECS
Fall 2008 John Kubiatowicz
Midterm I October 15th, 2008 CS162: Operating Systems and Systems Programming
Your Name:
SID Number:
Discussion Section:
General Information: This is a closed book exam. You are allowed 1 page of hand-written notes (both sides). You have 3 hours to complete as much of the exam as possible. Make sure to read all of the questions first, as some of the questions are substantially more time consuming.
Write all of your answers directly on this paper. Make your answers as concise as possible. On programming questions, we will be looking for performance as well as correctness, so think through your answers carefully. If there is something about the questions that you believe is open to interpretation, please ask us about it!
Problem Possible Score
1 24
2 12
3 25
4 21
5 18
Total 100
[ This page left for π ]
Reader() { //First check self into system lock.acquire(); while ((AW + WW) > 0) { WR++; okToRead.wait(&lock); WR--; } AR++; lock.release(); // Perform actual read-only access AccessDatabase(ReadOnly); // Now, check out of system lock.acquire(); AR--; if (AR == 0 && WW > 0) okToWrite.signal(); lock.release(); }
Writer() { // First check self into system lock.acquire(); while ((AW + AR) > 0) { WW++; okToWrite.wait(&lock); WW--; } AW++; lock.release(); // Perform actual read/write access AccessDatabase(ReadWrite); // Now, check out of system lock.acquire(); AW--; if (WW > 0){ okToWrite.signal(); } else if (WR > 0) { okToRead.broadcast(); } lock.release(); } Problem 1e[3pts]: Above, we show the Readers-Writers example given in class. It used two condition variables, one for waiting readers and one for waiting writers. Suppose that all of the following requests arrive in very short order (while R 1 and R 2 are still executing):
Incoming stream: R 1 R 2 W 1 W 2 R 3 R 4 R 5 W 3 R 6 W 4 W 5 R 7 R 8 W 6 R 9
In what order would the above code process the above requests? If you have a group of requests that are equivalent (unordered), indicate this clearly by surrounding them with braces ‘{}’. You can assume that the wait queues for condition variables are FIFO in nature (i.e. signal() wakes up the oldest thread on the queue). Explain how you got your answer.
Problem 1f[4pts]: Suppose that you were to redesign the code in (1e). What is the minimum number of condition variables that we would we need in order to handle the above requests in an order that guarantees that a read always returns the results of writes that have arrived before it but not after it? (Another way to say this is that the reads and writes occur in the order in which they arrive, while still allowing groups of reads that arrive together to occur simultaneously.) Provide a two or three sentence sketch of your scheme (do not try to write code!).
Problem 1g[3pts]: What are exceptions? Name two different types of exceptions and give an example of each type:
Problem 1h[2pts]: What was the problem with the Therac-25? Your answer should involve one of the topics of the class.
[ This page intentionally left blank ]
Problem 3: Atomic Synchronization Primitives [25 pts]
In class, we discussed a number of atomic hardware primitives that are available on modern architectures. In particular, we discussed “test and set” (TSET), SWAP, and “compare and swap” (CAS). They can be defined as follows (let “expr” be an expression, “&addr” be an address of a memory location, and “M[addr]” be the actual memory location at address addr):
Test and Set (TSET) Atomic Swap (SWAP) Compare and Swap (CAS) TSET(&addr) { int result = M[addr]; M[addr] = 1; return (result); }
SWAP(&addr, expr) { int result = M[addr]; M[addr] = expr; return (result); }
CAS(&addr, expr1, expr2) { if (M[addr] == expr1) { M[addr] = expr2; return true; } else { return false; } } Both TSET and SWAP return values (from memory), whereas CAS returns either true or false. Note that our &addr notation is similar to a reference in c++, and means that the &addr argument must be something that can be stored into (an “lvalue”). For instance, TSET could be used to implement a spin-lock acquire as follows: int lock = 0; // lock is free // Later: acquire lock while (TSET(lock));
CAS is general enough as an atomic operation that it can be used to implement both TSET and SWAP. For instance, consider the following implementation of TSET with CAS: TSET(&addr) { int temp; do { temp = M[addr]; } while (!CAS(addr,temp,1)); return temp; }
Problem 3a[3pts]: Show how to implement a spinlock acquire with a single while loop using CAS instead of TSET. You must only fill in the arguments to CAS below:
// Initialization int lock = 0; // Lock is free
// acquire lock while ( !CAS( , , ) );
An object such as a queue is considered “lock-free” if multiple processes can operate on this object simultaneously without requiring the use of locks, busy-waiting, or sleeping. In this problem, we are going to construct a lock-free FIFO queue using the atomic CAS operation. This queue needs both an Enqueue and Dequeue method.
We are going to do this in a slightly different way than normally. Rather than Head and Tail pointers, we are going to have “PrevHead” and Tail pointers. PrevHead will point at the last object returned from the queue. Thus, we can find the head of the queue (for dequeuing). If we don’t have to worry about simultaneous Enqueue or Dequeue operations, the code is straightforward ( ignore the null-pointer exception for the Dequeue() operation for now):
// Holding cell for an entry class QueueEntry { QueueEntry next = null; Object stored; QueueEntry(Object newobject) { stored = newobject; } }
// The actual Queue (not yet lock free!) class Queue { QueueEntry prevHead = new QueueEntry(null); QueueEntry tail = prevHead; void Enqueue(Object newobject) { QueueEntry newEntry = new QueueEntry(newobject); QueneEntry oldtail = tail; tail = newEntry; oldtail.next = newEntry; } Object Dequeue() { QueueEntry oldprevHead = prevHead; QueueEntry nextEntry = oldprevHead.next; prevHead = nextEntry; return nextEntry.stored; } }
Problem 3d[3pts]: For this non-multithreaded code, draw the state of a queue with 2 queued items on it:
Problem 3e[3pts]: For each of the following potential context switch points, state whether or not a context switch at that point could cause incorrect behavior of Enqueue(); Explain!
void Enqueue(Object newobject) { 1 QueueEntry newEntry = new QueueEntry(newobject); 2 QueueEntry oldtail = tail; 3 tail = newEntry; oldtail.next = newEntry; }
Point 1:
Point 2:
Point 3:
Problem 3f[4pts]:
Rewrite code for Enqueue(), using the CAS() operation, such that it will work for any number of simultaneous Enqueue and Dequeue operations. You should never need to busy wait. Do not use locking (i.e. don’t use a test-and-set lock). The solution is tricky but can be done in a few lines. We will be grading on conciseness. Do not use more than one CAS() or more than 10 lines total (including the function declaration at the beginning). Hint: wrap a do-while around vulnerable parts of the code identified above.
void Enqueue(Object newobject) { QueueEntry newEntry = new QueueEntry(newobject); // Insert code here
}
Problem 4: Deadlock[21 pts]
Problem 4a[5pts]: The figure at the right illustrates a 2D mesh of network routers. Each router is connected to each of its neighbors by two network links (small arrows), one in each direction. Messages are routed from a source router to a destination router and can stretch through the network (i.e. consume links along the route from source to destination). Messages can cross inside routers. Assume that no network link can service more than one message at a time, and that each message must consume a continuous set of channels (like a snake). Messages always make progress to the destination and never wrap back on themselves. The figure shows two messages (thick arrows). Assume that each router or link has a very small amount of buffer space and that each message can be arbitrarily long. Show a situation (with a drawing) in which messages are deadlocked and can make no further progress. Explain how each of the four conditions of deadlock are satisfied by your example. Hint: Links are the limited resources in this example.
Problem 4b[3pts]: Define a routing policy that avoids deadlocks in the network of (4a). Name one of the four conditions that is no longer possible, given your routing policy. Explain.
Problem 4c[3pts]: Suppose that each router node contains sufficient queue space to hold complete messages (assume infinite space, if you like). Why is it impossible for deadlocks such as in (4a) to occur? Name one of the four conditions that is no longer possible, given infinite queue space in the router. Explain.
R R R R
R R R R
R R R R
R R R R
R R R R
R R R R
R R R R
R R R R
RRR RRR RRR RRR
RRRR RRRR RRRR RRRR
RRRR RRRR RRRR RRRR
RRRR RRRR RRRR RRRR
Problem 4d[4pts]: Suppose that we have the following resources: A, B, C and threads T1, T2, T3, T4. The total number of each resource is:
Further, assume that the processes have the following maximum requirements and current allocations:
Thread Current Allocation Maximum ID (^) A B C A B C T1 2 1 3 4 9 4 T2 1 2 3 5 3 3 T3 5 4 3 6 4 3 T4 2 1 2 4 8 2
Is the system in a safe state? If “yes”, show a non-blocking sequence of thread executions. Otherwise, provide a proof that the system is unsafe. Show all steps, intermediate matrices, etc.
Total A B C 12 9 12
[ This page intentionally left blank ]
Problem 5: Address Translation [18 pts]
Problem 5a[3pts]: Suppose we have a 32-bit processor (with 32-bit virtual addresses) and 8 KB pages. Assume that it can address up to 2 TB (terabytes) of DRAM; 1TB = 1024 GB = (1024)^2 MB. Assume that we need 4 permissions bits in each page table entry (PTE), namely Valid (V), Writable (W), Accessed (A), and Dirty (D). Show the format of a PTE, assuming that each page should be able to hold an integer number of PTEs. If you have extra bits in the PTE, you can mark them as “unused”. Explain.
Problem 5b[5pts]: Assume that we wish to build a two-level page table for the processor from (5a) in which each piece of the page table consumes exactly a page (no more, no less). We may end up wasting space as a result. Draw and label a figure showing how a virtual address gets mapped into a physical address. Show the format of the page table (complete with access checks), the virtual address, and physical address. Minimize pieces of the page table that consume less than a page (and thus waste space).
.
Segment Table (Max Segment=3)
Seg #
Page Table Base
Max Page Entries
Segment State 0 0x02030 0x20 Valid 1 0x01020 0x10 Valid 2 0x01040 0x40 Invalid 3 0x04000 0x20 Valid
Physical Memory Address +0 +1 +2 +3 +4 +5 +6 +7 +8 +9 +A +B +C +D +E +F 0x00000 0E 0F 10 11 12 13 14 15 16 17 18 19 1A 1B 1C 1D 0x00010 1E 1F 20 21 22 23 24 25 26 27 28 29 2A 2B 2C 2D …. 0x01010 40 41 42 43 44 45 46 47 48 49 4A 4B 4C 4D 4E 4F 0x01020 40 03 41 01 30 01 31 03 00 03 00 00 00 00 00 00 0x01030 00 11 22 33 44 55 66 77 88 99 AA BB CC DD EE FF 0x01040 10 01 11 03 31 03 13 00 14 01 15 03 16 01 17 00 …. 0x02030 10 01 11 00 12 03 67 03 11 03 00 00 00 00 00 00 0x02040 02 20 03 30 04 40 05 50 01 60 03 70 08 80 09 90 0x02050 10 00 31 01 10 03 31 01 12 03 30 00 10 00 10 01 …. 0x04000 30 00 31 01 11 01 33 03 34 01 35 00 43 38 32 79 0x04010 50 28 84 19 71 69 39 93 75 10 58 20 97 49 44 59 0x04020 23 03 20 03 00 01 62 08 99 86 28 03 48 25 34 21 …. 0x10000 AA 55 AA 55 AA 55 AA 55 AA 55 AA 55 AA 55 AA 55 0x10010 A5 5A A5 5A A5 5A A5 5A A5 5A A5 5A A5 5A A5 5A …. 0x11000 00 11 22 33 44 55 66 77 88 99 AA BB CC DD EE FF 0x11010 11 22 33 44 55 66 77 88 99 AA BB CC DD EE FF 00 0x11020 22 33 44 55 66 77 88 99 AA BB CC DD EE FF 00 11 …. 0x31000 01 12 23 34 45 56 67 78 89 9A AB BC CD DE EF 00 0x31010 02 13 24 35 46 57 68 79 8A 9B AC BD CE DF F0 01 0x31020 03 01 25 36 47 58 69 7A 8B 9C AD BE CF E0 F1 02 0x31030 04 15 26 37 48 59 70 7B 8C 9D AE BF D0 E1 F2 03 ….
