Classical Waterfall Model
Classical waterfall model divides
life cycle into phases:
feasibility study,
requirements analysis and
specification,
design,
coding and unit testing,
integration and system testing,
maintenance.
Prepare for your exams
Study with the several resources on Docsity
Earn points to download
Earn points by helping other students or get them with a premium plan
Guidelines and tips
Prepare for your exams
Study with the several resources on Docsity
Earn points to download
Earn points by helping other students or get them with a premium plan
Software engineering lec 2., Cheat Sheet of Software Engineering
This is first lecture of software engineering course .you will be able to understand each concept very clearly.
Typology: Cheat Sheet
2020/2021
1 / 57
This page cannot be seen from the preview
Don't miss anything!
Related documents
Partial preview of the text
Download Software engineering lec 2. and more Cheat Sheet Software Engineering in PDF only on Docsity!
Classical Waterfall Model
Classical waterfall model divides life cycle into phases: feasibility study, requirements analysis and specification, design, coding and unit testing, integration and system testing, maintenance.
Classical Waterfall Model
Feasibility Study Req. Analysis Design Coding Testing Maintenance
Classical Waterfall Model
(CONT.) Most organizations usually define: entry and exit criteria for every phase. They also prescribe specific methodologies for: specification, design, testing, project management, etc.
Feasibility Study
Main aim of feasibility study:determine whether developing the product financially worthwhile technically feasible. First roughly understand what the customer wants: different data which would be input to the system, processing needed on these data, output data to be produced by the system, various constraints on the behavior of the system.
Activities during Feasibility
Study
Perform a cost/benefit analysis: to determine which solution is the best. you may determine that none of the solutions is feasible due to: high cost, resource constraints, technical reasons.
Requirements Analysis and
