Security Technology

Chapter 8

People are the missing link to improving

Information Security. Technology alone can't solve the challenges

of Information Security. -- The Human Firewall Council

Principles of Information Security - Chapter 8

Slide 2

Learning Objectives:Upon completion of this chapter you should be able to:– Define and identify the various types of firewalls.– Discuss the approaches to firewallimplementation.– Discuss the approaches to dial-up access andprotection.– Identify and describe the two categories ofintrusion detection systems.– Discuss the two strategies behind intrusiondetection systems.

Principles of Information Security - Chapter 8

Slide 4

Physical Design of theSecSDLC The physical design phase of theSecSDLC is made up of two parts:– security technologies– physical security

Principles of Information Security - Chapter 8

Slide 5docsity.com

Principles of Information Security - Chapter 8

Slide 7

Firewalls ^ A firewall is any device that prevents a specifictype of information from moving between theuntrusted network outside and the trustednetwork inside ^ There are five recognized generations offirewalls ^ The firewall may be:– a separate computer system– a service running on an existing router or server– a separate network containing a number ofsupporting devices

Principles of Information Security - Chapter 8

Slide 8

First Generation Called packet filtering firewalls Examines every incoming packet headerand selectively filters packets based on– address, packet type, port request, andothers factors The restrictions most commonlyimplemented are based on:– IP source and destination address– Direction (inbound or outbound)– TCP or UDP source and destination port-requests

Principles of Information Security - Chapter 8

Slide 10

Second Generation ^ Called application-level firewall or proxy server ^ Often a dedicated computer separate from thefiltering router ^ With this configuration the proxy server, ratherthan the Web server, is exposed to the outsideworld in the DMZ ^ Additional filtering routers can be implementedbehind the proxy server ^ The primary disadvantage of application-levelfirewalls is that they are designed for a specificprotocol and cannot easily be reconfigured toprotect against attacks on protocols for whichthey are not designed

Principles of Information Security - Chapter 8

Slide 11

Third Generation ^ Called stateful inspection firewalls ^ Keeps track of each network connection establishedbetween internal and external systems using a statetable which tracks the state and context of each packetin the conversation by recording which station sent whatpacket and when ^ If the stateful firewall receives an incoming packet that itcannot match in its state table, then it defaults to its ACLto determine whether to allow the packet to pass ^ The primary disadvantage is the additional processingrequirements of managing and verifying packets againstthe state table which can possibly expose the system toa DoS attack ^ These firewalls can track connectionless packet trafficsuch as UDP and remote procedure calls (RPC) traffic

Principles of Information Security - Chapter 8

Slide 13

Fifth Generation The final form of firewall is the kernelproxy, a specialized form that works underthe Windows NT Executive, which is thekernel of Windows NT It evaluates packets at multiple layers ofthe protocol stack, by checking security inthe kernel as data is passed up and downthe stack

Principles of Information Security - Chapter 8

Slide 14

Packet-filtering Routers ^ Most organizations with an Internet connection havesome form of a router as the interface at the perimeterbetween the organization’s internal networks and theexternal service provider ^ Many of these routers can be configured to filter packetsthat the organization does not allow into the network ^ This is a simple but effective means to lower theorganization’s risk to external attack ^ The drawback to this type of system includes a lack ofauditing and strong authentication ^ The complexity of the access control lists used to filterthe packets can grow and degrade networkperformance

Principles of Information Security - Chapter 8

Slide 16docsity.com

Principles of Information Security - Chapter 8

Slide 17

Dual-homed Host Firewalls ^ The bastion-host contains two NICs (networkinterface cards) ^ One NIC is connected to the external network,and one is connected to the internal network ^ With two NICs all traffic must physically gothrough the firewall to move between theinternal and external networks ^ A technology known as network-addresstranslation (NAT) is commonly implementedwith this architecture to map from real, valid,external IP addresses to ranges of internal IPaddresses that are non-routable

Principles of Information Security - Chapter 8

Slide 19

Screened-Subnet Firewalls(with DMZ) ^ Consists of two or more internal bastion-hosts, behind apacket-filtering router, with each host protecting thetrusted network ^ The first general model consists of two filtering routers,with one or more dual-homed bastion-host betweenthem ^ The second general model involves the connection fromthe outside or untrusted network going through thispath:– Through an external filtering router– Into and then out of a routing firewall to the separate networksegment known as the DMZ ^ Connections into the trusted internal network areallowed only from the DMZ bastion-host servers

Principles of Information Security - Chapter 8

Slide 20docsity.com
