Problem 1 (4 points)
What are the values of the registers A, B, IX, and CC (condition code register), the array GAMMA, and the variable COUNT after executing the following code written in the assembly language. Please provide only relevant intermediate values of registers and variables to qualify for a partial credit in case of a mistake.
SIZE EQU 4
org $D COUNT dc.w 12 GAMMA dc.b $CB, $AF, $FF, $F
section .text SHIFT: LDY COUNT
OUTER_LOOP LDAB #SIZE LDX #GAMMA+ CLC
INNER_LOOP ROL 0,X DEX DECB BNE INNER_LOOP
DEY BNE OUTER_LOOP
LDD GAMMA+ SUBD GAMMA
RTS END
Problem 5 (4 points) Write a sequence of assembler directives corresponding to the following sequence of declarations and definitions in C. Define sections, and group together variables belonging to the same section.
#define AA 16 #define COLUMN_NR 3 static unsigned int counter1 = 1000; extern long count(int event_nr); static int array1[][COLUMN_NR]={{0x76, 076, 76}, {’a’, 0xAA, AA}} static float *fptr; long long1 = -2; char *string1 = "GMU"; char string2[] = "CpE"; unsigned char blank[] = {’\t’, ’ ’};
