Table of Contents

ReadMe

About this Book

Remoting Basics

Accessing Remote Computers

Working with Endpoints, AKA Session Configurations

Diagnostics and Troubleshooting

Session Management

PowerShell Remoting and Security

Configuring Remoting via GPO

Secrets of PowerShell Remoting

Principle author: Don Jones Contributing author: Dr. Tobias Weltner With contributions by Dave Wyatt and Aleksandar Nikolik Cover design by Nathan Vonnahme

Introduced in Windows PowerShell 2.0, Remoting is one of PowerShell's most useful, and most important, core technologies. It enables you to run almost any command that exists on a remote computer, opening up a universe of possibilities for bulk and remote administration. Remoting underpins other technologies, including Workflow, Desired State Configuration, certain types of background jobs, and much more. This guide isn't intended to be a complete document of what Remoting is and does, although it does provide a good introduction. Instead, this guide is designed to document all the little configuration details that don't appear to be documented elsewhere.

This guide is released under the Creative Commons Attribution-NoDerivs 3.0 Unported License. The authors encourage you to redistribute this file as widely as possible, but ask that you do not modify the document.

Was this book helpful? The author(s) kindly ask(s) that you make a tax-deductible (in the US; check your laws if you live elsewhere) donation of any amount to The DevOps Collective to support their ongoing work.

Check for Updates! Our ebooks are often updated with new and corrected content. We make them available in three ways:

Our main, authoritative GitHub organization, with a repo for each book. Visit https://github.com/devops-collective-inc/ Our GitBook page, where you can browse books online, or download as PDF, EPUB, or MOBI. Using the online reader, you can link to specific chapters. Visit https://www.gitbook.com/@devopscollective On LeanPub, where you can download as PDF, EPUB, or MOBI (login required), and "purchase" the books to make a donation to DevOps Collective. You can also choose to be notified of updates. Visit https://leanpub.com/u/devopscollective

GitBook and LeanPub have slightly different PDF formatting output, so you can choose the one you prefer. LeanPub can also notify you when we push updates. Our main GitHub repo is authoritative; repositories on other sites are usually just mirrors used for the publishing

About this Book

process. GitBook will usually contain our latest version, including not-yet-finished bits; LeanPub always contains the most recent "public release" of any book.

About this Book

As shown in figure 1.1, PowerShell's generic Remoting architecture consists of numerous different, interrelated components and elements.

Figure 1.1: The elements and components of PowerShell Remoting

Here is the complete list:

■ At the bottom of the figure is your computer, or more properly your client. This is where you physically sit, and it's where you'll initiate most of your Remoting activities.

■ Your computer will communicate via the WS-MAN, or Web Services for Management, protocol. This is an HTTP(S)-based protocol that can encapsulate a variety of different communications. We've illustrated this as using HTTP, which is Remoting's default configuration, but it could just as easily be HTTPS.

Remoting Basics

■ On the remote computer, in the proper terminology the server (which does not refer to the operating system), the Windows Remote Management (WinRM) service runs. This service is configured to have one or more listeners. Each listener waits for incoming WS-MAN traffic on a specific port, each bound to a specific protocol (HTTP or HTTPS), and on specific IP addresses (or all local addresses).

■ When a listener receives traffic, the WinRM service looks to see which endpoint the traffic is meant for. For our purposes, an endpoint will usually be launching an instance of Windows PowerShell. In PowerShell terms, an endpoint is also called a session configuration. This is because, in addition to launching PowerShell, it can auto-load scripts and modules, place restrictions upon what can be done by the connecting user, and apply additional session specific settings not mentioned here.

Note Although we show PowerShell.exe in our diagram, that's for illustration purposes. PowerShell.exe is the PowerShell console application, and it would not make sense to have this running as a background process on a remote computer. The actual process is called Wsmprovhost.exe , which hosts PowerShell in the background for Remoting connections.

As you can see, a single remote computer can easily have dozens or even hundreds of endpoints, each with a different configuration. PowerShell 3.0 sets up three such endpoints by default: One for 32-bit PowerShell (on 64-bit systems), the default PowerShell endpoint (which is 64-bit on x64 systems), and one for PowerShell Workflow. Beginning with Windows Server 2008 R2, there is a fourth default endpoint for Server Manager Workflow tasks.

Enabling Remoting

Most client versions of Windows, beginning with Windows Vista, do not enable incoming Remoting connections by default. Newer Windows Server versions do, but older versions may not. So your first step with Remoting will usually be to enable it on those computers which you want to receive incoming connections. There are three ways to enable Remoting, and table 1.1 compares what is achievable with each of them.

Table 1.1 Comparing the ways of enabling remoting

Remoting Basics

Figure 1.2: Test environment configuration

Some important notes:

■ .NET Framework v4 and PowerShell 3.0 is installed on all computers. Most of what we'll cover also applies to PowerShell 2.0.

■ As shown, most computers have a numeric computer name (C2108222963, and so on); the domain controller for each domain (which is also a DNS server) has CNAME records with easier-to-remember names.

■ Each domain controller has a conditional forwarder set up for the other domain, so that machines in either domain can resolve computer names in the other domain.

■ We performed all tasks as a member of the Domain Admins group, unless noted otherwise.

■ We created a sixth, completely standalone server that isn't in any domain at all. This will be useful for covering some of the non-domain situations you can find yourself in with Remoting.

Caution When opening PowerShell on a computer that has User Account Control (UAC) enabled, make sure you right-click the PowerShell icon and select Run as Administrator. If the resulting PowerShell window's title bar doesn't begin with Administrator: then you do

Remoting Basics

not have administrative privileges. You can check permissions programmatically with this (whoami /all | select-string S-1-16-12288) -ne $null from the PowerShell console. In an elevated shell True is returned, otherwise False is.

Enabling Remoting

We began by running Enable-PSRemoting on all six computers. We took care to ensure that the command ran without error; any errors at this point are a signal that you must stop and resolve the error before attempting to proceed. Figure 1.3 shows the expected output.

Figure 1.3: Expected output from Enable-PSRemoting

Note: You'll notice profligate use of screen shots throughout this guide. It helps ensure that I don't make any typos or copy/paste errors - you're seeing exactly what we typed and ran.

Running Get-PSSessionConfiguration should reveal the three or four endpoints created by Enable-PSRemoting. Figure 1.4 shows the expected output on a server.

Remoting Basics

Figure 1.5: Checking remoting connectivity from COMPANY.loc's CLIENTA to the DCA domain controller.

Caution: If you're following along in your own test environment, don't proceed until you've confirmed Remoting connectivity between two computers in the same domain. No other scenario needs to work right now; we'll get to them in the upcoming sections.

Core Remoting Tasks

PowerShell provides for two principal Remoting use cases. The first, 1-to-1 Remoting, is similar in nature to the SSH secure shell offered on UNIX and Linux systems. With it, you get a command-line prompt on a single remote computer. The second, 1-to-Many Remoting, enables you to send a command (or a list of commands) in parallel to a set of remote computers. There are also a couple of useful secondary techniques we'll look at.

1-to-1 Remoting

The Enter-PSSession command connects to a remote computer and gives you a command- line prompt on that computer. You can run whatever commands are on that computer, provided you have permission to perform that task. Note that you are not creating an interactive logon session; your connection will be audited as a network logon, just as if you

Remoting Basics

were connecting to the computer's C$ administrative share. PowerShell will not load or process profile scripts on the remote computer. Any scripts that you choose to run (and this includes importing script modules) will only work if the remote machine's Execution Policy permits it.

Enter-PSSession -computerName DC

Note: While connected to a remote machine via Enter-PSSession, your prompt changes and displays the name of the remote system in square brackets. If you have customized your prompt, all customizations will be lost because the prompt is now created on the remote system and transferred back to you. All of your interactive keyboard input is sent to the remote machine, and all results are marshaled back to you. This is important to note because you cannot use Enter-PSSession in a script. If you did, the script would still run on your local machine since no code was entered interactively.

1-to-Many Remoting

With this technique, you specify one or more computer names and a command (or a semicolon-separated list of commands); PowerShell sends the commands, via Remoting, to the specified computers. Those computers execute the commands, serialize the results into XML, and transmit the results back to you. Your computer deserializes the XML back into objects, and places them in the pipeline of your PowerShell session. This is accomplished via the Invoke-Command cmdlet.

Invoke-Command -computername DC01,CLIENT1 -scriptBlock { Get-Service }

If you have a script of commands to run, you can have Invoke-Command read it, transmit the contents to the remote computers, and have them execute those commands.

Invoke-Command -computername DC01,CLIENT1 -filePath c:\Scripts\Task.ps

Note that Invoke-Command will, by default, communicate with only 32 computers at once. If you specify more, the extras will queue up, and Invoke-Command will begin processing them as it finishes the first 32. The -ThrottleLimit parameter can raise this limit; the only cost is to your computer, which must have sufficient resources to maintain a unique PowerShell session for each computer you're contacting simultaneously. If you expect to receive large amounts of data from the remote computers, available network bandwidth can be another limiting factor.

Sessions

Remoting Basics

prevent others from connecting. By default, only 10 simultaneous connections to a remote machine are permitted. If you keep too many active sessions, you will easily run into resource limits. This line demonstrates what happens if you try and set up too many simultaneous sessions:

PS> 1..10 | Foreach-Object { New-PSSession -ComputerName CLIENT1 }

Remoting Returns Deserialized Data

The results you receive from a remote computer have been serialized into XML, and then deserialized on your computer. In essence, the objects placed into your shell's pipeline are static, detached snapshots of what was on the remote computer at the time your command completed. These deserialized objects lack the methods of the originals objects, and instead only offer static properties.

If you need to access methods or change properties, or in other words if you must work with the live objects, simply make sure you do so on the remote side, before the objects get serialized and travel back to the caller. This example uses object methods on the remote side to determine process owners which works just fine:

PS> Invoke-Command -ComputerName CLIENT1 -scriptBlock { Get-WmiObject -Class Win32_Pro cess | Select-Object Name, { $_.GetOwner().User } }

Once the results travel back to you, you can no longer invoke object methods because now you work with "rehydrated" objects that are detached from the live objects and do not contain any methods anymore:

PS> Invoke-Command -ComputerName CLIENT1 -scriptBlock { Get-WmiObject -Class Win32_Pro cess } | Select-Object Name, { $_.GetOwner().User }

Serializing and deserializing is relatively expensive. You can optimize speed and resources by making sure that your remote code emits only the data you really need. You could for example use Select-Object and carefully pick the properties you want back rather than serializing and deserializing everything.

Enter-PSSession vs. Invoke-Command

Remoting Basics

A lot of newcomers will get a bit confused about remoting, in part because of how PowerShell executes scripts. Consider the following, and assume that SERVER2 contains a script named C:\RemoteTest.ps1:

Enter-PSSession -ComputerName SERVER C:\RemoteTest.ps

If you were to sit and type these commands interactively in the console window on your client computer, this would work (assuming remoting was set up, you had permissions, and all that). However, if you pasted these into a script and ran that script, it wouldn't work. The script would try to run C:\RemoteTest.ps1 on your local computer.

The practical upshot of this is that Enter-PSSession is really meant for interactive use by a human being, not for batch use by a script. If you wanted to send a command to a remote computer, from within a script, Invoke-Command is the right way to do it. You can either set up a session in advance (useful if you plan to send more than one command), or you can use a computer name if you only want to send a single command. For example:

$session = New-PSSession -ComputerName SERVER Invoke-Command -session $session -ScriptBlock { C:\RemoteTest.ps1 }

Obviously, you'll need to use some caution. If those were the only two lines in the script, then when the script finished running, $session would cease to exist. That might disconnect you (in a sense) from the session running on SERVER2. What you do, and even whether you need to worry about it, depends a lot on what you're doing and how you're doing it. In this example, everything would probably be okay, because Invoke-Command would "keep" the local script running until the remote script finished and returned its output (if any).

Remoting Basics

name, an IP address, or a CNAME alias) to your local computer's WinRM TrustedHosts list. Note that this basically disables mutual authentication: You're allowing WinRM to connect to that one identifier (name, IP address, or whatever) without mutual authentication. This opens the possibility for a machine to pretend to be the one you want, so use due caution.

In both cases, you also have to specify a -Credential parameter to your Remoting command, even if you're just specifying the same credential that you're using to run PowerShell. We'll cover both cases in the next two sections.

Note: Throughout this guide, we'll use "Remoting command" to generically refer to any command that involves setting up a Remoting connection. Those include (but are not limited to) New-PSSession, Enter-PSSession, Invoke-Command, and so on.

Setting up an HTTPS Listener

This is one of the more complex things you can do with Remoting, and will involve running a lot of external utilities. Sorry - that's just the way it's done! Right now there doesn't seem to be an easy way to do this entirely from within PowerShell, at least not that we've found. Some things, as you'll see, could be done through PowerShell, but are more easily done elsewhere - so that's what I've done.

Your first step is to identify the host name that people will use to access your server. This is very, very important, and it isn't necessarily the same as the server's actual computer name. For example, folks accessing "www.ad2008r2.loc" might in fact be hitting a server named "DC01," but the SSL certificate you'll create must be issued to host name "www.ad2008r2.loc" because that's what people will be typing. So, the certificate name needs to match whatever name people will be typing to get to the machine - even if that's different from its true computer name. Got that?

Note: As the above implies, part of setting up an HTTPS listener is obtaining an SSL certificate. I'll be using a public Certification Authority (CA) named DigiCert.com. You could also use an internal PKI, if your organization has one. I don't recommend using MakeCert.exe, since such a certificate can't be implicitly trusted by the machines attempting to connect. I realize that every blog in the universe tells you to use MakeCert.exe to make a local self-signed certificate. Yes, it's easy - but it's wrong. Using it requires you to shut off most of WinRM's security - so why bother with SSL if you plan to shut off most of its security features?

You need to make sure you know the full name used to connect to a computer, too. If people will have to type "dc01.ad2008r2.loc," then that's what goes into the certificate. If they'll simply need to provide "dca," and know that DNS can resolve that to an IP address, then

Accessing Remote Computers

"dca" is what goes into the certificate. We're creating a certificate that just says "dca" and we'll make sure our computers can resolve that to an IP address.

Creating a Certificate Request

Unlike IIS, PowerShell doesn't offer a friendly, graphical way of creating a Certificate Request (or, in fact, any way at all to do so.) So, go to http://DigiCert.com/util and download their free certificate utility. Figure 2.1 shows the utility. Note the warning message.

Figure 2.1: Launching DigiCertUtil.exe

You only need to worry about this warning if you plan to acquire your certificate from the DigiCert CA; click the Repair button to install their intermediate certificates on your computer, enabling their certificate to be trusted and used. Figure 2.2 shows the result of doing so. Again, if you plan to take the eventual Certificate Request (CSR) to a different CA, don't worry about the Repair button or the warning message.

Note You can also open a blank MMC console and add Windows' "Certificate" snap-in. Focus it on the computer account for the local computer (you'll be prompted). Then, right- click on the "Personal" folder and select All Tasks to find the option to create a new

Accessing Remote Computers
