VLAN Trunking Protocol
Semester 3 – Module 9
Students completing this module should be able to:
Explain the origins and functions of VLAN trunking
Describe how trunking enables the implementation of VLANs in a large network
Define IEEE 802.1Q and Cisco ISL
Configure and verify a VLAN trunk
Define VTP
Explain why VTP was developed
Describe the contents of VTP messages
List and define the three VTP modes
Configure and verify VTP on an IOS-based switch
Explain why routing is necessary for inter-VLAN communication
Explain the difference between physical and logical interfaces
Define subinterfaces
Configure inter-VLAN routing using subinterfaces on a router port
Docsity.com
pf3
pf4
pf5
pf8
pf9
pfa
pfd
pfe
pff
pf12
pf13
pf14

Partial preview of the text

Download VLAN Trunking Protocol - Computer Network - Lecture Slides and more Slides Computer Networks in PDF only on Docsity!

VLAN Trunking Protocol

Semester 3 – Module 9

Students completing this module should be able to:

Explain the origins and functions of VLAN trunking Describe how trunking enables the implementation of VLANs in a large network Define IEEE 802.1Q and Cisco ISL Configure and verify a VLAN trunk Define VTP Explain why VTP was developed Describe the contents of VTP messages List and define the three VTP modes Configure and verify VTP on an IOS-based switch Explain why routing is necessary for inter-VLAN communication Explain the difference between physical and logical interfaces Define subinterfaces Configure inter-VLAN routing using subinterfaces on a router port Docsity.com

Overview

• VLAN trunking allows many VLANs to be

defined throughout an organization by adding

special tags to frames to identify the VLAN to

which they belong

• This tagging allows many VLANs to be carried

across a common backbone, or trunk

• VLAN trunking is standards-based, with the

IEEE 802.1Q trunking protocol now widely

implemented

• Cisco’s Inter-Switch Link (ISL) is a proprietary

trunking protocol that can be implemented in all

Cisco networks

Trunking Concepts

• In the context of a VLAN switching environment,

a trunk is a point-to-point link that supports

several VLANs

Trunking Operations

  • Trunking protocols were developed to effectively manage the

transfer of frames from different VLANs on a single physical line

  • Currently two types of trunking mechanisms exist, frame filtering and

frame tagging

  • Frame tagging has been adopted as the standard trunking

mechanism by IEEE

  • Trunking protocols that use a frame tagging mechanism assign an

identifier to the frames to make their management easier and to

achieve a faster delivery of the frames

  • The unique physical link between the two switches is able to carry

traffic for any VLAN

  • In order to achieve this, each frame sent on the link is tagged to

identify which VLAN it belongs to

  • Different tagging schemes exist. The most common tagging

schemes for Ethernet segments are listed below:

  • ISL – Cisco proprietary Inter-Switch Link protocol
  • 802.1Q – IEEE standard that will be focused on in this section

Trunking Implementation

• To create or configure a VLAN trunk on a Cisco

IOS command-based switch, configure the port first

as a trunk and then specify the trunk encapsulation

with the following commands:

VLAN Trunking Protocol (VTP)

• VTP is a messaging protocol that uses Layer 2

trunk frames to manage the addition, deletion,

and renaming of VLANs on a single domain

• VTP was created to solve operational problems

in a switched network with VLANs:

  • VTP has the ability to trunk over mixed media

environments such as Ethernet and FDDI

  • VTP ensures VLAN configuration consistency across

an administrative domain

  • VTP reduces the complexity of managing and

monitoring VLAN networks

VTP Operation

• A VTP domain is made up of one or more

interconnected devices that share the same VTP

domain name

• A switch can only be in one VTP domain

• The VTP header varies, depending upon the

type of VTP message, but generally, four items

are found in all VTP messages:

  • VTP protocol version: Either Version 1 or 2
  • VTP message type: Indicates one of four types
  • Management domain name length: Indicates size of

the name that follows

  • Management domain name: The name configured for

the management domain

VTP Operation Modes

  • VTP switches operate in one of three modes:
    • Server
      • Can create, modify, and delete VLAN and VLAN configuration parameters for the entire domain
      • VTP servers save VLAN configuration information in the switch NVRAM
      • VTP servers send VTP messages out to all trunk ports
    • Client
      • Cannot create, modify, or delete VLAN information
      • Can ONLY adopt VLAN management changes
      • Useful for switches lacking memory to store large tables of VLAN information
      • Only role of VTP clients is to process VLAN changes and send VTP messages out all trunk ports
    • Transparent
      • Pass VLAN management information received from other switches, but ignore information contained in the message
      • Add VLANs of local significance only
      • VLANs created are not included in VTP advertisements

VTP Advertisements

  • The following can trigger these advertisements:
    • Creating or deleting a VLAN
    • Suspending or activating a VLAN
    • Changing the name of a VLAN
    • Changing the maximum transmission unit (MTU) of a VLAN
  • Advertisements may contain some or all of the following

information:

  • Management domain name - Advertisements with different

names are ignored

  • Configuration revision number - The higher number indicates a

more recent configuration

  • Message Digest 5 (MD5) - MD5 is the key that is sent with the

VTP when a password has been assigned. If the key does not

match, the update is ignored

  • Updater identity - The updater identity is the identity of the switch

that is sending the VTP summary advertisement

VTP Configuration

  • The following basic tasks must be considered before

configuring VTP and VLANs on the network:

  • Determine the version number of VTP that will be utilized
  • Decide if this switch is to be a member of an existing

management domain or if a new domain should be created

  • If a management domain exists, determine the name and password of the domain
  • Choose a VTP mode for the switch
  • Two different versions of VTP are available
  • Can NOT be used together
  • Version 1
  • VTP Version 1 is the default
  • Version 2
  • May be implemented if some of the specific features that VTP Version 2 offers are not offered in VTP Version 1
  • The most common feature that is needed is Token Ring VLAN support

VTP – Management Domain

  • If the switch being installed is the first switch in the network,

create the management domain

  • To create a management domain use the following

command:

  • Switch(vlan)#vtp domain cisco
  • The domain name can be between 1 and 32 characters
  • The password must be between 8 and 64 characters long

VTP – Switch Mode

  • Choose one of the three modes for the switch:
  • Server – use this if this is the first switch in the network. This will allow other switches to get information from this switch - Switch(vlan)#vtp server
  • Client
    • Verify that its VTP configuration revision number is lower than the configuration revision number of the other switches in the VTP domain
    • Use the show vtp status command
    • Switch(vlan)#vtp client
  • Transparent
    • Switch(vlan)#vtp transparent

Subinterfaces

• A subinterface is a logical interface within

a physical interface, such as the Fast

Ethernet interface on a router

• Multiple subinterfaces can exist on a

single physical interface

Configuring Inter-VLAN Routing

• Routers are needed for inter-VLAN

communication
