ABB Large Motors and Generators

Keeping the world turning, while saving energy every day

Making the case

for energy efficiency

→ The global population

is expected to rise to

9.7 billion by 2050

→ The global economy

is expected to double

over the same period

→ Urbanization, and the

rise of living standards

will increase the

demand for energy

→ The world is going

electric and the

number of motors

will double by 2040

→ Critical processes

can’t stop, but need to

be energy efficient to

reduce CO 2 emissions

→ With high-efficiency

motors we can do

just that

Energy efficiency

makes the difference

It has been estimated that, if all of the more than 300 million industrial electric motor-driven systems currently in operation were replaced with optimized, high-efficiency equipment, global electricity consumption could be reduced by up to 10 percent Electricity consumption

Our products power the critical applications in industry, infrastructure and

marine transportation

Induction motors Powering pumps to provide reliable water supply 24/ Synchronous motors Running the compressors at the heart of air separation plants Special design motors Turning propellers to navigate the worlds largest cruise ships Synchronous Generators Providing stability and inertia to the (renewable) power grid Our portfolio and where are our Motors and Generators are used ↓

Our domain expertise

leads the industry

We understand customer needs, building on decades-long experience and relationships Here’s some examples of our customer successes

Telangana State Irrigation

India

Telangana is the world’s largest multi-stage pumping Infrastructure. The

Kaleshwaram Lift Irrigation System is a massive engineering project designed to

bring much needed water to the region.

Stretching over 300 km, the gravity- driven lift irrigation system raises and redirects 5,5 Billion cubic meters of water annually to the reservoirs and channels Reliable, advanced technology Electrical stress to machine and power grids minimized with integrated Drives We supplied the largest capacity motors used by ABB for irrigation: 40 & 43 MW Rich industry experience Global & Local team collaboration

Tallink MyStar

Helsinki, Finland

AS Tallink Grupp is a leading provider of passenger

and freight transport services in the northern Baltic region

MyStar uses liquefied natural gas (LNG) as its main fuel source. In addition, MyStar has state-of-the-art technology that meets all current and known future emissions requirements MyStar is fitted with 2 main motors and five generators which supply the ship with all the necessary electricity it needs

Statkraft

Lister Drive,

Liverpool, UK

ABB’s synchronous condensers are being used to stabilize the UK power grid with growing renewable energy.

Thanks to a close, trusted collaboration Statkraft have signed a 10-year services contract.

High inertia system Ensures that network frequency and voltage are stable Essential for grid reliability Close collaboration Rich industry experience

Our offerings in a nutshell

Large Motors and Generators for all major industries and applications

Induction motors ABB offers a full range of high voltage induction motors, including rib cooled motors, modular slip-ring motors and modular welded frame motors with different cooling options Generators ABB has a long and successful track record of designing and building generators for all power generation applications. ABB has the modern products, experience and resources needed to support plant builders and operators from the initial project concept through design and installation to many years of efficient, reliable operation. Synchronous motors ABB is the market’s leading supplier of synchronous motors and generators. All over the world our synchronous motors deliver high performance in industrial processes, marine and offshore sectors, utilities, and specialized applications. Special design motors ABB offers a wide variety of solutions for other specialized needs. From propulsion and Direct drive motors for Marine, to Drilling motors for particular working environments.

Induction motors product offering

• High power density
• Easy configurability
• Flameproof option available
• ABB Ability™ Smart Sensor equipped
• Utilizing our modular design, we provide reliable, optimized solutions for a wide variability of customer needs
• Complete range of enclosures and cooling arrangements
• Modular offering for hazardous areas
• Slip-ring modular design offering
• Above NEMA frame sizes and matching dimensions Rib Cooled Modular Above NEMA

Synchronous Motors product offering

• Driven equipment:
  • Compressors (primarily centrifugal)
  • Refiners
  • Pumps
  • Blowers
  • Extruders AMS Motors 3,000 – 75,000 kW 4 - 6 pole Horizontal AMZ Motors
• Other (AMS and AMZ):
• DOL/VSD
• Ex standards
• Air and water cooled
• IEC/NEMA
• Driven equipment:
• Compressors (reciprocating)
• Mine Hoist
• Refiners
• Pumps
• Mills
• Conveyors
• Extruders
• Rolling mills
• Propulsion 3 ,000 – 50,000 kW 4 - 40 pole* *4-6 pole only for small sized VSD (metal) Horizontal and Vertical

Special solutions product offering

• Gearless steerable propulsion system
• Ability to cut fuel consumption up to 20% compared to traditional shaft line propulsion systems Permanent magnet motor solutions could replace:
• Traditional AC motor, VSD and gear box combination
• Traditional slow speed AC motor, typically 10- 16 - pole or slower with frequency converter
• Variable speed DC drive system with gear box
• Flexible drop-in replacement for motors commonly used in O&G drilling industry
• Highest power available in the market for typical mud-pump applications
• Available as complete motor-drive package Azipod® propulsion motors Direct Drive motors Drilling motors

ABB Ability™ Digital Services

Digitalizing your powertrain assets

We support our customers throughout the whole life cycle helping them maximize operational uptime and performance through preventive and condition-based servicing

MachSize quotation tool

A drive and motor for your needs in just four steps

“It only takes five minutes to buy a high voltage motor?”

• Easy-to-use online tool
• Accessible 24/7 on laptops, tablets, phones
