1
CM0368
Scientific Computing
Spring 2009
Professor David Walker
[email protected]
Schedule
• Weeks 1 & 2 (6): Numerical linear algebra (DWW)
– Solving Ax= b by Gaussian elimination and Gauss-Seidel.
– Algebraic eigenvalue problem. Power method and QR method.
• Weeks 3 & 4 (6): Numerical solution of differential
equations (BMB)
– Ordinary differential equations (finite difference and Runge-Kutta
methods).
– Partial differential equations (finite difference method)
• Weeks 5 & 6 (5): Applications in Physics (BMB)
– Laplace and Helmholtz equations, Schrodinger problem for the
hydrogen atom, etc.
• Weeks 6 & 7 (4): Numerical optimisation (DWW)
• Weeks 2 – 11: Tutorials on Wednesdays at 1pm in
T2.07. These will be given by Kieran Robert.
Text Book
• “Numerical Computing with MATLAB” by
Cleve B. Moler, SIAM Press, 2004. ISBN
0898715601.
•http://www.readinglists.co.uk/rsl/student/sv
iewlist.dfp?id=20248
• Web edition at
http://www.mathworks.com/moler/
Web Site
• Lecture notes and other module material
can be found at:
http://users.cs.cf.ac.uk/David.W.Walker/CM0368
Numerical Linear Algebra
• A system of n simultaneous linear equations can
be represented in matrix notation as:
Ax= b
where A is an nμn matrix, and xand bare
vectors of length n.
• Can write solution as x= A-1b where A-1 is the
inverse of A.
• A square matrix is said to be non-singular if its
inverse exists. If the inverse does not exist then
the matrix is singular.
Geometrical Interpretation
•If A is a 2μ2 matrix, for example
⎟
⎟
⎠
⎞
⎜
⎜
⎝
⎛
−
=
⎟
⎟
⎠
⎞
⎜
⎜
⎝
⎛
⎟
⎟
⎠
⎞
⎜
⎜
⎝
⎛−
1
3
43
12
2
1
x
x
•If A is a 3μ3 matrix each of the three equations
represents a plane, and the solution is the point lying at
the intersection of the three planes.
then 2x1–x
2= 3 and 3x1+ 4x2= -1. Each
represents a straight line and the solution of the
above is given by their intersection.
