Lecture 19

Trusted Computing and Multilevel Security

Computer Security Models

• two fundamental computer security facts:
  • all complex software systems have eventually revealed flaws or bugs that need to be fixed
  • it is extraordinarily difficult to build computer hardware/software not vulnerable to security attacks
• problems involved both design and

implementation

• led to development of formal security models

Bell-LaPadula (BLP) Model

• formal model for access control
  • developed in 1970s
• subjects and objects are assigned a security class
  • a subject has a security clearance
  • an object has a security classification
  • form a hierarchy and are referred to as security levels - top secret > secret > confidential > restricted >unclassified
  • security classes control the manner by which a subject may access an object

BLP Model Access Modes

• READ
  • the subject is allowed only read access to the object
• APPEND
  • the subject is allowed only write access to the object
• WRITE
  • the subject is allowed both read and write access to the object
• EXECUTE
  • the subject is allowed neither read nor write access to the object but may invoke the object for execution

Multi-Level Security

• no read up
  • subject can only read an object of less or equal security level
  • referred to as the simple security property
    • ss-property
• no write down
  • a subject can only write into an object of greater or equal security level
  • referred to as the *-property

7

? AC

Multi-Level Security

BLP Formal Description

• based on current state of system (b, M, f, H):
  • current access set b : triples of (s, o, a)
    • subject s has current access to object o in access mode a
  • access matrix M : matrix of M (^) ij
    • access modes of subject S (^) i to access object Oj
  • level function f : security level of subjects and objects
    • fo ( Oj ) is the classification level of object Oj
    • fs ( S (^) i ) is the security clearance of subject S (^) i
    • fc ( S (^) i ) is the current security level of subject S (^) i
  • hierarchy H : a directed rooted tree of objects

BLP Formal Description

• three BLP properties:
  • ss-property: ∀ (Si , Oj, read) has fc (Si) ≥ fo (Oj)
  • *-property: ∀ (S (^) i , Oj, append) has fc (Si) ≤ fo (Oj) and ∀ (S (^) i , Oj, write) has fc (Si ) = fo (Oj)
  • ds-property: current (Si , Oj, A (^) x ) implies A (^) x ∈ M[S (^) i Oj]
• BLP gives formal theorems
  • theoretically possible to prove system is secure
  • in practice usually not possible

BLP Rules

1 •^ get access

2 •^ release access

3 •^ change object level

4 •^ change current level

5 •^ give access permission

6 •^ rescind access permission

7 •^ create an object

8 •^ delete a group of objects

BLP

Example

*-property

16

BLP

Example

“ downgrade ” in a controlled and monitored manner “ classification creep ”: information from a range of sources and levels

“ covert channels ”: (untrusted) low classified executable data allowed to be executed by a high clearance (trusted) subject

Confidentiality or Integrity

Biba Integrity Model

• strict integrity policy:
  • Modify : To write or update information in an object
  • Observe : To read information in an object
  • Execute : To execute an object
  • Invoke : Communication from one subject to another
  • simple integrity: I(S) ≥ I(O)
  • integrity confinement: I(S) ≤ I(O)
  • invocation property: I(S1) ≥ I(S2)

Clark-Wilson Integrity Model

• Principal components of the model
  • Constrained data items (CDIs)
    • Subject to strict integrity controls
  • Unconstrained data items (UDIs)
    • Unchecked data items
  • Integrity verification procedures (IVPs):
    • Intended to assure that all CDIs conform to some application-specific model of integrity and consistency
  • Transformation procedures (TPs):
    • System transactions that change the set of CDIs from one consistent state to another (^) Docsity.com 19

Clark-Wilson Integrity Model
