An overview of securing inter-VLAN traffic using Palo Alto Networks firewalls in two different scenarios: when each VLAN has its unique IP subnet and when a single IP subnet spans multiple VLANs. configuration examples and interface, zone, and VLAN configurations.
Typology: Schemes and Mind Maps
1 / 12
This page cannot be seen from the preview
Don't miss anything!







Revision B ©2012, Palo Alto Networks, Inc. www.paloaltonetworks.com
Interface Interface type Zone/Type VR IP address
Ethernet 1/15 Layer 3 Trust/layer3 default-vr
Ethernet 1/15.10 Layer 3 VLAN10/layer3 default-vr 172.16.10.1/
Ethernet 1/15.20 Layer 3 VLAN 20/layer3 default-vr 172.16.20.1/
Ethernet 1/15.30 Layer 3 VLAN 30/layer3 default-vr 172.16.30.1/
Create a new Layer 3 interface, one for each VLAN. The following figure shows the screen shot for interface ethernet1/15.10 configured for VLAN 10. Note that the parent interface ethernet1/15 must be configured as a layer 3 interface.
With all the interfaces configured, the VLAN and interface configuration must look like the following screenshot:
In this example, we allow oracle traffic from VLAN10 to VLAN20 as well as internet access for all VLANs.
In this case, the same IP subnet spans multiple VLANs as shown in the following figure. The Palo Alto Networks firewall in configured in layer 2 mode and can be deployed to secure inter VLAN traffic.
The interface ethernet1/15 is configured as a layer 2 interface. Subinterfaces corresponding to each one of the VLAN are created off of the parent interface ethernet1/15. These subinterfaces are then assigned to a single VLAN. The firewall treats each one of the VLAN logical interfaces as physical interfaces, all in the same VLAN. This allows the firewall to forward traffic between each of these interfaces since they are in the same VLAN, irrespective of the tag. In order to apply security policies, each of these individual interfaces can be assigned to its own zone. The table below summarizes the interface, zone, and VLAN configuration on the firewall.
Interface Interface type Tag VLAN Zone/Type
Ethernet 1/15 Layer 2 untagged VLAN-BRIDGE Trust-L2/layer
Ethernet 1/15.10 Layer 2 10 VLAN- BRIDGE VLAN10/layer
Ethernet 1/15.20 Layer 2 20 VLAN-BRIDGE VLAN 20/layer
Ethernet 1/15.30 Layer 2 30 VLAN-BRIDGE VLAN 30/layer
Create a new VLAN called Bridge_50to70. Navigate to network > vlans > new
Packet received at slowpath stage Packet info: len 70 port 30 interface 256 wqe index 229357 packet 0x0x8000000416fb30e Packet decoded dump: L2: a4:ba:db:ba:3f:07->00:1b:17:00:01:1e, VLAN 10 (0x8100 0x000a), type 0x IP: 172.16.1.100->172.16.2.100, protocol 6 version 4, ihl 5, tos 0x00, len 52 , id 1119, frag_off 0x4000, ttl 128, checksum 39548 TCP: sport 57032, dport 443, seq 3256824124, ack 0, reserved 0, offset 8, window 8192, checksum 8014, flags 0x0002 ( SYN), urgent data 0 TCP option: 00000000: 02 04 05 b4 01 03 03 02 01 01 04 02 ........ .... Session setup: vsys 1 Session setup: ingress interface ethernet1/15.10 egress interface ethernet1/15.20 (zone 5) Policy lookup, matched rule index 0 Allocated new session 52 Created session, enqueue to install
== Sep 10 11:53:29 == Packet received at fastpath stage Packet info: len 70 port 30 interface 256 wqe index 229357 packet 0x0x8000000416fb30e Packet decoded dump: L2: a4:ba:db:ba:3f:07->00:1b:17:00:01:1e, VLAN 10 (0x8100 0x000a), type 0x IP: 172.16.1.100->172.16.2.100, protocol 6 version 4, ihl 5, tos 0x00, len 52, id 1119, frag_off 0x4000, ttl 128, checksum 39548 TCP: sport 57032, dport 443, seq 3256824124, ack 0, reserved 0, offset 8, window 8192, checksum 8014, flags 0x0002 ( SYN), urgent data 0 TCP option: 00000000: 02 04 05 b4 01 03 03 02 01 01 04 02 ........ .... Flow fastpath, session 52 Forwarding lookup, ingress interface 256 L2 mode, VLAN 1 MAC entry found on VLAN 1, packet switched to interface ethernet1/15. L2 tag translation, replace VLAN tag with 20 Transmit packet on port 30
== Sep 10 11:53:29 == Packet received at np stage Packet info: len 70 port 30 interface 257 wqe index 229339 packet 0x0x8000000416ff70e Packet decoded dump: L2: 00:1b:17:00:01:1e->a4:ba:db:ba:3f:07, VLAN 20 (0x8100 0x0014), type 0x IP: 172.16.2.100->172.16.1.100, protocol 6 version 4, ihl 5, tos 0x00, len 52, id 0, frag_off 0x4000, ttl 64, checksum 57051 TCP: sport 443, dport 57032, seq 1526252708, ack 3256824125,
reserved 0, offset 8, window 5840, checksum 2252, flags 0x0012 ( SYN ACK), urgent data 0 TCP option: 00000000: 02 04 05 b4 01 01 04 02 01 03 03 06 ........ ....
== Sep 10 11:53:29 == Packet received at np stage Packet info: len 64 port 30 interface 256 wqe index 229295 packet 0x0x8000000416fec8e Packet decoded dump: L2: a4:ba:db:ba:3f:07->00:1b:17:00:01:1e, VLAN 10 (0x8100 0x000a), type 0x IP: 172.16.1.100->172.16.2.100, protocol 6 version 4, ihl 5, tos 0x00, len 40, id 1120, frag_off 0x4000, ttl 128, checksum 39559 TCP: sport 57032, dport 443, seq 3256824125, ack 1526252709, reserved 0, offset 5, window 16425, checksum 8260, flags 0x0010 ( ACK), urgent data 0 TCP option:
== Sep 10 11:53:29 == Packet received at fastpath stage Packet info: len 70 port 30 interface 257 wqe index 229339 packet 0x0x8000000416ff70e Packet decoded dump: L2: 00:1b:17:00:01:1e->a4:ba:db:ba:3f:07, VLAN 20 (0x8100 0x0014), type 0x IP: 172.16.2.100->172.16.1.100, protocol 6 version 4, ihl 5, tos 0x00, len 52, id 0, frag_off 0x4000, ttl 64, checksum 57051 TCP: sport 443, dport 57032, seq 1526252708, ack 3256824125, reserved 0, offset 8, window 5840, checksum 2252, flags 0x0012 ( SYN ACK), urgent data 0 TCP option: 00000000: 02 04 05 b4 01 01 04 02 01 03 03 06 ........ .... Flow fastpath, session 52 Forwarding lookup, ingress interface 257 L2 mode, VLAN 1 MAC entry found on VLAN 1, packet switched to interface ethernet1/15. L2 tag translation, replace VLAN tag with 10 Transmit packet on port 30
Traffic Log
All traffic for destination other than 172.16.0.0/16 will be forwarded to the VLAN.1 interface. It is important to understand the security policies must be created between the layer3 zones, i.e. trust-VLAN zone where the VLAN.1 interface is untrust zone, and where the ethernet1/14 interface is bound. The following figure shows the security rules required to permit access from VLAN10 and VLAN20 to the external network.
NAT can also be applied to traffic from the VLANs. Sample NAT configuration to translate all traffic from trust-VLAN to the egress interface IP is shown in the following table:
Palo Alto Networks firewalls provide a very flexible architecture to deploy and secure layer2 networks, while still offering the benefits of App-ID, Content-ID, and User-ID.
