Improving Software Quality

with Static Analysis

William Pugh

Professor, Univ. of Maryland

http://www.cs.umd.edu/~pugh

4

Static Analysis

• Analyzes your program without executing it
• Doesn’t depend on having good test cases
  • or even any test cases
• Generally, doesn’t know what your software is supposed to do
  • Looks for violations of reasonable programming
    • Shouldn’t throw NPE
    • Shouldn’t allow SQL injection
• Not a replacement for testing
  • Very good at finding problems on untested paths
  • But many defects can’t be found with static analysis

Can You Find The Bug?

if (listeners == null) listeners.remove(listener);

• JDK1.6.0, b105, sun.awt.x11.XMSelection
  • lines 243-

Why Do Bugs Occur?

• Nobody is perfect
• Common types of errors:
  • Misunderstood language features, API methods
  • Typos (using wrong boolean operator, forgetting parentheses or brackets, etc.)
  • Misunderstood class or method invariants
• Everyone makes syntax errors, but the compiler catches them
  • What about bugs one step removed from a syntax error?

Bug Patterns

• Some big, broad and common patterns
  • Dereferencing a null pointer
  • An impossible checked cast
  • Methods whose return value should not be ignored
• Lots of small, specific bug patterns, that together find lots of bugs
  • Every Programming Puzzler
  • Every chapter in^ Effective Java
  • Many postings to http://thedailywtf.com/

Analysis Techniques

• Local pattern matching
  • If you invoke^ String.toLowerCase() , don’t ignore the return value
• Intraprocedural dataflow analysis
  • Null pointer, type cast errors
• Interprocedural method summaries
  • This method always dereferences its parameter
• Context sensitive interprocedural analysis
  • Interprocedural flow of untrusted data
    • SQL injection, cross site scripting Whatever you need to find the bugs

Double Check Against

JDK1.6.0-b

• Found 5 infinite recursive loops
• Including one written by Joshua Bloch

public String foundType() {

return this.foundType();

• Smart people make dumb mistakes
  • 27 across all versions of JDK, 40+ in Google’s Java code
• Embrace and fix your dumb mistakes

Finding Null Pointer Bugs

with FindBugs

FindBugs looks for a statement or branch that, if executed, guarantees a null pointer exception

Either a null pointer exception could be thrown, or the program contains a statement/branch that can’t be executed

Could look for exceptions that only occur on a path

e.g., if the condition on line 29 is true and the condition on line 38 is false, then a NPE will be thrown

but would need to worry about whether that path is feasible

Examples of null pointer bugs //com.sun.corba.se.impl.naming.cosnaming.NamingContextImpl if (name != null || name.length > 0) //com.sun.xml.internal.ws.wsdl.parser.RuntimeWSDLParser if (part == null | part.equals("")) // sun.awt.x11.ScrollPanePeer if (g != null) paintScrollBars(g,colors); g.dispose(); simple ones

Redundant Check For Null

Checking a value to see if it is null

When it can't possibly be null // java.awt.image.LoopupOp, lines 236- public final WritableRaster filter( Raster src, WritableRaster dst) { int dstLength = dst.getNumBands(); // Create a new destination Raster, // if needed if (dst == null) dst = createCompatibleDestRaster(src); Also known as a reverse null dereference error

Bad Method Invocation

• Methods whose return value shouldn't be ignored
  • Strings are immutable, so functions like^ trim() and toLowerCase() return new String
• Dumb/useless methods
  • Invoking^ toString^ or equals on an array
• Lots of specific rules about particular API methods
  • Hard to memorize, easy to get wrong

Examples of bad method

calls

// com.sun.rowset.CachedRowSetImpl if (type == Types.DECIMAL || type == Types.NUMERIC) ((java.math.BigDecimal)x).setScale(scale); // com.sun.xml.internal.txw2.output.XMLWriter try { ... } catch (IOException e) { new SAXException("Server side Exception:" + e); }

Lots of Little Bug Patterns

• checking if^ d ==^ Double.NaN
• Bit shifting an^ int^ by a value greater than 31

bits

• Every Puzzler this year
  • more than half for most years

When Bad Code Isn't A Bug

• Static analysis tools will sometimes find ugly,

nasty code

• that can't cause your application to misbehave
• Cleaning this up is a good thing
• makes the code easier to understand and

maintain

• But for ugly code already in production
  • sometimes you just don't want to touch it
• We've found more cases like this than we

expected
