IEEE TRANSACTIONS ON^ COMPUTERS, VOL.^ C-25, NO.^ 12, DECEMBER^1976
Software Engineering
BARRY W. BOEHM
Abstract-This paper provides a definition of the term "software engineering" and a survey of the current state of the art^ and^ likely future trends in the field. The survey covers the technology avail- able in the various phases of the software life cycle-requirements engineering, design, coding, test, and maintenance-and in^ the overall area of software management and integrated technology- management approaches. It is oriented primarily toward^ discussing the domain of applicability of techniques (where and when they work), rather than how they work in detail. To cover the^ latter,^ an extensive set of 104 references is provided. Index Terms-Computer software, data^ systems, information systems, research and development, software^ development,^ soft- ware engineering, software management.
I. INTRODUCTION r (^) HE annual cost of software in the U.S. is approximately 20 billion dollars. Its rate of growth is considerably greater than that of the economy in^ general.
Compared to the cost of computer hardware, the cost^ of
software is continuing to escalate along the lines^ predicted
in Fig. 1 [1].1 A^ recent SHARE study [2]^ indicates^ further
that software demand over the years 1975-1985^ will^ grow
considerably faster (about 21-23^ percent per^ year)^ than
the growth rate in^ software supply^ at^ current^ estimated growth rates of the software labor force^ and^ its^ productivity
per individual, which produce a^ combined^ growth rate^ of
about 11.5-17 percent per year over the^ years 1975-
In addition, as we continue to^ automate^ many^ of^ the processes which control^ our^ life-style-our^ medical equipment, air traffic control, defense^ system, personal records, bank accounts-we continue to^ trust^ more^ and more in the reliable functioning of^ this proliferating mass
of software. Software engineering is^ the means^ by which
we attempt to produce all of this software in^ a way that^ is
both cost-effective and reliable enough to^ deserve^ our^ trust.
Clearly, it is a discipline which is important to^ establish
well and to perform well. This paper will begin with a definition^ of^ "software^ en- gineering." It will then survey^ the^ current^ state^ of^ the^ art
of the discipline, and^ conclude^ with^ an^ assessment^ of^ likely
future trends.
II. DEFINITIONS Let (^) us begin by defining "software engineering." We will
define software to^ include^ not^ only computer programs,
Manuscript received June 24, 1976; revised August 16, 1976. The author is with the TRW Systems and Energy Group, Redondo Beach, CA 90278. (^1) Another trend has been added to Fig. 1: the growth of software maintenance, which^ will^ be discussed later.
but also the associated documentation required^ to-develop, operate, and^ maintain^ the^ programs.^ By^ defining^ software in this broader sense,^ we^ wish^ to^ emphasize the necessity of (^) considering the generation of timely documentation as
an integral portion of the software development process.
We (^) can then combine this with a definition of "engineer- ing" to produce the following definition. Software Engineering: The^ practical application^ of scientific knowledge^ in^ the^ design^ and^ construction^ of computer programs and the^ associated^ documentation required to develop, operate, and maintain them.
Three main points should be made about this definition.
The first concerns the necessity of considering a broad enough interpretation of the word "design" to cover the extremely important activity^ of^ software requirements engineering. The second point^ is^ that^ the^ definition^ should
cover the entire software^ life cycle,^ thus^ including^ those
activities of^ redesign and^ modification^ often^ termed "software maintenance." (Fig. 2 indicates^ the^ overall^ set
of activities thus encompassed in the definition.) The final
point is that^ our store^ of^ knowledge^ about^ software^ which can really be called "scientific knowledge" is a rather small base upon which to build an engineering discipline. But, of course, that is what makes software engineering such a fascinating challenge at this time. The remainder of this paper will discuss the state of the art of software (^) engineering along the lines of the software life cycle depicted in Fig. 2. Section III contains a discus- sion of software requirements engineering, with some mention of the problem of determining overall system requirements. Section IV discusses both preliminary de- sign and detailed design technology trends. Section V
contains only a brief discussion of programming, as this
topic is also covered in a companion article in this issue [3].
Section VI covers both software testing and the overall life cycle concern^ with^ software^ reliability.^ Section^ VII^ dis- cusses the highly important but largely neglected area of software maintenance. Section VIII surveys software management concepts and techniques, and discusses the
status and trends of integrated technology-management
approaches to^ software^ development. Finally,^ Section^ IX
concludes with an assessment of the current state of the
art of software engineering with respect to the definition
above.
Each section (sometimes after an introduction) contains
a short summary of current practice in the area, followed
by a^ survey of^ current^ frontier^ technology,^ and^ concluding
with a short summary of likely trends in the area. The
survey is oriented primarily toward discussing the domain
of applicability of techniques (where and when they work)
1226
BOEHM: SOFTWARE ENGINEERING
Fig. 1. Hardware-software cost trends.
Fig. 2. Software life cycle.
rather than how they work in detail. An extensive set of references is provided for readers wishing to pursue the latter.
III. SOFTWARE REQUIREMENTS ENGINEERING
A. Critical Nature of Software Requirements Engineering
Software requirements engineering is the discipline for
developing a^ complete, consistent, unambiguous specifi-
cation-which can serve as a basis for common (^) agreement
among all parties concerned-describing what the soft-
ware product will do (but not how it will do it; this is to be
done in the design specification).
The extreme importance of such a specification is (^) only now becoming generally recognized. Its (^) importance derives from two main characteristics: 1) it is easy to delay or avoid
doing thoroughly; and 2) deficiencies in it are very difficult
and expensive to correct later. Fig. 3 shows a summary of current experience at IBM
[4], GTE^ [5], and^ TRW^ on^ the relative^ cost^ of^ correcting software errors as a function of the phase in which they are corrected. Clearly, it pays off to invest effort in finding requirements errors early and correcting them in, say, 1 man-hour rather than waiting to find the error during
operations and having to spend 100 man-hours correcting
it. Besides the cost-to-fix problems, there are other critical problems stemming from a lack of a good requirements
specification. These include [6]: 1) top-down designing is
impossible, for lack of a well-specified "top"; 2) testing is
impossible, because there is nothing to test against; 3) the
user is frozen (^) out, because there is no (^) clear statement of
what is being produced for him; and 4) management is not
in (^) control, as (^) there is no clear statement of what the project
team is producing.
B. (^) Current Practice
Currently, software requirements specifications (when
they exist^ at all) are generally expressed in free-form En-
glish. They abound with ambiguous terms ("suitable,"
1227
BOEHM: SOFTWARE ENGINEERING
standard line printer. Much of the current work on ISDOS/CARA is oriented (^) toward remedying such limita- tions, and extending the^ system to further^ support soft- ware design.
- SREP: The most extensive and powerful system for software requirements specification in evidence today is that being developed under the Software Requirements Engineering Program (SREP) by TRW for the U.S. Army Ballistic Missile (^) Defense Advanced Technology Center
(BMDATC) [11]-[13]. Portions of this effort are derivative
of (^) ISDOS; it uses the (^) ISDOS data management system, and is (^) primarily organized into a (^) language, the require- ments statement (^) language (RSL), and an (^) analyzer, the requirements evaluation and (^) validation system (REVS). SREP contains (^) a number of extensions and innovations which are needed for requirements engineering in real-time software (^) development projects. In (^) order to represent real-time performance (^) requirements, the individual functional requirements can be joined into stimulus-re- sponse networks^ called^ R-Nets.^ In^ order^ to^ focus^ early attention on software (^) testing and (^) reliability, there are
capabilities for^ designating "validation points" within the
R-Nets. For (^) early requirements validation, there are capabilities for^ automatic^ generation of^ functional simu- lators from^ the requirements statements. And, for adap-
tation to changing requirements, there are capabilities for
configuration control, traceability to design, and extensive report generation and consistency checking. Current SREP limitations (^) again mostly reflect delib- erate (^) design decisions centered around the (^) autonomous, highly real-time process-control problem of (^) ballistic missile
defense. Capabilities to represent large file processing and
man-machine interactions are (^) missing. Portability is a problem: although some parts run on several (^) machines, other (^) parts of the (^) system run (^) only on a TI-ASC (^) computer with a (^) very powerful but (^) expensive multicolor interactive graphics terminal. However, the system has been designed with the use of (^) compiler generators and (^) extensibility fea- tures which should allow these limitations to be rem- edied.
- Automatic (^) Programming and Other (^) Approaches: Under the (^) sponsorship of the Defense (^) Advanced Research Projects Agency (DARPA), several^ researchers^ are at-
tempting to^ develop "automatic^ programming" systems
to (^) replace the functions of (^) currently performed by pro- grammers. If successful, could they drive software costs
down to zero? Clearly not, because there would still be the
need to determine what software the system should pro-
duce, i.e., the software requirements. Thus, the methods,
or at least the forms, of capturing software requirements
are of central concern in automatic programming re- search. Two main directions are being taken in this research.
One, exemplified by the work of Balzer at USC-ISI [14],
is to work within a general problem context, relying on only general rules of^ information processing (items must be
defined or received before they are used, an "if' should
have both a "then" and an "else," etc.) to resolve am-
biguities, deficiencies, (^) or inconsistencies in the problem statement. This (^) approach encounters formidable problems in natural language processing and may require (^) further restrictions to make it (^) tractable. The other direction, exemplified by the work of Martin at MIT [15], is to work within a particular problem area, such as inventory control, where there is enough of a gen- eral model of software (^) requirements and acceptable ter- minology to make the problems of resolving (^) ambiguities, deficiencies, and (^) inconsistencies reasonably tractable. This second approach has, of course, been used in the past in various forms of "programming-by-question- naire" and application generators [1], [2]. Perhaps (^) the most widely used are the (^) parameterized application generators developed for use on the IBM System/3. IBM has some more (^) ambitious efforts on requirements specification underway, notably one called the Application Software Engineering Tool [16] and one (^) called the Information Automat [17], but further information is needed to assess their current status and directions. Another avenue involves the formalization and speci- fication of required properties in a software specification (reliability, maintainability, portability, etc.). Some success has been experienced here for small-to-medium (^) systems, using a^ "Requirements-Properties Matrix" to help analysts infer additional requirements implied by such (^) consider- ations (^) [18].
D. Trends
In the area of requirements statement languages, we will see further efforts either to extend the ISDOS-PSL and SREP-RSL capabilities to handle further areas of appli- cation, such as man-machine interactions, or to develop language variants specific to such areas. It is still an open
question as to how general such a language can be and still
retain its utility. Other open questions are those of the nature, "which representation scheme is best for describing requirements in a certain area?" BMDATC is sponsoring some work here in representing general data-processing system requirements for the BMD problem, involving Petri nets, state transition diagrams, and predicate cal-
culus [11], but its outcome is still uncertain.
A good deal more can and will be done to extend the capability of requirements statement analyzers. Some extensions are fairly straightforward consistency checking; others, involving the use of relational operators to deduce derived requirements and the detection (and perhaps
generation) of missing requirements are more difficult,
tending toward the automatic programming work.
Other advances will involve the use of formal require-
ments statements to improve subsequent parts of the
software life cycle. Examples include requirements-de-
sign-code consistency checking (one initial effort is un-
derway), the automatic generation of test cases from re- quirements statements, and, of course, the advances in automatic programming involving the generation of code from (^) requirements.
1229
IEEE TRANSACTIONS ON (^) COMPUTERS, DECEMBER 1976
Progress (^) will not necessarily be evolutionary, though. There is always a good chance of a breakthrough: some key concept which will simplify and formalize large regions of the problem (^) space. Even then, though, there will always remain difficult regions which will require human insight and (^) sensitivity to come up with an acceptable set of soft- ware requirements. Another trend involves the impact of having formal, machine-analyzable requirements (and design) specifi- cations on our (^) overall inventory of software code. Besides improving software reliability, this will make our software
much more portable; users will not be tied so much to a
particular machine configuration. It is interesting to speculate on what impact this will have on hardware ven- dors in the future.
IV. SOFTWARE DESIGN
A. The Requirements/Design Dilemma Ideally, one would like to have a complete, consistent, validated, unambiguous, machine-independent specifi- cation of software requirements before proceeding to software design. However, the requirements are not really validated until it is determined that the resulting system can be built for a reasonable cost-and to do so requires
developing one or more software designs (and any asso-
ciated hardware designs needed). This dilemma is complicated by the huge number of
degrees of freedom available to software/hardware system
designers. In^ the 1950's, as indicated by Table I, the de.-
signer had only a few alternatives to choose from in se- lecting a central processing unit (CPU), a set of peripher- als, a^ programming language, and an ensemble of support software. In^ the 1970's, with rapidly evolving mini- and microcomputers, firmware, modems, smart (^) terminals, data management systems, etc., the designer has an enormous number of alternative design components to sort out
(possibilities) and to seriously choose from (likely choices).
By the 1980's, the number of possible design combinations will be formidable.
The following are some of the implications for the de-
signer. 1) It is easier for him^ to^ do^ an^ outstanding design
job. 2) It is easier for him^ to^ do^ a^ terrible^ design job. 3) He
needs more powerful analysis tools^ to^ help him^ sort^ out^ the
alternatives. 4) He^ has more^ opportunities for^ designing-
to-cost. 5) He^ has^ more^ opportunities to^ design and^ de-
velop tunable^ systems. 6) He^ needs^ a more^ flexible^ re-
quirements-tracking and hardware^ procurement mecha-
nism to support the above flexibility (particularly in gov-
ernment systems). 7) Any rational standardization (e.g.,
in programming languages) will be a big help to him, in that
it reduces the number of alternatives he must consider.
B. Current Practice
Software design is still almost completely a manual
process; There is relatively little effort devoted to design validation and risk analysis before committing to a par-
TABLE I Design Degrees of Freedom for New Data Processing Systems (Rough Estimates)
Likely Choices Possibilities Choices Element (1950's) (1970's) (1970's) CPU 5 200 100 Op-Codes fixed variable (^) variable Peripherals (per function) 1 200 100 Programming language 1 50 5- Operating system 0-1 10 5 Data management system 0 100 30
ticular software design. Most software errors are made during the^ design phase. As^ seen^ in^ Fig. 4, which^ summa- rizes several software error analyses by IBM [4], [19] and TRW (^) [20], [21], the ratio of design to coding errors gener- ally exceeds 60:40. (For the TRW data, an error was called a design error if and only if the resulting fix required a change in the detailed design specification.) Most software design is still done bottom-up, by devel- oping software components before addressing interface and integration issues. There is, however, increasing suc- cessful use of top-down design. There is little organized knowledge of what a software designer does, how he does it, or of what makes a good software designer, although
some initial work along these lines has been done by
Freeman [22].
C. Current Frontier Technology Relatively little is available to help the designer make the overall hardware-software tradeoff analyses and de- cisions to appropriately narrow the large number of design degrees of freedom available to him. At the micro level,
some formalisms such as LOGOS [23] have been helpful,
but at the macro level, not much is available beyond gen- eral system engineering techniques. Some help is provided via (^) improved techniques for (^) simulating information sys- tems, such as the Extendable Computer System Simulator
(ECSS) [24], [25], which make it possible to develop a fairly
thorough functional simulation^ of^ the system for design
analysis in^ a considerably shorter time than it takes to
develop the complete design itself.
- Top-Down (^) Design: Most of (^) the helpful new tech- niques for (^) software design fall into (^) the category of "top- down" (^) approaches, where the (^) "top" is (^) already assumed to
be a firm, fixed requirements specification and hardware
architecture. (^) Often, it is also assumed that the data structure has also been established. (These assumptions
must in many cases be considered potential pitfalls in using
such top-down techniques.)
What the top-down approach does well, though, is to
provide a procedure for organizing and developing the control structure of a program in a way which focuses (^) early attention on the critical issues of integration and interface definition. It begins with a top-level expression of a hier-
archical control structure (often a top level "executive"
routine controlling an "input," a "process," and an "out-
1230
IEEE TRANSACTIONS ON COMPUTERS, DECEMBER (^1976)
level modules in sequence, in a loop, or in an if/else rela- tionship?), the lack of summary information about data, the unwieldiness of the graphics on large systems, and the manual nature of the technique. Some attempts have been made to automate the representation and generation of HIPO's such as Univac's PROVAC System (^) [36].
The structure charts used in structured design [30], [31]
remedy some of these (^) disadvantages, although they lose the advantage of representing the processes connecting the
inputs with the outputs. In doing so, though, they provide
a more compact summary of a module's inputs and outputs which is less unwieldy on large problems. They also provide some extra symbology to remove at least some of the se-
quence/loop/branch ambiguity of the control relation-
ships. Several other similar conventions have been developed
[37]-[39], each with different strong points, but one main
difficulty of^ any such manual system is the difficulty of keeping the design consistent and (^) up-to-date, especially on large problems. Thus, a (^) number of systems have been developed which store design (^) information in (^) machine- readable form. This simplifies updating (and reduces update errors) and facilitates generation of selective design summaries and simple consistency checking. Experience has shown that even a simple set of (^) automated consistency checks can catch dozens of (^) potential problems in a large design specification (^) [21]. Systems of this nature that have been reported include (^) the Newcastle TOPD system (^) [401,
TRW's DACC and DEVISE systems [21], Boeing's DECA
System [41], and Univac's PROVAC (^) [361; several more are under development. Another machine-processable (^) design representation is provided by Caine, Farber, and Gordon's Program Design Language (PDL) System [42]. This system accepts con- structs which have the form of (^) hierarchical structured programs, but instead of the actual code, the designer can write some English text describing what the segment of code will do. (This representation was (^) originally called
"structured pidgin" by Mills [43].) The PDL system again
makes updating much easier; it also provides a (^) number of useful formatted summaries of the design (^) information, although it still lacks some wished-for features to support terminology control and version control. The (^) program-like representation makes it easy for programmers to read and write PDL, albeit less easy for nonprogrammers. Initial results in using the PDL system on projects have been quite favorable.
D. Trends
Once a good deal of design information is in^ machine-
readable form, there is a fair amount of pressure from users
to do more with it: to generate core and time budgets,
software cost estimates, first-cut data base descriptions,
etc. We should continue to see such added (^) capabilities, and
generally a further evolution toward computer-aided-
design (^) systems for software. Besides improvements in
determining and^ representing control structures, we should
see progress in^ the more difficult area of data structuring.
Some initial (^) attempts have been made (^) by Hoare (^) [44] and others to provide a data (^) analog of the basic (^) control struc- tures in structured (^) programming, but with less practical impact to date. Additionally, there will be more integration and traceability between the (^) requirements specification,
the design specification, and the code-again with signif-
icant implications regarding the improved (^) portability of a user's software. The proliferation of minicomputers and (^) microcompu- ters will continue to complicate the designer's job. It is difficult enough to derive or use principles for (^) partitioning software jobs on single machines; additional degrees of freedom and concurrency problems just make things so much harder. Here again, though, we should expect at least some initial guidelines for decomposing information pro- cessing jobs into separate concurrent (^) processes. It is still not clear, however, how much one can formalize the software design process. Surveys of software designers have indicated a wide variation in their design styles and approaches, and in their receptiveness to using formal design procedures. The key to good software design still lies in getting the best out of good people, and in struct- uring the job so that the less-good people can still make a positive contribution.
V. PROGRAMMING
This section will be brief, because much of the material
will be covered in the companion article by Wegner on
"Computer Languages" [3].
A. Current Practice
Many organizations are moving toward using structured
code [28], [43] (hierarchical, block-oriented code with a
limited number (^) of control structures-generally SE- QUENCE, IFTHENELSE, CASE, DOWHILE, and DOUNTIL-
and rules for formatting and limiting module size). A great
deal of terribly unstructured code is still being written,
though, often in assembly language and particularly for the rapidly proliferating minicomputers and microcompu- ters.
B. Current Frontier Technology
Languages are becoming available which support
structured code and additional valuable features such (^) as
data typing and type checking (e.g., Pascal [45]). Exten-
sions such as concurrent Pascal [46] have been developed
to support the programming of concurrent processes. Ex-
tensions to data typing involving more explicit binding of
procedures and their data have been embodied in recent
languages such as ALPHARD [47] and CLU [48]. Me-
tacompiler and compiler writing system technology con-
tinues to improve, although much more slowly in the code
generation area than in the syntax analysis area.
Automated aids include support systems for top-down
structured programming such as the Program Support
Library [49], Process Construction [50], TOPD [40], and
1232
BOEHM: SOFTWARE ENGINEERING
COLUMBUS [51]. Another novel aid is the Code Auditor program [50] for automated standards compliance checking-which guarantees that the standards are more than just words. Good programming practices are now becoming codified into style handbooks, i.e., Kernighan
and Plauger [52] and Ledgard [53].
C. Trends It is difficult to clean up old programming languages or to introduce new ones into widespread practice. Perhaps the (^) strongest hope in (^) this direction is the current De- partment of Defense (DoD) effort to define requirements for its future (^) higher order (^) programming languages [54], which (^) may eventually lead to the development and wide- spread use of^ a cleaner programming language. Another trend will be an (^) increasing capability for (^) automatically generating code^ from design specifications.
VI. SOFTWARE TESTING AND RELIABILITY
A. Current Practice
Surprisingly often, software testing and reliability ac-
tivities are still not considered until the code has been run the first time and found not to work. In general, the high
cost of testing (still 40-50 percent of the development ef-
fort) is^ due^ to^ the^ high cost^ of^ reworking the code^ at^ this
stage (see Fig. 3), and^ to^ the^ wasted^ effort^ resulting^ from
the lack of an advance test plan to efficiently guide testing
activities. In addition, most testing is still a tedious manual process which is error-prone in itself. There are few effective cri- teria used for answering the question, "How much testing is enough?" except the usual "when the budget (or schedule) runs out." However, more and more organiza- tions are now using disciplined test planning and some objective criteria such as "exercise every instruction" or "exercise every branch," often with the aid of automated test monitoring tools and test case planning aids. But other technologies, such as mathematical proof techniques, have
barely begun to penetrate the world of production soft-
ware.
B. Current Frontier Technology
- Software Reliability Models and Phenomenology: Initially, attempts to predict software reliability (the
probability of future satisfactory operation of the software)
were made by applying models derived from hardware
reliability analysis and fitting them to observed software error rates [55]. These models worked at times, but often
were unable to explain actual experienced error phenom-
ena. This was primarily because of fundamental differ-
ences between software phenomenology and the hard-
ware-oriented assumptions on which the models were based. For example, software components do not degrade due to wear or fatigue; no imperfection or variations are introduced in making additional copies of a piece of soft-
ware (except possibly for a class of easy-to-check copying
errors); repair of a software fault generally results in a
different software configuration than previously, unlike most hardware replacement repairs.
Models are now being developed which provide expla-
nations of the previous error histories in terms of appro- priate software phenomenology. They are based on a view of a software program as a mapping from a space of inputs
into a space of outputs [56], of program operation as the
processing of a sequence of points in the input space, dis- tributed according to an operational profile [57], and of
testing as a sampling of points from the input space [56]
(see Fig. 5). This approach encounters severe problems of scale on large programs, but can be used conceptually as a means of appropriately conditioning time-driven reli-
ability models [58]. Still, we are a long way off from having
truly reliable reliability-estimation methods for soft- ware.
- Software Error Data: Additional insights into reli- ability estimation have come from analyzing the increasing data base of software errors. For example, the fact that the distributions of serious software errors are dissimilar from
the distributions of minor errors [59] means that we need
to define "errors" very carefully when using reliability
prediction models. Further, another study [60] found that
the rates of fixing serious errors and of fixing minor errors vary with management direction. ("Close out all problems quickly" generally gets minor simple errors fixed very quickly, as compared to "Get the serious problems fixed first.")
Other insights afforded by software data collection in-
clude better assessments of the relative efflcacy of various
software reliability techniques [4], [19], (^) [601, identification of the requirements and design phases as key leverage points for cost savings by eliminating errors earlier (Figs. 2 and 3), and guidelines for organizing test efforts (for example, one recent analysis indicated that over half the
errors were experienced when the software was handling
data singularities and extreme points [60]). So far, how-
ever, the proliferation of definitions of various terms (error,
design phase, logic error, validation test), still make it ex-
tremely difficult to compare error data from different sources. Some efforts to establish a unified software reli-
ability data base and associated standards, terminology,
and data collection procedures are now under way at USAF Rome Air Development Center, and within the IEEE Technical Committee on Software Engineering.
- Automated Aids: Let us sketch the main steps of testing between the point the code has been written and
the point it is^ pronounced acceptable for use, and describe
for each stop the main types of automated aids which have
been found helpful. More detailed discussion of these aids
can be found in^ the surveys by Reifer [61] and Rama-
moorthy and Ho [62] which in^ turn have references to in-
dividual contributions to the field.
a) Static code analysis: Automated aids here include
the usual compiler diagnostics, plus extensions involving
more detailed data-type checking. Code auditors check for
1233
BOEHM: (^) SOFTWARE ENGINEERING
about one man-month of expert effort was required to prove 100 lines of code [67]. The largest program to be proved correct to date contained about 2000 statements [68]. Again, automation can help out on some of the com- plications. Some automated verification systems exist,
notably those of London et al. [69] and Luckham et al.
[70]. In general, such systems do not work on programs in the more common languages such as Fortran or Cobol.
They work in^ languages such as Pascal [45], which has
(unlike Fortran or^ Cobol) an axiomatic definition [71] al-
lowing, clean expression^ of^ program statements as logical
propositions. An (^) excellent survey of program verification
technology has been given by London [72].
Besides size and language limitations, there are other
factors which limit the utility of program proving tech-
niques. Computations on (^) "real" variables involving trun-
cation and roundoff errors are virtually impossible to an-
alyze with adequate accuracy for most nontrivial programs.
Programs with nonformalizable (^) inputs (e.g., from a (^) sensor where one has just a rough idea of its (^) bias, signal-to-noise ratio, etc.) are impossible to handle. (^) And, of (^) course, pro-
grams can be proved to be consistent with a specification
which is itself incorrect with (^) respect to the (^) system's proper functioning. (^) Finally, there is no (^) guarantee that the (^) proof
is correct or complete; in fact, many published "proofs"
have subsequently been demonstrated to have (^) holes in
them [63].
It has been said and often repeated that "testing can be used to demonstrate the presence of errors but never their
absence" [73]. Unfortunately, if we must define "errors"
to include those incurred by the two limitations above
(errors in specifications and errors in proofs), it must be
admitted that "program proving can be used to demon- strate the presence of errors but never their absence."
- Fault-Tolerance: Programs do not have to be error-free to be reliable. If one could just detect erroneous computations as they occur and compensate (^) for them, one could achieve reliable operation. This is the rationale be- hind schemes for fault-tolerant software. Unfortunately, both (^) detection and compensation are formidable problems. Some (^) progress has been made in the case of software de- tection (^) and compensation for hardware errors; see, for example, the articles by Wulf (^) [741 and Goldberg [75]. For software errors, Randell has formulated a concept of sep- arately-programmed, alternate "recovery blocks" (^) [761. It appears attractive for parts of the error compensation
activity, but it is still too early to tell how well it will handle
the error detection (^) problem, or what the price will be in program slowdown.
C. (^) Trends
As we continue to collect and analyze more and more data on^ how, when, where, and why people make software errors, we will^ get added insights on how to avoid making
such errors, how to organize our validation strategy and
tactics (^) (not only in testing but throughout the software life cycle), how^ to^ develop or evaluate new automated aids, and
how to (^) develop useful methods for (^) predicting software reliability. Some automated (^) aids, particularly for static
code checking, and for some dynamic-type or assertion
checking, will^ be^ integrated into future programming
languages and compilers. We should see some (^) added useful
criteria and associated aids for test completeness, partic-
ularly along the^ lines of exercising "all data elements" in
some (^) appropriate way. Symbolic execution capabilities will probably make their way into automated aids for test (^) case
generation, monitoring, and^ perhaps retesting.
Continuing work into the (^) theory of software testing should (^) provide some refined concepts of (^) test validity, re- liability, and completeness, plus a better theoretical (^) base for supporting hybrid test/proof (^) methods of verifying programs. Program proving techniques and aids will be- come more powerful in the size and range of programs they handle, and hopefully easier to use and (^) harder to misuse. But many of their basic limitations will remain, (^) particu- larly those involving real variables and (^) nonformalizable inputs. Unfortunately, most of these helpful capabilities will be available only to people working in higher order (^) languages. Much of the progress in test technology will be (^) unavailable to the increasing number of people who find (^) themselves spending more and more time testing (^) assembly language software written for minicomputers and (^) microcomputers with poor test support capabilities. (^) Powerful cross-com- piler capabilities on large host machines and micropro- grammed diagnostic emulation (^) capabilities [77] should provide these people some relief after a while, but a great deal of software testing will regress back to earlier gener- ation "dark ages."
VII. SOFTWARE MAINTENANCE
A. Scope of Software Maintenance Software maintenance is an extremely important (^) but highly neglected activity. Its importance is clear from Fig. 1: (^) about 40 percent of the overall hardware-software dollar is going into software maintenance today, and this number is (^) likely to grow to about 60 percent by 1985. It will con- tinue to grow for a long time, as we continue to add to our inventory of code via development at a faster rate than we make (^) code obsolete. The (^) figures above are only very approximate, because our (^) only data (^) so far are based on highly approximate def- initions. It is hard to (^) come up with an unexceptional def- inition of software (^) maintenance. Here, we define it as "the process of modifying existing (^) operational software while leaving its primary functions intact." It is useful to divide software (^) maintenance into two categories: software update, which results in (^) a changed functional specification for the software, and (^) software repair, which leaves the functional (^) specification intact. A (^) good discussion of soft- ware repair is (^) given in the (^) paper by Swanson [78], who
divides it into the subcategories of corrective maintenance
(of processing, performance, or (^) implementation failures),
1235
IEEE TRANSACTIONS (^) ON COMPUTERS, DECEMBER 1976
MINIMUM-VARIANCE UNBIASED ESTIMATOR. (^) * .* SPACE
- PICK N {SAY, 10001 RANDOM, REPRESENTATIVE INPUTS
- (^) PROCESS THE 1000 INPUTS, OBTAIN M SAY, 3) FAILURES
- THEN R PRO NO FAILURE NEXT RUNI (^) 'N M 0.
OPERATIONAL ESTIMATION PROBLEMS
- SIZE OF INPUT SPACE PROGRAM
- ACCOUNTING FOR FIXES
- ENSURING RANDOM INPUTS
- (^) ENSURING REPRESENTATIVE INPUTS OUTPUT SPACE Fig. 5. Input space sampling provides a basis for software reliability measurement.
adaptive maintenance (to changes in the (^) processing or data environment), and perfective maintenance (for enhancing performance or maintainability). For either update or repair, three main functions are-
involved in software maintenance [79].
Understanding the existing software: This implies the need for good documentation, good traceability between requirements and code, and well-structured and well- formatted code. Modifying the existing software: This implies the need
for software, hardware, and data structures which are easy
to expand and which minimize side effects of (^) changes, plus easy-to-update documentation. Revalidating the modified software: This implies the need for software structures which facilitate selective re-
test, and aids for making retest more thorough and effi-
cient. Following a short discussion of current practice in
software maintenance, these three functions will be used
below as a framework for discussing current frontier technology in software maintenance.
B. Current Practice As indicated in Fig. 6, probably about 70 percent of the overall cost of software is spent in software maintenance.
A recent paper by Elshoff [80] indicates that the figure for
General Motors is about 75 percent, and that GM is fairly
typical of large business software activities. Daly [5] indi-
cates that about 60 percent of GTE's 10-year life cycle costs for real-time software are devoted to maintenance. On two Air Force command and control software systems, the maintenance portions of the 10-year life cycle costs were
about 67 and 72 percent. Often, maintenance is not done
very efficiently. On one aircraft computer, software de-
velopment costs were roughly $75/instruction, while
maintenance costs ran as high as $4000/instruction [81].
Despite its size, software maintenance is a highly ne- glected activity. In general, less-qualified personnel are assigned to maintenance tasks. There are few good general principles and few studies of the process, most of them
inconclusive.
Further, data processing practices, are usually optimized
MAINTENANCE DEDELOPMENT GEN. TEL. + ELECT.
USAF C+C NO. 1
USAF C+C NO. 2
GENERAL (^) MOTORS
(^0 20 40 60) s PERCENT OF 10-YEAR LIFE-CYCLE COSTS
100
Fig. 6. Software life-cycle cost breakdown.
around other criteria than maintenance efficiency. Opti-
mizing around development cost and schedule criteria
generally leads to compromises in documentation, testing,
and structuring. Optimizing around hardware efficiency
criteria generally leads to use of assembly language and
skimping on hardware, both of which correlate strongly
with (^) increased software maintenance costs [1].
C. Current Frontier (^) Technology
1) Understanding the Existing Software: Aids here
have largely been discussed in^ previous sections: structured programming, automatic formatting, and code auditors
for standards compliance checking to enhance code read-
ability; machine-readable requirements and^ design lan-
guages with^ traceability support to^ and^ from^ the^ code.
Several systems exist for automatically updating docu-
mentation by excerpting information from the revised code
and comment cards.
- Modifying the^ Existing Software: Some^ of^ Parnas' modularization guidelines [32] and the^ data abstractions
of the CLU [48] and ALPHARD [47] languages make it
easier to minimize the side effects of changes. There may
be a maintenance price, however. In the past, some systems
with highly coupled programs and associated data struc-
1236
IEEE TRANSACTIONS ON COMPUPERS, DECEMBER 1976
the "software physics" lines being investigated by Halstead [97] and others; some interesting initial results have been obtained here, but their utility for practical cost estimation remains to be demonstrated. A good review of the software cost estimation area is contained in [98].
- Management-Technology Decoupling: Another difficulty of the above books is the degree to which they are decoupled from software technology. Except for the Ho- rowitz and Aron books, they say relatively little about the use of such advanced-technology aids as formal, ma- chine-readable requirements, top-down design approaches, structured programming, and automated aids-to software testing. Unfortunately, the management-technology decoupling works the other way, also. In the design area, for example, most treatments of top-down software design are pre- sented as logical exercises independent of user or economic considerations. Most automated aids to software design provide little support for such management needs as configuration management, traceability to code or re- quirements, and resource estimation and control. Clearly, there needs to be a closer coupling between technology and management than this. Some current efforts to provide integrated management-technology approaches are pre- sented next.
- Integrated Approaches: Several major integrated systems for software development are currently in opera- tion or under development. In general, their objectives are similar: to achieve a significant boost in software devel- opment efficiency and quality through the synergism of a unified approach. Examples are the utility of having a complementary development approach (top-down, hier-
archical) and set of programming standards (hierarchical,
structured code); the ability to perform a software update and at the same time perform a set of timely, consistent project status updates (new version number of module, closure of software problem report, updated status logs); or simply the improvement in software system integration achieved when all participants are using the same devel- opment concept, ground rules, and support software. The most familiar of the integrated approaches is the IBM "top-down structured programming with chief pro- grammer teams" concept. A good short description of the
concept is given by Baker [49]; an extensive treatment is
available in a 15-volume series of reports done by IBM for
the U.S. Army and Air Force [99]. The top-down struc-
tured approach was discussed earlier. The Chief Pro- grammer Team centers around an individual (the Chief) who is (^) responsible for designing, coding, and integrating the (^) top-level control structure as well as the key compo-
nents of the team's product; for managing and motivating.
the team personnel and personally reading and reviewing
all their code; and also for performing traditional man-
agement and customer interface functions. The Chief is assisted by a Backup (^) programmer who is (^) prepared at
anytime to take the Chiefs place, a^ Librarian who handles
job submission, configuration control, and project status
accounting, and additional programmers and specialists
as needed.
In general, the overall ensemble of techniques has been
quite successful, but the Chief Programmer concept has had mixed results [99]. It is difficult to find individuals with enough energy and talent to perform all the above
functions. If you find one, the project will do quite well;
otherwise, you have concentrated most of the project risk in a single individual, without a good way of finding out whether or not he is in trouble. The Librarian and Pro- gramming Support Library concept have generally been quite useful, although to date the concept has been ori- ented toward a batch-processing development environ- ment. Another "structured" integrated approach has been developed and used at SofTech [38]. It is oriented (^) largely around a hierarchical-decomposition design approach, guided by formalized sets of principles (modularity, ab- straction, localization, hiding, uniformity, completeness, confirmability), processes (purpose, concept, mechanism, notation, usage), and goals (modularity, efficiency, reli- ability, understandability). Thus, it accommodates some economic considerations, although it says little about any other management considerations. It appears to work well for SofTech, but in general has not been widely assimilated elsewhere. A more management-intensive integrated approach is the TRW software development methodology exemplified in the paper by Williams [50] and the TRW Software De- velopment and Configuration Management Manual [100], which has been used as the basis for several recent gov- ernment in-house software manuals. This approach fea- tures a coordinated set of high-level and detailed man-
agement objectives, associated automated aids-standards
compliance checkers, test thoroughness checkers, process
construction aids, reporting systems for cost, schedule, core
and time budgets, problem identification and closure, etc.-and unified documentation and management devices such as the Unit Development Folder. Portions of the approach are still largely manual, although additional
automation is underway, e.g., via the Requirements
Statement Language [13].
The SDC Software Factory [101] is a highly ambitious
attempt to automate and integrate software development
technology. It consists of an interface control component,
the Factory Access and Control Executive (FACE), which
provides users access to various tools and data bases: a
project planning and monitoring system, a software de-
velopment data base and module management system, a
top-down development support system, a set of test tools,
etc. As the system is still undergoing development and
preliminary evaluation, it is too early to tell what degree
of success it will have.
Another factory-type approach is the System Design
Laboratory (SDL) under^ development at the Naval Elec-
tronics (^) Laboratory Center (^) [102]. It (^) currently consists primarily of a framework within which a wide range of aids
to software development can be incorporated. The initial
installment contains text editors, compilers, assemblers,
and microprogrammed emulators. Later additions are
envisioned to include design, development, and test aids,
and such management aids as progress reporting, cost re-
porting, and^ user^ profile analysis.
1238
BOEHM: SOFTWARE ENGINEERING
SDL itself is only a part of a more ambitious integrated approach, ARPA's National Software Works (NSW) [102]. The initial objective here has been to develop a "Works Manager" which will allow a software developer at a ter- minal to access a wide variety of software development tools on various computers available over the ARPANET. Thus, a developer might log into the NSW, obtain his source code from one computer, text-edit it on another, and perhaps continue to hand the program to^ additional computers for test instrumentation, compiling, executing, and postprocessing of output data. Currently, an initial version of the Works Manager is operational, along with a few tools, but it is too early to assess the likely outcome and payoffs of the project.
C. Trends In the area of management techniques, we are probably entering a consolidation period, particularly as the U.S. DoD proceeds to implement the upgrades in its standards and procedures called for in^ the recent DoD Directive
5000.29 [104]. The resulting government-industry efforts
should produce a set of software management guidelines
which are more consistent and up-to-date with today's
technology than the ones currently in use. It is likely that they will also be more comprehensible and less encum- bered with DoD jargon; this will make them more useful to the software field in general. Efforts to develop integrated, semiautomated systems for software development will continue at a healthy clip. They will run into a number of challenges which will probably take a few years to work out. Some are technical, such as the lack of a good technological base for data
structuring aids, and the formidable problem of integrating
complex software support tools. Some are economic and managerial, such as the problems of pricing services, pro- viding tool warranties, and controlling the evolution of the system. Others are environmental, such as the proliferation of minicomputers and microcomputers, which will strain
the capability of any support system to keep up-to-date.
Even if the various integrated systems do not achieve all their goals, there will be a number of major benefits from the effort. One is of course that a larger number of support tools will become available to a larger number of people (another major channel of tools will still continue
to expand, though: the independent software products
marketplace). More importantly, those systems which
achieve a degree of conceptual integration (not just a
free-form tool box) will eliminate a great deal of the se- mantic confusion which currently slows down our group
efforts throughout the software life cycle. Where we have
learned how to talk to each other about our software problems, we tend to do pretty well.
IX. CONCLUSIONS Let us^ now assess the current state of the art of tools and
techniques which^ are^ being used to solve software devel-
opment problems, in^ terms^ of^ our^ original definition^ of
software engineering: the practical application of scientific
knowledge in^ the^ design and^ construction of software.
TABLE II Applicability of Existing Scientific Principles
Software Hardware Dimension Engineering Engineering Scope Across Some principles for com- Many principles ap- Life Cycle ponent construction plicable across and detailed design, vir- life cycle, e.g., tually none for system communication design and integration, theory, control e.g., algorithms, auto- theory. mata theory. Scope Across Some (^) principles for "sys- Many principles ap- Application tems" software, virtu- plicable across ally none^ for^ applica- entire^ application tions software, e.g., system, e.g., con- discrete mathematical trol theory appli- structures. cation. Engineering Very few principles Many principles ap- Economics which apply to system ply well to system economics, e.g., algo- economics, e.g., rithms. strength of mate- rials, optimization, and control the- ory. Required Very few^ principles for-^ Many principles Training mulated for^ consump- formulated for tion by technicians, consumption by e.g., structured code, technicians, e.g., basic math (^) packages. handbooks for structural design, stress testing, maintainability.
Table II presents a (^) summary assessment of the extent to which current software engineering techniques are based
on solid scientific principles (versus empirical heuristics).
The summary assessment covers four dimensions: the extent to which existing scientific principles apply across the entire software life cycle, across the entire range of software applications, across the range of engineering-
economic analyses required for software development, and
across the range of personnel available to perform software development.
For perspective, a similar summary assessment is pre-
sented in Table II for hardware engineering. It is clear from
Table II that software engineering is in a very primitive state as compared to hardware engineering, with respect to its range of scientific foundations. Those scientific principles available to support software engineering ad-
dress problems in an area we shall call Area 1: detailed
design and coding of systems software by experts in a relatively economics-independent context. Unfortunately, the most pressing software development problems are in an area we shall call Area 2: requirements analysis design, test, and maintenance of applications software by tech- nicians3 in an economics-driven context. And in Area 2, our scientific foundations are so slight that one can seri-
(^3) For example, a recent survey of 14 installations in one large organi- zation produced the following profile of its "average coder": 2 years col- lege-level education, 2 years software experience, familiarity with 2 programming languages and 2 applications, and generally introverted, sloppy, inflexible, "in over his head," and undermanaged. Given the continuing increase in demand for software personnel, one should not assume that this typical profile will improve much. This has strong im- plications for effective software engineering technology which, like ef- fective software, must be well-matched to the people who must use it.
1239
BOEHM: SOFTWARE ENGINEERING
Eng., pp. 358-363, Dec. 1975. [52] B. W. (^) Kernighan and^ P. J.^ Plauger, The^ Elements^ of Programming Style. New York: McGraw-Hill, 1974. 153] H. F. Ledgard, Programming^ Proverbs.^ Rochelle^ Park, NJ: Hayden, 1975 [54] W. A. Whitaker etal., "Department of Defense requirements for high order computer programming languages: 'Tinman,' " Defense Advanced Research Projects Agency, Apr. 1976. [55] Proc. 1973 IEEE Symp. Comput. Software Reliability, Apr.-May
[56] E. C. Nelson, "A statistical basis for software reliability assess- ment," TRW Systems, Redondo Beach, CA, rep. TRW-SS-73-03, Mar. 1973. [57] J. R. Brown and M. Lipow, "Testing for software reliability," in Proc. 1975 Int. Conf. Reliable Software, Apr. 1975, pp. 518-527. [58] J. D. Musa, "Theory of software reliability and its application," IEEE Trans. Software Eng., pp. 312-327, Sept. 1975. [59] R. J. Rubey, J. A. Dana, and P. W. Biche, "Quantitative Aspects
of software validation," IEEE Trans. Software Eng., pp. 150-155,
June 1975. [60] T. A. Thayer, M. Lipow, and E. C. Nelson, "Software reliability study," TRW Systems, Redondo Beach, CA, rep. to RADC, Con- tract F30602-74-C-0036, Mar. 1976. [61] D. J. Reifer, "Automated aids for reliable software," in Proc. 1975 Int. Conf. Reliable Software, Apr. 1975, pp. 131-142. [62] C. V. Ramamoorthy and S. B. F. Ho, "Testing large software with automated software evaluation systems," IEEE Trans. Software Eng., pp. 46-58, Mar. 1975. [63] J. B. Goodenough and S. L. Gerhart, "Toward a theory of test data selection," IEEE Trans. Software Eng., pp. 156-173, June 1975. [64] P. Wegner, "Report on the 1975 International Conference on Re- liable Software," in Findings and Recommendations of the Joint Logistics Commanders' Software Reliability Work Group, Vol. II, Nov. 1975, pp. 45-88.
[65] J. C. King, "A new approach to program testing," in Proc. 1975 Int.
Conf. Reliable Software, Apr. 1975, pp. 228-233. [66] R. S. Boyer, B. Elspas, and K. N. Levitt,^ "Select-A^ formal system for testing and debugging programs," in Proc. 1975Int. Conf. Re- liable Software, Apr. 1975, pp. 234-245. [67] J. Goldberg, Ed., Proc. Symp. High Cost of Software, Stanford Research Institute, Stanford, CA, Sept. 1973, p. 63. [68] L. C. Ragland, "A verified program verifier," Ph.D. dissertation, Univ. of Texas, Austin, 1973. [69] D. I. Good, R. L. London, and W. W. Bledsoe, "An interactive program verification system," IEEE Trans. Software Eng., pp. 59-67, Mar. 1975. [70] F. W. von Henke and D. C. Luckham, "A methodology for verifying
programs," in Proc. 1975Int. Conf. Reliable Software, pp. 156-164,
Apr. 1975. [71] C. A. R. Hoare and N. Wirth, "An axiomatic definition of the programming language PASCAL," Acta Informatica, vol. 2, pp. 335-355, 1973. [72] R. L. London, "A view of program verification," in Proc. 1975Int. Conf. Reliable Software, Apr. 1975, pp. 534-545. [73] E. W. Dijkstra, "Notes on structured programming," in Structured Programming, 0. J.^ Dahl,^ E. W. Dijkstra, and C. A. R. Hoare.^ New York: Academic, 1972. [74] W. A. Wulf, "Reliable hardware-software architectures," IEEE Trans. Software Eng., pp. 233-240, June 1975. [75] J.^ Goldberg,^ "New problems in fault-tolerant computing," in Proc. 1975 Int. Symp. Fault-Tolerant Computing, Paris, France, pp. 29-36, June 1975. [76] B. Randell, "System structure for software fault-tolerance," IEEE Trans. Software Eng., pp. 220-232, June 1975. [77] R. K. McClean and B. Press, "Improved techniques for reliable software using microprogrammed diagnostic emulation," in Proc. IFAC Cong., Vol. IV, Aug. 1975. [78] E. B. Swanson, "The dimensions of maintenance," in Proc. IEEE/ACM 2nd Int. Conf. Software Eng., Oct. 1976. [79] B. W. Boehm, J. R. Brown, and M. Lipow, "Quantitative evaluation of software quality," in^ Proc.^ IEEE/ACM^ 2nd^ Int.^ Conf.^ Software Eng., Oct. 1976. [80] J. L.^ Elshoff,^ "An analysis of some commercial PL/I programs," IEEE Trans. Software Eng., pp. 113-120, June 1976. [81] W. L. Trainor, "Software: From Satan to saviour," in^ Proc;, NAECON, May 1973. [82] E. H. Sibley, Ed., ACM Comput. Surveys (Special Issue on Data
Base Management Systems), Mar. 1976.
[83] Defense Management J.^ (Special Issue on^ Software^ Manage- ment), vol.II,^ Oct.^ 1975. [84] L. A.^ Belady and M.^ M.^ Lehman, "The evolution^ dynamics^ of large
programs," IBM Research,^ Sept.^ 1975.
[85] F. P.^ Brooks, The^ Mythical Man-Month.^ Reading,^ MA: Addi-
son-Wesley, 1975. [86] E.^ Horowitz,^ Ed., Practical^ Strategies^ for^ Developing^ Large-Scale Software. Reading, MA:^ Addison-Wesley,^ 1975. [87] G. F.^ Weinwurm, Ed., On the^ Management^ of^ Computer^ Pro-
gramming. New York: Auerbach,^ 1970.
[88] P. Naur and B.^ Randell, Eds., Software Engineering,^ NATO, Jan.
[89] P. J.^ Metzger, Managing a^ Programming^ Project.^ Englewood Cliffs, NJ:^ Prentice-Hall,^ 1973. [90] J.^ C. Shaw^ and W.^ Atkins, Managing^ Computer^ System^ Projects. New York: McGraw-Hill, 1970. [91] G. F.^ Hice, W.^ S.^ Turner, and^ L.^ F. Cashwell,^ System^ Development
Methodology. New York: American^ Elsevier,^1974
[92] W. J.^ Ridge and L. E.^ Johnson, Effective^ Management^ of^ Com-
puter Software. Homewood,^ IL: Dow Jones-Irwin,^ 1973.
[93] T. R.^ Gildersleeve, Data^ Processing^ Project^ Management.^ New York: (^) Van Nostrand Reinhold, 1974. [94] G.^ F.^ Weinberg, The^ Psychology of^ Computer^ Programming.^ New York: Van (^) Nostrand Reinhold, 1971.
[95] J. D.^ Aron,^ The^ Program Development^ Process:^ The^ Individual
Programmer. Reading,^ MA:^ Addison-Wesley,^ 1974.
[96] R. W.^ Wolverton,^ "The cost of^ developing^ large-scale^ software,"
IEEE Trans. Comput., 1974. [97] M. H.^ Halstead,^ "Toward^ a^ theoretical^ basis for^ estimating^ pro- gramming effort," in Proc. Ass.^ Comput.^ Mach.^ Conf.,^ Oct.^ 1975, pp. 222-224. [98] Summary Notes, Government/Industry^ Software^ Sizing^ and Costing Workshop, USAF Electron.^ Syst.^ Div.,^ Oct.^ 1974. [99] B. S.^ Barry and J. J.^ Naughton, "Chief^ programmer^ team^ opera-
tions description," U. S. Air Force, rep. RADC-TR-74-300, Vol.
X (^) (of 15-volume series), pp. 1-2-1-3. [100] Software^ Development and^ Configuration^ Management^ Manual,
TRW Systems, Redondo Beach, CA, rep. TRW-SS-73-07, Dec.
[101] H. Bratman and T.^ Court,^ "The^ software factory,"^ Computer,^ pp. 28-37, May 1975. [102] "Systems^ design laboratory:^ Preliminary^ design^ report,"^ Naval Electronics Lab. (^) Center, Preliminary Working Paper, TN-3145, Mar. 1976. [103] W. E. Carlson^ and S.^ D.^ Crocker,^ "The^ impact^ of^ networks^ on^ the'
software marketplace," in Proc. EASCON, Oct. 1974.
[104] "Management of^ computer resources^ in^ major^ defense^ systems," Department of^ Defense, Directive^ 6000.29,Apr.^ 1976.
Barry W. Boehm received^ the B.A.^ degree^ in mathematics from Harvard University, Cam- bridge, MA, in^ 1957,^ and^ the^ M.A. and Ph.D.
degrees from the^ University^ of California,^ Los
Angeles, in 1961^ and^ 1964,^ respectively. He entered the (^) computing field as a Pro-
grammer in^ 1955 and^ has variously^ served^ as a
Numerical Analyst, System Analyst,^ Informa- tion System Development Project Leader, Manager of groups performing such tasks, Head of the Information Sciences Department at the Rand (^) Corporation, and as Director of the 1971 Air Force CCIP-
study. He is^ currently^ Director of^ Software Research^ and^ Technology
within the TRW Systems and Energy Group, Redondo Beach, CA. He
is the author of papers on a number of computing subjects, most recently
in the area of software (^) requirements analysis and design technology. He serves on several (^) governmental advisory committees, and currently^ is Chairman of the NASA Research and Technology Advisory Committee
on Guidance, Control, and.Information Systems.
Dr. Boehm is a member of the IEEE Computer Society, in^ which^ he currently serves on the Editorial Board of the^ IEEE TRANSACTIONS^ ON SOFTWARE ENGINEERING^ and on the^ Technical^ Committee^ on^ Software Engineering.
1241
