What Are Seismic Waves?
Seismic waves are the waves of energy caused by the sudden breaking of rock within the earth or an explosion. They are the energy that travels through the earth and is recorded on seismographs. Types of Seismic Waves There are several different kinds of seismic waves, and they all move in different ways. The two main types of waves are body waves and surface waves. Body waves can travel through the earth's inner layers, but surface waves can only move along the surface of the planet like ripples on water. Earthquakes radiate seismic energy as both body and surface waves. BODY WAVES Traveling through the interior of the earth, body waves arrive before the surface waves emitted by an earthquake. These waves are of a higher frequency than surface waves. P WAVES The first kind of body wave is the P wave or primary wave. This is the fastest kind of seismic wave, and, consequently, the first to 'arrive' at a seismic station. The P wave can move through solid rock and fluids, like water or the liquid layers of the earth. It pushes and pulls the rock it moves through just like sound waves push and pull the air. Have you ever heard a big clap of thunder and heard the windows rattle at the same time? The windows rattle because the sound waves were pushing and pulling on the window glass much like P waves push and pull on rock. Sometimes animals can hear the P waves of an earthquake. Dogs, for instance, commonly begin barking hysterically just before an earthquake 'hits' (or more specifically, before the surface waves arrive). Usually people can only feel the bump and rattle of these waves. P waves are also known as compressional waves, because of the pushing and pulling they do. Subjected to a P wave, particles move in the same direction that the wave is moving in, which is the direction that the energy is traveling in, and is sometimes called the 'direction of wave propagation'. S WAVES
The second type of body wave is the S wave or secondary wave, which is the second wave you feel in an earthquake. An S wave is slower than a P wave and can only move through solid rock, not through any liquid medium. It is this property of S waves that led seismologists to conclude that the Earth's outer core is a liquid. S waves move rock particles up and down, or side-to-side-- perpendicular to the direction that the wave is traveling in (the direction of wave propagation). SURFACE WAVES Travelling only through the crust, surface waves are of a lower frequency than body waves, and are easily distinguished on a seismogram as a result. Though they arrive after body waves, it is surface waves that are almost entirely responsible for the damage and destruction associated with earthquakes. This damage and the strength of the surface waves are reduced in deeper earthquakes. LOVE WAVES The first kind of surface wave is called a Love wave, named after A.E.H. Love, a British mathematician who worked out the mathematical model for this kind of wave in 1911. It's the fastest surface wave and moves the ground from side-to-side. Confined to the surface of the crust, Love waves produce entirely horizontal motion. RAYLEIGH WAVES The other kind of surface wave is the Rayleigh wave, named for John William Strutt, Lord Rayleigh, who mathematically predicted the existence of this kind of wave in 1885. A Rayleigh wave rolls along the ground just like a wave rolls across a lake or an ocean. Because it rolls, it moves the ground up and down, and side-to-side in the same direction that the wave is moving. Most of the shaking felt from an earthquake is due to the Rayleigh wave, which can be much larger than the other waves.
magnitude level category effects earthquakes per year less than 1. to 2. micro generally not felt by people, though recorded on local instruments more than 100, 3.0–3.9 minor felt by many people; no damage
4.0–4.9 light felt by all; minor breakage of objects
5.0–5.9 moderate some damage to weak structures
6.0–6.9 strong moderate damage in populated areas
7.0–7.9 major serious damage over large areas; loss of life
8.0 and higher great severe destruction and loss of life over large areas fewer than 3 Richter scale of earthquake magnitude At the present time a number of different magnitude scales are used by scientists and engineers as a measure of the relative size of an earthquake. The P-wave magnitude (Mb), for one, is defined in terms of the amplitude of the P wave recorded on a standard seismograph. Similarly, the surface-wave magnitude (Ms) is defined in terms of the logarithm of the maximum amplitude of ground motion for surface waves with a wave period of 20 seconds. As defined, an earthquake magnitude scale has no lower or upper limit. Sensitive seismographs can record earthquakes with magnitudes of negative value and have recorded magnitudes up to about 9.0. (The 1906 San Francisco earthquake, for example, had a Richter magnitude of 8.25.) A scientific weakness is that there is no direct mechanical basis for magnitude as defined above. Rather, it is an
empirical parameter analogous to stellar magnitude assessed by astronomers. In modern practice a more soundly based mechanical measure of earthquake size is used—namely, the seismic moment (M 0 ). Such a parameter is related to the angular leverage of the forces that produce the slip on the causative fault. It can be calculated both from recorded seismic waves and from field measurements of the size of the fault rupture. Consequently, seismic moment provides a more uniform scale of earthquake size based on classical mechanics. This measure allows a more scientific magnitude to be used called moment magnitude (Mw). It is proportional to the logarithm of the seismic moment; values do not differ greatly from Ms values for moderate earthquakes. Given the above definitions, the great Alaska earthquake of 1964, with a Richter magnitude (ML) of 8.3, also had the values Ms = 8.4, M 0 = 820 × 10^27 dyne centimetres, and Mw = 9.2. Earthquake energy Energy in an earthquake passing a particular surface site can be calculated directly from the recordings of seismic ground motion, given, for example, as ground velocity. Such recordings indicate an energy rate of 10^5 watts per square metre (9,300 watts per square foot) near a moderate-size earthquake source. The total power output of a rupturing fault in a shallow earthquake is on the order of 10^14 watts, compared with the 10^5 watts generated in rocket motors. The surface-wave magnitude Ms has also been connected with the surface energy Es of an earthquake by empirical formulas. These give Es = 6.3 × 1011 and 1.4 × 10^25 ergs for earthquakes of Ms = 0 and 8.9, respectively. A unit increase in Ms corresponds to approximately a 32-fold increase in energy. Negative magnitudes Ms correspond to the smallest instrumentally recorded earthquakes, a magnitude of 1.5 to the smallest felt earthquakes, and one of 3.0 to any shock felt at a distance of up to 20 km (12 miles). Earthquakes of magnitude 5.0 cause light damage near the epicentre; those of 6.0 are destructive over a restricted area; and those of 7.5 are at the lower limit of major earthquakes. The total annual energy released in all earthquakes is about 1025 ergs, corresponding to a rate of work between 10 million and 100 million kilowatts. This is approximately one one-thousandth the annual amount of heat escaping from the Earth’s interior. Ninety percent of the total seismic energy comes from earthquakes of magnitude 7.0 and higher—that is, those whose energy is on the order of 10^23 ergs or more. Advertisement Frequency There also are empirical relations for the frequencies of earthquakes of various magnitudes. Suppose N to be the average number of shocks per year for which the magnitude lies in a range about Ms. Thenlog 10 N = a − bMsfits the data well both globally and for particular regions; for example, for shallow earthquakes worldwide, a = 6.7 and b = 0.9 when Ms > 6.0. The
The low seismicity within plates is consistent with the plate tectonic description. Small to large earthquakes do occur in limited regions well within the boundaries of plates; however, such intraplate seismic events can be explained by tectonic mechanisms other than plate boundary motions and their associated phenomena.
