Yimin Zhang, Villanova University 1
ECE 8708 Wireless Communications : The Cellular Concept System Design Fundamentals
Chapter 3
Chapter 3
The Cellular Concept
The Cellular Concept
System Design Fundamentals
System Design Fundamentals
Yimin Zhang, Ph.D.
Department of Electrical & Computer Engineering
Villanova University
http://yiminzhang.com/ECE8708
pf3
pf4
pf5
pf8
pf9
pfa
pfd
pfe
pff
pf12
pf13
pf14
pf15
pf16
pf17
pf18
pf19
pf1a
pf1b
pf1c
pf1d
pf1e
pf1f
pf20
pf21
pf22
pf23
pf24
pf25
pf26
pf27
pf28
pf29
pf2a
pf2b
pf2c
pf2d
pf2e
pf2f
pf30
pf31
pf32

Partial preview of the text

Download The Cellular Concepts - System Design Fundamentals | ECE 8708 and more Study notes Mass Communication in PDF only on Docsity!

Chapter 3 Chapter 3

The Cellular ConceptThe Cellular Concept

  • System Design Fundamentals– System Design Fundamentals

Yimin Zhang, Ph.D.

Department of Electrical & Computer Engineering

Villanova University

http://yiminzhang.com/ECE

OutlinesOutlines

Frequency Reusing

Design of Clutter Size

Channel Assignment Strategies

Handoff Strategies

Co-channel Interference and Adjacent channel

Interference

Trunking and Grade of Service

Early Mobile Telephone System Low Capacity: Consider that the assigned frequency band can afford 100 simultaneous conversations (channels).

Early Mobile Telephone System

Low Capacity: Consider that the assigned frequency band can afford 100 simultaneous conversations (channels).

Cellular System High Capacity: Consider that the assigned frequency band is reused in 10 cells, the system may afford 1000 simultaneous conversations (channels).

Cellular System High Capacity: Consider that the assigned frequency band is reused in 10 cells, the system may afford 1000 simultaneous conversations (channels).

Frequency Reusing Frequency Reusing

l The cellular concept was a major breakthrough in solving the problem of spectral congestion and user capacity.

l It offered very high capacity in a limited spectrum allocation without any major technological changes.

l The cellular concept was a major breakthrough in solving the problem of spectral congestion and user capacity.

l It offered very high capacity in a limited spectrum allocation without any major technological changes.

Cellular System However, neighboring cells will interfere to each other. Therefore, they shall use different frequency bands. A cell cluster is outlined in bold, and replicated over the coverage area. Cells with the same letter use the same set of frequencies.

Cellular System

However, neighboring cells will interfere to each other. Therefore, they shall use different frequency bands.

A cell cluster is outlined in bold, and replicated over the coverage area. Cells with the same letter use the same set of frequencies.

In this example, the cluster size is N =7, and the frequency reuse factor is 1/7, since each cell contains 1/7 of the total number of available channels.

In this example, the cluster size is N =7, and the frequency reuse factor is 1/7, since each cell contains 1/7 of the total number of available channels.

Frequency Reusing Frequency Reusing

Frequency Reusing Frequency Reusing

Actual cellular footprint is determined by the contour of a given transmitting antenna.

Frequency Reusing Frequency Reusing

Consider a cellular system

Total duplex channels : S

Cluster size : N cells

No. of channels in each cell : k = S/N

Capacity in a cluster : C = kN = S

If a cluster is replicated M times

Total capacity : C = MkN = MS

‡ The capacity is increased by M.

In order to connect without gaps between adjacent cells

N = i^2 + ij + j^2

where i and j are non-negative integers.

Example: When i = 2, j = 1

N = 2^2 + 2(1) + 1^2 = 4 + 2 + 1 = 7

Commonly used cluster size N = 4, 7, 12.

Design of Cluster Size Design of Cluster Size

Example Example

Problem: If a particular FDD cellular telephone system has a total bandwidth of 33 MHz, and if the phone system uses two 25 KHz simplex channels to provide full duplex voice and control channels...

compute the number of channels per cell if N = 4, 7, 12.

Problem: If a particular FDD cellular telephone system has a total bandwidth of 33 MHz,

and if the phone system uses two 25 KHz simplex channels to provide full duplex voice and control channels...

compute the number of channels per cell if N = 4, 7, 12.

Solution: Total bandwidth = 33 MHz Channel bandwidth = 25 KHz x 2 = 50 KHz Total available channels = 33 MHz / 50 KHz = 660

N = 4 Channel per cell = 660 / 4 =165 channels

N = 7 Channel per cell = 660 / 7 = 95 channels

N = 12 Channel per cell = 660 / 12 = 55 channels

Solution: Total bandwidth = 33 MHz Channel bandwidth = 25 KHz x 2 = 50 KHz Total available channels = 33 MHz / 50 KHz = 660

N = 4 Channel per cell = 660 / 4 =165 channels

N = 7 Channel per cell = 660 / 7 = 95 channels

N = 12 Channel per cell = 660 / 12 = 55 channels

Handoff Strategies Handoff Strategies

Handoff: When a mobile moves into a different cell while a conversation is in progress, the MSC automatically transfers the call to a new channel belonging to the new base station.

  • Important task in any cellular radio system
  • Handoffs must be performed successfully, as infrequently as possible, and not visible to users.

When designing handoff, it is important to bear in mind that it requires certain time to complete the handoff.

Handoff:

When a mobile moves into a different cell while a conversation is in progress, the MSC automatically transfers the call to a new channel belonging to the new base station.

  • Important task in any cellular radio system
  • Handoffs must be performed successfully, as infrequently as possible, and not visible to users.

When designing handoff, it is important to bear in mind that it requires certain time to complete the handoff.

(a) Improper Handoff Situation (a) Improper Handoff Situation

Received signal levelReceived signal level

Level at point ALevel at point A

Handoff thresholdHandoff threshold

Minimum acceptable signalMinimum acceptable signal to maintain the callto maintain the call

TimeTime

Level at point BLevel at point B

Pr, handoff

Pr, min usable

AA^ BB

BS1 BS1 BS2BS

Margin? =Pr, handoff – Pr, min usable

Handoff Strategies Handoff Strategies

call is terminatedcall is terminated call is terminated

(b) Proper Handoff Situation (b) Proper Handoff Situation

Level at which handoff is made Level at which handoff is made

TimeTime

Level at point BLevel at point B

AA^ BB

BS1 BS1 BS2BS

Handoff Strategies Handoff Strategies

Received signal level Received signal level^ call properly transferred to BS

call properly transferred to BS2call properly transferred to BS

In deciding when to handoff, it is important to ensure that the drop in the measured signal level is not due to momentary fading.

Each base station constantly monitors the signal strength of all its reverse voice channels to determine the relative location of each mobile user with respect to the base station tower.

Dwell Time: time over which a call may be maintained within a cell, without hand-off.

Dwell time of a particular user is governed by a number of factors, including propagation, interference, distance between the subscriber and the base station, and other time-varying effects.

Handoff Strategies Handoff Strategies

Major limiting factor in performance of cellular radio systems:

  • Co-channel interference
    • Cells that use the same set of frequencies are called co- channel cells.
    • Interference between them is called co-channel interference.
  • Adjacent channel interference
    • Interference resulting from signals which are adjacent in frequency to the desired signal.
    • Due to imperfect receiver filters that allow nearby frequencies to leak into pass band.

InterferenceInterference

Signal to interference ratio (SIR, or S/I ) for a mobile receiver is given by:

S = desired signal power from designated base station

Ii = interference power caused by the i th interfering

co-channel cell base station

i 0 = number of interfering co-channel cells

Co- Co-Channel InterferenceChannel Interference

=

= = 0

1

SIR (^) i

i

Ii

S I

S
