CMSC 132:
Object-Oriented Programming II
Software Process Models
Department of Computer Science
University of Maryland, College Park
Overview
Software process models
Waterfall Iterative
Choosing a software process model
Level of understanding Cost of change
Waterfall Model
Approach
Perform steps in order Begin new step only when previous step is complete Result of each step flow into next step
Waterfall Model
Advantages
Simple Predictable results Software follows specifications Reasonable for small projects
Problems
In real life May need to return to previous step Steps may be more integrated Steps may occur at same time Unworkable for large projects
Iterative Software Development
Goals
Emphasize adaptability instead of predictability Respond to changes in customer requirements
Examples
Unified model Agile software development Extreme programming (XP)
Unified Model
Development divided into phases (iterations)
- Inception
- Elaboration
- Construction
- Transition
During each phase
Multiple iterations of software development Development treated as mini-waterfalls Emphasis gradually shifts from specification to testing
Agile Software Development
Agile approach
Based on iterative development Short iterations (timeboxes) lasting 1- 4 weeks Working software as principal measure of progress Produced at end of each iteration Adds a more people-centric viewpoint Face-to-face communication preferred Co- locate programmers, testers, “customers” Relies on adapting to feedback rather than planning as the primary control mechanism Less specification & documentation
Extreme Programming (XP)
Prominent example of Agile methodology
Iterative, adaptive software development
Describes set of day-to-day practices
Followed by managers & programmers Intended to encourage a set of values
Appropriate for environments with
Small teams Rapidly-changing requirements
Extreme Programming Practices
Pair programming
Pairs of programmers combine software development efforts at one computer Especially useful for novice programmers
Test-driven development
Tests are designed first, before writing software
Continuous integration
Tests performed throughout development process
On-site customer
Customer available at all times to answer questions
Formal Methods
Mathematically-based techniques for
Specification, development, and verification Software and hardware systems
Intended for high-integrity systems
Safety Security
Levels
0 – Informal implementation of formal specifications 1 – Formal code development & verification 2 – Theorem prover to ensure correctness
Do You Understand The Problem?
In many cases, the things we want software to
do are not well understood
Examples Provide a web interface for student applications Allow users to view and manipulate photographs Build a better search engine
Hard to understand constraints / interactions
May have to build prototype
To understand how users can effectively use it
What Is The Cost Of Change?
Possible situation
Most coding already complete Realize need to change something In the design Or even the requirements
How expensive is that?
If hugely expensive Better get requirements & design right Before completing too much code
Sometimes, Change Is Still Expensive
Expensive to change software that
Is key nexus in a large system Affects many lines of code Interacts with co-designed hardware May need to change hardware design Interacts with software being developed externally Can’t easily change API once published
How Many People Interact With Its Design?
People interacting with software design
Part of the cost of change Need to alert / consult people on design change Design changes that interact with a lot of people Expensive and need to be minimized Try to get design choices right early and documented
