Quiz
•A full wave rectifier circuit with 1kohm load operates on a 120 Vrms 60 Hz
supply through a 5-to-1 transformer having a center tapped secondary
winding. Using practical model of silicon diode find
–The peak voltage of rectified output
–The average output voltage
–The average current in the load
•Determine the voltage across the Diode using practical and complete
diode model assume rd‘=10 ohm and rR’=100 Mohm
