Methods & Codes 1Lecture 13
thirteen
design loads & methods,
structural codes
lecture
ARCHITECTURAL STRUCTURES:
FORM, BEHAVIOR, AND DESIGN
Methods & Codes 2Lecture 13
Design
- factors out of the designer’s control
- loads
- occurrence
- factors within the designer’s control
- choice of material
- “cost” of failure (F.S., probability, location)
- economic design method
- analysis method
Methods & Codes 4Lecture 13
Load Types
- D = dead load
- L = live load
- Lr = live roof load
- W = wind load
- S = snow load
- E = earthquake load
- R = rainwater load or ice water load
- T = effect of material & temperature
- H = hydraulic loads from soil (F from fluids)
Methods & Codes 5Lecture 13
Dead Loads
- fixed elements
- structure itself
- internal partitions
- hung ceilings
- all internal and external finishes
- HVAC ductwork and equipment
- permanently mounted equipment
- F = mg (GRAVITY)
Methods & Codes 7Lecture 13
Concentrated Loads
Methods & Codes 8Lecture 13
Distributed Loads
- for an area
w A
Methods & Codes 10Lecture 13
Load Locations
- centric
- eccentric
- bending or flexural load
- torsional load
- combined loading
Methods & Codes 11Lecture 13 F2012abn
Load Paths
- tributary
areas
- transfer
Methods & Codes 13Lecture 13
Wind Load
- wind speed
- gusting
- terrain
- windward, leeward, up and down!
- drag
- rocking
- harmonic
- torsion
Methods & Codes 14Lecture 13
Snow Load
- latitude
- solar exposure
- wind speed
- roof slope
Moscow 2006 (BBC News)
Methods & Codes 16Lecture 13 Architectural StructuresARCH 331
Dynamic Response
Methods & Codes 17Lecture 13
Dynamic Response
- period of vibration or
frequency
- wave
- sway/time period
- damping
- reduction in sway
- resonance
- amplification of sway
Methods & Codes 19Lecture 13
Water Load
- rainwater – clogged drains
- ponding
- ice formation
mrfussycontracting.com
Methods & Codes 20Lecture 13
Thermal Load
- stress due to strain
- restrained expansion or contraction
- temperature gradients
- composite construction
