ASSIGNMENT 1 ANSWER P1. Discuss the benefits and constraints of different network types and standards
1. Overview about Network The exchange of information or services among individuals, groups, or institutions is referred to as networking. It is made up of a number of devices that communicate with one another. Imagine a spiderweb with several spiders, each of which can link and approach each other via spider silk. Almost everywhere, networks are used. We wouldn’t be able to use our computers at school or at work if they weren’t available. Seriously, without the internet, many jobs that appear to be simple when completed with a computer would become very hard to do. Most of the technological services we use, such as desktop computers, laptops, tablets, smartphones, televisions, game consoles, smart appliances, and other gadgets, are all connected through networks. 1.1 Types of network There are several sorts of networks, each of which may be utilized for a variety of reasons and by a variety of individuals and organizations. Here are some of the different sorts of networks you could encounter. 1. 1 .1 Local Area Network (LAN)
- Define: A local area network, often known as LAN, is a network that links computers within a certain geographic region. This might happen in a classroom, a workplace, or even your own house. A PC, for example, may connect to the router using Ethernet, while smartphones and tablets might connect via Wi-Fi. All router-connected devices share the same network and, in many cases, the same Internet connection. Benefits: A local area network (LAN) is handy for sharing resources like as files, printers, games, and other programs. Because data is housed on a single computer, it might be simple to handle.
- Constraints: The LAN administrator has access to each LAN user’s personal data files and can inspect them. He may also view the LAN user’s PC and internet history. As a result, security has been compromised, and privacy has been violated. In addition, the available space is restricted. Figure 1: Local area network Source: https://techterms.com/definition/network
1 .1. 2 Metropolitan Area Network (MAN)
- Define: A MAN network is a network model that connects many LANs via cables, transmission facilities, and other means. The connection range is large, similar to that of a metropolis. Organizations and corporations with several branches or divisions are the most common users of the MAN network paradigm.
- Benefits: MAN provides a solid connection and all data is readily handled in a centralized manner, despite the fact that it is not as expensive as WAN. Furthermore, the security server is superior than WAN.
- Constraints: It isn’t compatible with phone copper cables. The speed of MAN is influenced by copper cables. Fiber optics, as a result, need a high cost. When compared to a LAN, this network has a higher chance of being attacked by hackers. As a result, there may be a data breach. In MAN, high-security personnel are required. Figure 2 : Metropolitan Area Network Source: https://mesidas.com/lan-man-wan/ 1 .1. 3 Wide Area Network (WAN)
- Define: A WAN is a network that connects a LAN and a MAN through satellite, fiber optic cable, or wire cable. This wide area network may link to a private network as well as construct huge connections that span the entire country or the globe.
- Benefits: Information exchange and storage capabilities. The network may be used by both employees and customers.
- Constraints: Because data transit can be easily accessed by hackers, security solutions are required. They are costly to put up. Purchasing routers, switches, and security solutions is required to set up a WAN.
2. Overview about Protocol Network protocols are a collection of rules that regulate how computer network devices – from servers and routers to endpoints – format, send, and receive data. For device networks, standardized protocol networks provide a common language. Computers would be unable to interact with one another without them. A network protocol links one device’s layer to another device’s layer, with each layer adding control information to the communication. The message is eventually carried via a stream of bits carried by the physical layer. Each protocol is implemented at each layer by each network device. Ethernet is a network protocol designed for use in local area networks (LAN). Figure 2: Overview about Protocol Source: https://fcit.usf.edu/network/chap2/chap2.htm# At the application layer, this is an example of a real network protocol stack; we may use an application layer protocol such as HTTP. We’ll jump right to the transport layer, where TCP (transmission control protocol) may be used, followed by IP and the Internet Protocol. Our IP network might be built on top of Ethernet, with an Ethernet data link layer and 1000 base-T connections as our physical layer. 2.1 Transmission Control Protocol (TCP) The core protocol of the Internet Protocol Suite is Transmission Control Protocol (TCP). The Transmission Control Protocol (TCP) is a network protocol that works in conjunction with the Internet Protocol. TCP/IP stands for Transmission Control Protocol/Internet Protocol Suite. TCP is a protocol that allows an octet stream (8-bit data block) to be securely delivered across an IP network. The ability to send orders and check for mistakes is TCP’s key feature. TCP is used by every major Internet application, including the World Wide Web, email, and file transmission. 2 .2 Internet Protocol (IP) For transporting data over a network, the Internet Protocol is the most important protocol in the Internet protocol suite. The Internet Protocol’s routing function fundamentally aids in the establishment of the Internet. This protocol was previously known as the Transmission Control Program’s connectionless datagram service (TCP). As a result, TCP/IP is another name for the Internet protocol suite. 2.3 Hypertext Transfer Protocol (HTTP) HTTP stands for Hypertext Transfer Protocol, and it is an application protocol for networked, collaborative, hypermedia information systems. The World Wide Web’s data communication is built on the HTTP protocol. Hypertext is a type of organized text that employs hyperlinks to connect text nodes. HTTP is the industry standard for exchanging and transferring hypertext. 2.4 Domain Name System (DNS) Domain names are converted to IP addresses via the Domain Name System (DNS). The DNS system is hierarchical, with the server root, TLD, and authorisation server all being listed.
2.5 Internet Control Message Protocol (ICMP) The ICMP protocol is used to convey network error signals. It utilizes the IP protocol. It assists in the diagnosis of network communication problems. ICMP is mostly used to evaluate whether data is reaching its intended destination in the most efficient manner. 2.6 Dynamic Host Configuration Protocol (DHCP) This protocol operates on IP networks, allocating IP addresses to networked devices and hosts. It also permits them to converse effectively with one another. DHCP assigns the subnet mask, default gateway address, domain name server (DNS) address, and other setup information in addition to the IP address. 2.7 Simple Network Management Protocol (SNMP) To administer the network, a basic network management protocol is employed. Monitoring, setting, and managing device networks are all possible with SNMP. On the device network, you may also set up SNMP traps to alert the server hub when the tool is ready to use. 2.8 Hypertext Transfer Protocol over SSL/TLS (HTTPS) HTTPS is used in conjunction with HTTP to provide similar services with the added security of SSL or TLS. 2.9 Secured Shell (SSH) SSH is the most used mechanism for securely manipulating network devices at the command level. Because Telnet does not provide secure connections, SSH is frequently used as an alternative.
3. International Networking Standards Organizations American National Standards Institute (ANSI) The American National Standards Institute (ANSI) is the main organization in charge of organizing and releasing computer and information technology standards in the United States. Information Technology Industry Council (ITIC) The Information Technology Industry Council (ITIC) is an association of several dozen companies in the information technology (computer) industry. ITIC is an ANSI-approved standards development organization (SDO) that develops and processes standards on a wide range of computer-related issues. National Committee for Information Technology (NCITS) The ITIC formed a committee to define and maintain information technology standards. It has multiple subcommittees that produce and maintain technical standards. Institute of Electrical and Electronics Engineers (IEEE) The IEEE (pronounced “eye-triple-ee”) is a well-known professional association for persons working in electrical and electronic sectors, such as computers and networking. Electronic Industries Alliance (EIA) The EIA is an international industry that publishes electrical wiring and transmission standards. Telecommunications Industry Association (TIA) ITU-T is another large international body that develops standards for the telecommunications industry. The ITU-T was formerly named the International Telephone and Telegraph Consultative Committee or CCITT International Telecommunication Union – Telecommunication Standardization Sector (ITU-T) The Multinational Telecommunication Union (ITU-T) is another big international organization that creates standards for the telecommunications sector. The International Telephone and Telegraph Consultative Committee, or CCITT, was the previous name for the ITU-T.
Figure 6 : Star Topology Source: https://www.totolink.vn/article/59-cac-kieu-topology-cua-mang-lan.html Advantages: Devices may be added, uninstalled, or upgraded without slowing down the central hub. Installing and modifying it is simple. The topology may be configured with less cabling. Troubleshooting is simple. It’s simple to remove parts and spot flaws. Disadvantages: All linked nodes are deactivated if the central hub fails. More cable length is required than with linear topologies. The hub’s efficiency, power, and arrangement determine its performance.
2 4 .1 Star Topology
This is a sort of topology in which all devices, such as servers, workstations, and information nodes, are connected to one another via a single main cable for data transmission. Two terminator devices seal the cable’s two ends. The destination’s particular address is carried in the data and signals transferred across the cable. Figure 7 : Bus Topology Source: https://www.totolink.vn/article/59-cac-kieu-topology-cua-mang-lan.html Advantages: It’s ideal for small network configurations.
It is possible to link the needed nodes using less cable. Allows for the expansion or contraction of a network. Affordability Simple to comprehend Disadvantages:
- Because determining the cause of the problem is hard, the system must be shut down for inspection and recovery.
- It is simple to cause state congestion on the transmission line while transferring data with a big volume of storage.
2.4.3 Ring Topology
A ring topology’s nodes are organized in a circle (or ring). Data can flow in either one or both ways throughout the ring network, with each device having exactly two neighbors. Figure 8 : Ring Topology Source: https://www.totolink.vn/article/59-cac-kieu-topology-cua-mang-lan.html Advantages: Implementation costs are low. Better than bus topology in terms of performance and ability to function under large loads. Orderly network flow. It’s easy to spot flaws and misconfiguration. Disadvantages: The network must be turned off before adding, deleting, or configuring nodes. A single defective node may destroy the entire network. The network can be disrupted if a transmission line fails.
2.4.4 Mesh Topology
Mesh network is a type of Topology in which each computer is connected to all other computers on the network without the use of a hub or switch. Mesh topologies feature a web-like topology that allows for both routing and flooding of data. Its structure is comparable to that of the internet today.
The method of installation is complicated. Designing and maintaining it is difficult. Costly. In order to link one topology to another, hardware must be changed.
2.4.6 Tree Topology
The tree topology structure takes its name from the fact that the central node acts as a network’s trunk, with nodes extending outward in a branch-like pattern. In a star topology, each node is connected directly to the central hub, whereas in a tree topology, the nodes are connected in a parent-child hierarchy. Those connected to the central hub are linked to other nodes in a linear way, thus two connected nodes share just one connection. The tree topology structure is frequently used for wide area networks to handle numerous spread-out devices since it is both incredibly flexible and scalable. Figure 11 : Tree Topology Source: https://boxhoidap.com/overview-of-network-topologies Advantages: Combination of bus and star topologies. Easy to manage. It is simple to enlarge. Appropriate for medium-sized enterprises. Disadvantages: The network is reliant on the root node’s health. Expertise in networking is required. There’s a lot of cable involved. Larger deployments necessitate the use of monitoring software. It’s possible to overspend. 3. Communication Network communication, also known as internetworking, refers to a collection of protocols (i.e., rules and standards) that enable application programs to communicate with one another regardless of the hardware or operating systems they are running on. Application programs can interact through the internet regardless of their actual network connectivity. 4. Rules of Communication Message Encoding:
- The format of the encoding between hosts must be acceptable for the medium. The transmitting host converts messages into bits first. Depending on the network media, each bit is encoded as a sequence of noises, light waves, or electrical impulses. To comprehend the message, the destination host receives and decodes the signals. Message Formatting and Encapsulation:
- For appropriate delivery, there is an agreed-upon structure for letters and addressing letters. Encapsulation is the process of placing a letter into an addressed envelope. Before being delivered over the network, each computer communication is contained in a precise format known as a frame. A frame functions as an envelope, containing both the destination and source addresses. Message Size: Long messages are broken down into smaller chunks or phrases by humans. To travel over a network, long messages must be broken down into smaller parts. Each item is encased in its own frame. Each frame contains its own set of addressing data. Multiple frames will be reconstructed into the original message by the receiving host. Mesage Timing:
- Access Method: Hosts on a network must understand when to start transmitting messages and how to handle collisions.
- Flow Control: To prevent overloading the destination and guarantee that information is received, source and destination hosts utilize flow control to negotiate precise timing.)
- Response Timeout: Network hosts have rules that govern how long they should wait for responses and what they should do if a response timeout occurs. Figure 12 : Network layer protocols forward encapsulated Transport Layer 5. Bandwidth The ability of a wired or wireless communications link to send data through a network connection in a certain length of time is measured in network bandwidth. The amount of bits, kilobits, megabits, or gigabits that can be communicated in one second is commonly used as a measure of bandwidth. Data transfer rate is defined by bandwidth, which is synonymous with capacity. It’s a popular misperception that bandwidth is a measure of network speed.
