Scheduling Algorithms

Jay Kothari ([email protected]) CS 370: Operating Systems July 9, 2008

CPU Scheduling

• Earlier, we talked about the life-cycle of a thread
  • Active threads work their way from Ready queue to Running to various waiting queues.
• Question: How is the OS to decide which of several tasks to take off a queue? - Obvious queue to worry about is ready queue - Others can be scheduled as well, however
• Scheduling: deciding which threads are given access to resources from moment to moment

Program behavior and scheduling...

Assumption: CPU Bursts

What is important in a scheduling algorithm?

Scheduling Policy Goals/Criteria

• Minimize Response Time
  • Minimize elapsed time to do an operation (or job)
  • Response time is what the user sees:
    • Time to echo a keystroke in editor
    • Time to compile a program
    • Real-time Tasks: Must meet deadlines imposed by World
• Maximize Throughput
  • Maximize operations (or jobs) per second
  • Throughput related to response time, but not identical:
    • Minimizing response time will lead to more context switching than if you only maximized throughput
  • Two parts to maximizing throughput
    • Minimize overhead (for example, context-switching)
    • Efficient use of resources (CPU, disk, memory, etc)
• Fairness
  • Share CPU among users in some equitable way
  • Fairness is not minimizing average response time:
    • Better average response time by making system less fair

First-Come, First-Serve Scheduling (1)

• First-Come, First-Served (FCFS)
• Also “First In, First Out” (FIFO) or “Run until done”
• In early systems, FCFS meant one program scheduled until done (including I/O)
• Now, means keep CPU until thread blocks
• Example:
  • Suppose processes arrive in the order: P1 , P2 , P3 The Gantt Chart for the schedule is:
  • Waiting time for P1 = 0; P2 = 24; P3 = 27
  • Average waiting time: (0 + 24 + 27)/3 = 17
  • Average Completion time: (24 + 27 + 30)/3 = 27 P 1 P 2 P 3 0 24 27 30

FCFS (2)

• Example continued:
  • Suppose that processes arrive in order: P2 , P3 , P Now, the Gantt chart for the schedule is:
  • Waiting time for P1 = 6; P2 = 0; P3 = 3
  • Average waiting time: (6 + 0 + 3)/3 = 3
  • Average Completion time: (3 + 6 + 30)/3 = 13
• In second case:
  • Average waiting time is much better (before it was 17)
  • Average completion time is better (before it was 27)
• FIFO Pros and Cons:
  • Simple (+)
  • Short jobs get stuck behind long ones (-)
    • Supermarket: Getting milk, always stuck behind cart full of small items. Upside: get to read about Britney Spears! P 2 P 3 P 1 0 3 6 30

Round Robin (RR) Scheduling

• FCFS Scheme: Potentially bad for short jobs!
  • Depends on submit order
  • If you are first in line at supermarket with milk, you don’t care who is behind you, on the other hand…
• Round Robin Scheme
  • Each process gets a small unit of CPU time (time quantum), usually 10-100 milliseconds
  • After quantum expires, the process is preempted and added to the end of the ready queue.
  • n processes in ready queue and time quantum is q
    • Each process gets 1/n of the CPU time
    • In chunks of at most q time units
    • No process waits more than (n-1)q time units
• Performance
  • q large FCFS
  • q small Interleaved (really small hyperthreading?)
  • q must be large with respect to context switch, otherwise overhead is too high (all overhead)

RR with Time Quantum = 20 milliseconds

• Example:
  • Waiting time for P1=(68-20)+(112-88)= P2=(20-0)= P3=(28-0)+(88-48)+(125-108)= P4=(48-0)+(108-68)=
  • Average waiting time = (72+20+85+88)/4=66¼
  • Average completion time = (125+28+153+112)/4 = 104½
• Thus, Round-Robin Pros and Cons:
  • Better for short jobs, Fair (+)
  • Context-switching time adds up for long jobs (-) P 1 P 2 P 3 P 4 P 1 P 3 P 4 P 1 P 3 P 3 0 20 28 48 68 88 108 112 125 145 153

Comparing FCFS and RR

• Assuming zero-cost context-switching time, is RR always better than FCFS?
• Simple example: 10 jobs, each take 100s of CPU time RR scheduler quantum of 1s All jobs start at the same time
• Completion Times:
  • Both RR and FCFS finish at the same time
  • Average response time is much worse under RR!
    • Bad when all jobs same length
• Also: Cache state must be shared between all jobs with RR but can be devoted to each job with FIFO - Total time for RR longer even for zero-cost switch!

FCFS with Different Time Quantum

• Best FCFS:

Discussion

• SJF/SRTF are the best you can do at minimizing average response time
  • Provably optimal (SJF among non-preemptive, SRTF among

preemptive)

• Since SRTF is always at least as good as SJF, focus on SRTF
• Comparison of SRTF with FCFS and RR
• What if all jobs the same length?
• SRTF becomes the same as FCFS (i.e. FCFS is best can do

if all jobs the same length)

• What if jobs have varying length?
  • SRTF (and RR): short jobs not stuck behind long ones

Example: SRTF (1)

• Three jobs:
  • A,B: both CPU bound, run for week C: I/O bound, loop 1ms CPU, 9ms disk I/O
  • If only one at a time, C uses 90% of the disk, A or B could use 100% of the CPU
• With FIFO:
  • Once A or B get in, keep CPU for two weeks
• What about RR or SRTF?
  • Easier to see with a timeline
