Chapter 1

Software Engineering Principles

  • Lecture

Waterfall Model

Spiral Model

  • A logical sequence of discrete steps that describes a complete solution to a given problem computable in a finite amount of time

An Algorithm Is...

  • Hardware
    • the computers and their peripheral devices
  • Software
    • operating systems, editors, compilers, interpreters, debugging systems, test-data generators, and so on
  • Ideaware
    • shared body of knowledge

Programmer ToolBoxes

  • Tells what the program must do, but not how it does it
  • Is written documentation about the program

Detailed Program Specification

  • A model of a complex system that includes only the details essential to the perspective of the viewer of the system
  • Programs are abstractions

Abstraction

  • The practice of hiding the details of a module with the goal of controlling access to the details from the rest of the system
  • A programmer can concentrate on one module at a time
  • Each module should have a single purpose or identity

Information Hiding

  • A problem is approached in stages
    • Similar steps are followed during each stage, with the only difference being the level of detail involved
  • Some variations:
    • Top-down
    • Bottom-up
    • Functional decomposition
    • Round-trip gestalt design

Stepwise Refinement

Visual Aids – CRC Cards

  • “Read the specification of the software you want to build.
  • Underline the verbs if you are after procedural code,
  • the nouns if you aim for an object-oriented program.”

Grady Booch, “What is and isn’t Object Oriented Design,” 1989.

Procedural vs. Object-Oriented Code

Functional Design Modules

Find Weighted Average

Print Weighted Average

Main

Print Data

Print Heading

Prepare File for Get Data

Reading

  • A technique for developing a program in which the solution is expressed in terms of objects - self- contained entities composed of data and operations on that data

Object-Oriented Design

Private data

<< setf

.. .

Private data

get .. . ignore

cin cout
