6: Process Synchronization (^1)

OPERATING SYSTEMS

PROCESS SYNCHRONIZATION

6: Process Synchronization (^2)

What Is In This Chapter?

• This is about getting processes to coordinate with each other.
• How do processes work with resources that must be shared

between them?

• How do we go about acquiring locks to protect regions of memory?
• How is synchronization really used?

OPERATING SYSTEM

Synchronization

6: Process Synchronization (^4)

PROCESS

SYNCHRONIZATION

A producer process "produces" information "consumed" by a consumer process. Here are the variables needed to define the problem:

The Producer

Consumer Problem

#define BUFFER_SIZE 10

typedef struct {

DATA data;

} item;

item buffer[BUFFER_SIZE];

int in = 0; // Location of next input to buffer

int out = 0; // Location of next removal from buffer

int counter = 0; // Number of buffers currently full

Consider the code segments on the next page:

• Does it work?
• Are all buffers utilized?

6: Process Synchronization (^5)

PROCESS

SYNCHRONIZATION

A producer process "produces" information "consumed" by a consumer process.

The Producer

Consumer Problem

item nextProduced;

while (TRUE) { while (counter == BUFFER_SIZE); buffer[in] = nextProduced; in = (in + 1) % BUFFER_SIZE; counter++; }

item nextConsumed;

while (TRUE) { while (counter == 0); nextConsumed = buffer[out]; out = (out + 1) % BUFFER_SIZE; counter--; }

#define BUFFER_SIZE 10 typedef struct { DATA data; } item; item buffer[BUFFER_SIZE]; int in = 0; int out = 0; int counter = 0;

PRODUCER

CONSUMER

producer consumer

6: Process Synchronization (^7)

A section of code, common to n cooperating processes, in which the

processes may be accessing common variables.

A Critical Section Environment contains:

Entry Section Code requesting entry into the critical section.

Critical Section Code in which only one process can execute at any one time.

Exit Section The end of the critical section, releasing or allowing others in.

Remainder Section Rest of the code AFTER the critical section.

SYNCHRONIZATION

Critical Sections

6: Process Synchronization (^8)

The critical section must ENFORCE ALL THREE of the following rules:

Mutual Exclusion: No more than one process can execute in its critical section

at one time.

Progress: If no one is in the critical section and someone wants in,

then those processes not in their remainder section must

be able to decide in a finite time who should go in.

Bounded Wait: All requesters must eventually be let into the critical

section.

SYNCHRONIZATION

Critical Sections

6: Process Synchronization (^10)

Here we try a succession of increasingly complicated solutions to the problem of

creating valid entry sections.

NOTE: In all examples, i is the current process, j the "other" process. In

these examples, envision the same code running on two processors at the same

time.

TOGGLED ACCESS:

do { while ( turn ^= i ); /* critical section / turn = j; / remainder section */ } while(TRUE);

SYNCHRONIZATION

Two Processes

Software

Are the three Critical Section Requirements Met?

Algorithm 1

6: Process Synchronization (^11)

FLAG FOR EACH PROCESS GIVES STATE:

Each process maintains a flag indicating that it wants to get into the critical section. It

checks the flag of the other process and doesn’t enter the critical section if that other

process wants to get in.

Are the three Critical Section Requirements Met?

SYNCHRONIZATION

Two Processes

Software

do {

flag[i] := true;

while (flag[j]) ;

critical section

flag [i] = false;

remainder section

} while (1);

Algorithm 2

Shared variables

boolean flag[2];

initially flag [0] = flag [1] = false.

flag [i] = true ⇒ Pi ready to enter its critical section

6: Process Synchronization (^13)

The hardware required to support critical sections must have

(minimally):

• Indivisible instructions (what are they?)
• Atomic load, store, test instruction. For instance, if a store and

test occur simultaneously, the test gets EITHER the old or the

new, but not some combination.

• Two atomic instructions, if executed simultaneously, behave as if

executed sequentially.

SYNCHRONIZATION

Critical Sections

6: Process Synchronization (^14)

Disabling Interrupts: Works for the Uni Processor case only. WHY?

Atomic test and set: Returns parameter and sets parameter to true atomically.

while ( test_and_set ( lock ) );

/* critical section */

lock = false;

Example of Assembler code:

GET_LOCK: IF_CLEAR_THEN_SET_BIT_AND_SKIP <bit_address>

BRANCH GET_LOCK /* set failed */

------- /* set succeeded */

Must be careful if these approaches are to satisfy a bounded wait condition - must

use round robin - requires code built around the lock instructions.

SYNCHRONIZATION

Hardware

Solutions

6: Process Synchronization (^16)

We first need to define, for multiprocessors:

caches,

shared memory (for storage of lock variables),

write through cache,

write pipes.

The last software solution we did ( the one we thought was correct ) may not

work on a cached multiprocessor. Why? { Hint, is the write by one

processor visible immediately to all other processors?}

What changes must be made to the hardware for this program to work?

SYNCHRONIZATION

Current Hardware

Dilemmas

6: Process Synchronization (^17)

Does the sequence below work on a cached multiprocessor?

Initially, location a contains A0 and location b contains B0.

a) Processor 1 writes data A1 to location a.

b) Processor 1 sets b to B1 indicating data at a is valid.

c) Processor 2 waits for b to take on value B1 and loops until that

change occurs.

d) Processor 2 reads the value from a.

What value is seen by Processor 2 when it reads a?

How must hardware be specified to guarantee the value seen?

SYNCHRONIZATION

Current Hardware

Dilemmas

a: A0 b: B

6: Process Synchronization (^19)

Hardware test and set on a multiprocessor causes

• an explicit flush of the write to main memory and
• the update of all other processor's caches.

Imagine needing to write all shared data straight through the cache.

With test and set, only lock locations are written out explicitly.

In not too many years, hardware will no longer support software solutions

because of the performance impact of doing so.

SYNCHRONIZATION

Current Hardware

Dilemmas

6: Process Synchronization (^20)

PURPOSE:

We want to be able to write more complex constructs and so need a language to do

so. We thus define semaphores which we assume are atomic operations:

As given here, these are not atomic as written in "macro code". We define these

operations, however, to be atomic (Protected by a hardware lock.)

FORMAT:

wait ( mutex ); <-- Mutual exclusion: mutex init to 1.

CRITICAL SECTION

signal( mutex );

REMAINDER

WAIT ( S ):

while ( S <= 0 ); S = S - 1;

SIGNAL ( S ):

S = S + 1;

SYNCHRONIZATION

Semaphores
