Advance Computer Programming

Introduction to Java

A Simple Java Program

//This program prints Welcome to Java! public class Welcome { public static void main(String[] args) { System.out.println("Welcome to Java!"); } }

Listing 1.

Creating and Editing Using WordPad

To use Word Pad , type w rite Welcom e.java from the DOS prom pt.

Creating, Compiling, and Running Programs

Source Code

Create/Modify Source Code

i.e., javac Welcome.java^ Compile Source Code

Bytecode

i.e., java Welcome^ Run Byteode

Result

If compilation errors

If runtime errors or incorrect result

public class Welcome { public static void main(String[] args) { }^ System.out.println("Welcome^ to Java!"); }

… Method Welcome() 0 aload_0 … Method void main(java.lang.String[]) 0 getstatic #2 … Java!^ 3 ldc #3 <String">^ "Welcome to 5 invokevirtual #4 … 8 return

Saved on the disk

stored on the disk

Source code (developed by the programmer)

Byte code (generated by the compiler for JVM to read and interpret, not for you to understand)

Trace a Program Execution

//This program prints Welcome to Java! public class Welcome { public static void main(String[] args) { System.out.println("Welcome to Java!"); } }

Execute statement

animation

Trace a Program Execution

//This program prints Welcome to Java! public class Welcome { public static void main(String[] args) { System.out.println("Welcome to Java!"); } }

animation

print a message to the console

Compiling and Running Java from

TextPad

Compiling and Running Java from

JBuilder

Anatomy of a Java Program

• Comments
• Package
• Reserved words
• Modifiers
• Statements
• Blocks
• Classes
• Methods
• The main method

Comments

In Java, comments are preceded by two slashes (//) in a line, or enclosed between /* and / in one or multiple lines. When the compiler sees //, it ignores all text after // in the same line. When it sees /, it scans for the next / and ignores any text between / and */.

Reserved Words

Reserved words or keywords are words that have a specific meaning to the compiler and cannot be used for other purposes in the program. For example, when the compiler sees the word class, it understands that the word after class is the name for the class. Other reserved words in Listing 1.1 are public, static, and void. Their use will be introduced later.

Modifiers

Java uses certain reserved words called modifiers that specify the properties of the data, methods, and classes and how they can be used. Examples of modifiers are public and static. Other modifiers are private, final, abstract, and protected. A public datum, method, or class can be accessed by other programs. A private dat or method cannot be accessed by other programs.

Blocks

A pair of braces in a program forms a block that groups

components of a program.

public class Test { public static void main(String[] args) { System.out.println("Welcome to Java!"); } }

Class block Method block

Classes

The class is the essential Java construct. A class is a template or blueprint for objects. To program in Java, you must understand classes and be able to write and use them. For now, though, understand that a program is defined by using one or more classes.
