Resistors and Capacitors | Lecture notes Basic Electronics

Resistors are classified into two broad categories i.e. Fixed and Variable. The Resistors whose values cannot

be changed and are fixed are called as Fixed Resistors and the resistors of which we can change the values

as per our requirement are called as Variable resistors.

Fixed Resistors

1. Carbon Film/Cracked Carbon Resistors: As the name suggests, the carbon film resistors have a film

of carbon deposited onto a suitable insulator such as ceramic in this case. These resistors have a

tolerance between ±5% to ±20%.

Construction:

 The substrate used is a ceramic stick of length between 10mm to 45mm and diameter between 3mm

and 8mm. The ceramic sticks are degreased by putting them in 10% HCl soln. in a revolving container.

This process goes on for 45 minutes and after that a 70% ammonia soln. is added in the container

and rotation goes on for 30 to 40 minutes. The sticks are washed in a continuous stream of water to

wash out every chemical. A centrifugal drier dries up the ceramic sticks and removes all moisture.

 The degreased ceramic sticks are put into an electrically heated oven that is rotated. The oven is first

cleaned with Benzene or petrol and the sticks are placed along the entire length. The end covers are

closed and air is removed with the help of vacuum pump. The temperature of oven is risen upto 3000C.

 When the pressure inside the oven reaches a minimum level, the vacuum pump is disconnected and

the stopper of the heated benzene flask is opened. Benzene is sucked onto the chamber. The gas

carbonises on entering the chamber and a uniform film of carbon is deposited on the hot ceramic

sticks. The time and amount of benzene suction in the chamber decides the resistance.

 After cooling, the carbonised sticks are gently transferred to a revolving container and Bakelite or

silicon is poured over them which forms a protective cover over the carbon film

 The caps are made of nickel-coated steel or brass and leads are attached to it. The caps are pressed

onto the sticks to fix them onto the sticks. The resistors are sorted as per their resistance values and

stored in different containers. The leads are soldered to the caps to make electrical contact across

carbon film.

Rating

10ohm to 10Mohm

wattage

0.25watts to 2 watts

Tolerance

5% to 20%

Operating temperature

-40C to 120C

Max. operating Voltage

500V DC
