Today, we will :
Derivation of the Navier-Stokes Equation (Section 9-5, Çengel and Cimbala)
We begin with the general differential equation for conservation of linear momentum, i.e., Cauchy’s equation , which is valid for any kind of fluid,
The problem is that the stress tensor σ ij needs to be written in terms of the primary unknowns in the problem in order for Cauchy’s equation to be useful to us. The equations that relate σ ij to other variables in the problem – velocity, pressure, and fluid properties – are called constitutive equations. There are different constitutive equations for different kinds of fluids.
Types of fluids:
Some examples of non-Newtonian fluids:
We consider only Newtonian fluids in this course.
Cauchy’s equation:
For Newtonian fluids , the shear stress is linearly proportional to the shear strain rate.
Examples of Newtonian fluids: water, air, oil, gasoline, most other common fluids.
Stress tensor
For Newtonian fluids (see text for derivation), it turns out that
Now we plug this expression for the stress tensor σ ij into Cauchy’s equation. The result is the famous Navier-Stokes equation , shown here for incompressible flow.
To solve fluid flow problems, we need both the continuity equation and the Navier-Stokes equation. Since it is a vector equation, the Navier-Stokes equation is usually split into three components in order to solve fluid flow problems. In Cartesian coordinates,
We have achieved our goal of writing σ ij in terms of pressure P , velocity components u , v , and w , and fluid viscosity μ.
Navier-Stokes equation:
