Chapter 6: Web Security

Objectives

  • Protect e-mail systems
  • List World Wide Web vulnerabilities
  • Secure Web communications
  • Secure instant messaging

How E-Mail Works

  • Use two Transmission Control Protocol/Internet Protocol (TCP/IP) protocols to send and receive messages - Simple Mail Transfer Protocol (SMTP) handles outgoing mail - Post Office Protocol (POP3 for the current version) handles incoming mail
  • The SMTP server on most machines uses sendmail to do the actual sending; this queue is called the sendmail queue

How E-Mail Works (continued)

How E-Mail Works (continued)

  • E-mail attachments are documents in binary format (word processing documents, spreadsheets, sound files, pictures)
  • Non-text documents must be converted into text format before being transmitted
  • Three bytes from the binary file are extracted and converted to four text characters

E-Mail Vulnerabilities

  • Several e-mail vulnerabilities can be exploited by attackers: - Malware - Spam - Hoaxes

Malware (continued)

  • A worm can enter a user’s computer through an e-mail attachment and send itself to all users listed in the address book or attach itself as a reply to all unread e-mail messages
  • E-mail clients can be particularly susceptible to macro viruses - A macro is a script that records the steps a user performs - A macro virus uses macros to carry out malicious functions

Malware (continued)

  • Users must be educated about how malware can enter a system through e-mail and proper policies must be enacted to reduce risk of infection - E-mail users should never open attachments with these file extensions: .bat, .ade, .usf, .exe, .pif
  • Antivirus software and firewall products must be installed and properly configured to prevent malicious code from entering the network through e-mail
  • Procedures including turning off ports and eliminating open mail relay servers must be developed and enforced

Spam (continued)

  • According to a Pew memorial Trust survey, almost half of the approximately 30 billion daily e-mail messages are spam
  • Spam is having a negative impact on e-mail users: - 25% of users say the ever-increasing volume of spam has reduced their overall use of e-mail - 52% of users indicate spam has made them less trusting of e-mail in general - 70% of users say spam has made being online unpleasant or annoying

Spam (continued)

  • Filter e-mails at the edge of the network to prevent spam from entering the SMTP server
  • Use a backlist of spammers to block any e-mail that originates from their e-mail addresses
  • Sophisticated e-mail filters can use Bayesian filtering - User divides e-mail messages received into two piles, spam and not-spam

Hoaxes (continued)

  • Any e-mail message that appears as though it could not be true probably is not
  • E-mail phishing is also a growing practice
  • A message that falsely identifies the sender as someone else is sent to unsuspecting recipients

E-Mail Encryption

  • Two technologies used to protect e-mail messages as they are being transported: - Secure/Multipurpose Internet Mail Extensions - Pretty Good Privacy

Pretty Good Privacy (PGP)

  • Functions much like S/MIME by encrypting messages using digital signatures
  • A user can sign an e-mail message without encrypting it, verifying the sender but not preventing anyone from seeing the contents
  • First compresses the message
    • Reduces patterns and enhances resistance to cryptanalysis
  • Creates a session key (a one-time-only secret key) - This key is a number generated from random movements of the mouse and keystrokes typed

Pretty Good Privacy (PGP)

(continued)

  • Uses a passphrase to encrypt the private key on the local computer
  • Passphrase:
    • A longer and more secure version of a password
    • Typically composed of multiple words
    • More secure against dictionary attacks
