1

Virtual Functions

 Virtual means existing in appearance but not in

reality.



When virtual functions are used, a program that

appears to be calling a function of one class may in

reality be calling a function of a different class.

 Why are virtual functions needed?

Suppose you have a number of objects of different

classes but you want to put them all in an array and

perform a particular operation on them using the

same function call.



For example, suppose a graphics program includes

several different shapes: a triangle, a ball, a square,

and so on, as in the MULTSHAP program in the,

“Inheritance.”chapter



Each of these classes has a member function draw()

Virtual Functions

 Now suppose you plan to make a picture by grouping

a number of these elements together, and you want

to draw the picture in a convenient way.



One approach is to create an array that holds pointers

to all the different objects in the picture. The array

might be defined like this: shape* ptrarr[100]; // array

of 100 pointers to shapes



If you insert pointers to all the shapes into this array,

you can then draw an entire picture using a simple

loop:

for(int j=0; j<N; j++) { ptrarr[j]->draw(); } //

(*ptrarr[j] ).draw()



This is an amazing capability: Completely different

functions are executed by the same function call.

Normal Member Functions Accessed with Pointers (1/2) // normal functions accessed from pointer #include using namespace std; class Base { //base class public: void show() { cout << "Base\n"; } }; class Derv1 : public Base { //derived class 1 public: void show() { cout << "Derv1\n"; } }; class Derv2 : public Base { //derived class 2 public: void show() { cout << "Derv2\n"; } };

Normal Member Functions Accessed with Pointers (1/2) int main() { Derv1 dv1; // object of derived class 1 Derv2 dv2; // object of derived class 2 Base* ptr; // pointer to base class ptr = &dv1; // put address of dv1 in pointer // The rule is that pointers to objects of a derived // class are type compatible with pointers to objects of // the base class. ptr->show(); // execute show() OR (*ptr).show(); // the function in the base class is always executed. ptr = &dv2; // put address of dv2 in pointer ptr->show(); // execute show() return 0; } 5

Virtual Member Functions Accessed with Pointers (1/2) // virtual functions accessed from pointer #include using namespace std; class Base{ // base class public: virtual void show() // virtual function { cout << "Base\n"; } }; class Derv1 : public Base { // derived class 1 public: void show() { cout << "Derv1\n"; } }; class Derv2 : public Base { //derived class 2 public: void show() { cout << "Derv2\n"; } };

Virtual Member Functions Accessed with Pointers (2/2) int main() { Derv1 dv1; // object of derived class 1 Derv2 dv2; // object of derived class 2 Base* ptr; // pointer to base class ptr = &dv1; // put address of dv1 in pointer ptr->show(); // execute show() of Derv // The rule is that the compiler selects the function // based on the contents of the pointer ptr, not on the // type of the pointer ptr = &dv2; // put address of dv2 in pointer ptr->show(); // execute show() of Derv return 0; }

Late Binding

 Which version of draw() does the compiler call?



In fact the compiler doesn’t know what to do, so it

arranges for the decision to be deferred until the

program is running.

 At runtime, when it is known what class is pointed to

by ptr, the appropriate version of draw will be called.

This is called late binding or dynamic binding.

 Choosing functions in the normal way, during

compilation, is called early binding or static binding.



Late binding requires some overhead but provides

increased power and flexibility.

 We’ll put these ideas to use in a moment, but first

let’s consider a refinement to the idea of virtual

functions.

11 Abstract Classes and Pure Virtual Functions  (^) Think of the shape class in the multshap program in Chapter 9. We’ll never make an object of the shape class; we’ll only make specific shapes such as circles and triangles.  When we will never want to instantiate objects of a base class, we call it an abstract class_. Such a class exists_ only to act as a parent of derived classes that will be used to instantiate objects.  (^) If we don’t want anyone to instantiate objects of the base class, we’ll write our classes so that such instantiation is impossible.  How can we can do that? By placing at least one pure virtual function in the base class.  A pure virtual function is one with the expression = added to the declaration. This is shown in the next

Abstract Classes and Pure Virtual Functions (1/2) int main() { // Base bad; // can’t make object from abstract class Base* arr[2]; // array of pointers to base class Derv1 dv1; // object of derived class 1 Derv2 dv2; // object of derived class 2 arr[0] = &dv1; // put address of dv1 in array arr[1] = &dv2; // put address of dv2 in array arr[0]->show(); // execute show() in both objects arr[1]->show(); return 0; }

Abstract Classes and Pure Virtual Functions  (^) Once you’ve placed a pure virtual function in the base class, you must override it in all the derived classes from which you want to instantiate objects.  If a class doesn’t override the pure virtual function, it becomes an abstract class itself, and you can’t instantiate objects from it (although you might from classes derived from it).  For consistency, you may want to make all the virtual functions in the base class pure.

Virtual Functions and the person Class (2/3) } bool isOutstanding(){ return (gpa > 3.5)? true : false; } }; class professor : public person { // professor class private: int numPubs; // number of papers published public: void getData() { //get professor data from user person::getName(); cout << " Enter number of professor’s publications: "; cin >> numPubs; } bool isOutstanding() { return (numPubs > 100)? true : false; } };

Virtual Functions and the person Class (1/3) int main(){ person* persPtr[100]; // array of pointers to persons int n = 0; char choice; // number of persons on list do { cout << "Enter student or professor (s/p): "; cin >> choice; if(choice=='s') persPtr[n] = new student; else persPtr[n] = new professor; persPtr[n++]->getData(); //get data for person cout << " Enter another (y/n)? "; cin >> choice; } while( choice=='y' ); //cycle until not ‘y’ for(int j=0; j<n; j++){ //print names of all persPtr[j]->putName(); // say if outstanding if( persPtr[j]->isOutstanding() ) cout << " This person is outstanding\n"; } return 0; } //end main()

Virtual Base Classes

 Before leaving the subject of virtual

programming elements, we should

mention virtual base classes as

they relate to multiple inheritance.



Consider the situation shown in Fig.

with a base class, Parent; two

derived classes, Child1 and Child2;

and a fourth class, Grandchild,

derived from both Child1 and Child2.



In this arrangement a problem can arise if a member

function in the Grandchild class wants to access data

or functions in the Parent class.



The NORMBASE program shows what happens.

Virtual Base Classes #include using namespace std; class Base { public: ~Base() // non-virtual destructor // virtual ~Base() // virtual destructor { cout << "Base destroyed\n"; } }; class Derv : public Base { public: ~Derv() { cout << "Derv destroyed\n"; } }; int main(){ Base* pBase = new Derv; delete pBase; return 0; }
