ME 164 (ME & AERO)
ASSIGNMENT 3
(Due June 18, 2020)
INSTRUCTIONS
Attempt all questions, but submit solutions to questions
2, 3
and
4
only.
Diagrams are
NOT
drawn to scale. Use the given dimensions on each drawing for all your calculations
whenever necessary.
Neglect masses and frictional effects if they are not given.
Use the value g = 9.81 m/s
2
for acceleration due to gravity, and unless otherwise stated,
work to three
decimal places.
Submit your
handwritten
solutions
(for
questions
2, 3
and
4)
on not more than
4. Marks will be
a
warded
for
clear and logical presentation of worked solutions.
Worked solution without free body diagrams will not be graded!!!.
Submissions must be scanned into one pdf file and turned in via the vclassroom. Make sure your index
number is on
every page of the submitted document.
The submitted file should be saved as your Index Number_3
(e.g. XXXXX19_3).
Failure to adhere to the
above instructions will result in the loss of marks.
