ASSIGNMENT 1 FRONT SHEET
Qualification BTEC Level 5 HND Diploma in Computing
Unit number and title WEBG301: Project Web
Submission date 4/29/2023 Date Received 1st submission
Re-submission Date Date Received 2nd submission
Student Name Dao Dinh Duc Student ID GCH
Class GCH1103 Assessor name Dinh Duc Manh
Student declaration
I certify that the assignment submission is entirely my own work and I fully understand the consequences of plagiarism. I understand that
making a false declaration is a form of malpractice.
Student’s signature
Grading grid
Grade (0-10)
Summative Feedback: Resubmission Feedback:
Grade: Assessor Signature: Date:
Lecturer Signature:
- Because the user needs to filter products by category, so that they can quickly find products
in specific categories.
- Because the user needs to add products to their shopping, Carts that they can keep track of
products they want to buy.
- Because the user needs to track their orders, so that they can see the status of their orders
and know when to expect their products.
Guest:
- Because the guest needs to see the home page of the store, so that they can view information
about the store and its products.
- Because the guest needs to register an account to become a member, so that they can access
additional features and make purchases.
- Because the guest needs to log in to their account, so that they can access their profile and
shopping cart.
Chapter 2 – System Design
2.1. Site map
FIGURE 1 SITE MAP
2.2. Entity Relationship Diagram
FIGURE 2 ERD
FIGURE 3 DATA TABLE RELATIONSHIP IN MYSQL SERVER (PHP MYADMIN)
$table->timestamps(); ///foreign key $table->foreign('cart_ID')->references('id')->on('carts')- >onDelete('cascade'); $table->foreign('product_ID')->references('id')->on('products')- >onDelete('cascade'); }); } /**
- Reverse the migrations.
- @return void */ public function down() { Schema::dropIfExists('cart_product'); } }; First thing after I have designed the data to generate the data for the whole site in the migrations section in the database. It will include all the relevant data like the Figure 3 table. In the data there are defaults including data types, foreign keys, and attributes like onDelete, default(1)... 2.model php namespace App\Models; use Illuminate\Database\Eloquent\Factories\HasFactory;
use Illuminate\Database\Eloquent\Model; use App\Models\Category; use App\Models\Order; use App\Models\Cart; class Product extends Model { use HasFactory; protected $table = 'products'; protected $fillable = [ 'name','quantity','image', 'price', 'description' ]; public function categories() { return $this->belongsToMany(Category::class, 'category_product')- >withTimestamps(); } public function orders() { return $this->belongsToMany(Order::class, 'order_product')->withTimestamps()- >withPivot('quantity'); } public function carts() { return $this->belongsToMany(Cart::class, 'order_product')->withTimestamps()- >withPivot('quantity'); } } I will then design the models to hold all the relevant data and return types while using the data in the Controller. Here is an example of how I created the product model and its related data such as belonging, data table to populate and where to get the data.
use App\Models\CartProduct; use App\Models\OrderProduct; use Illuminate\Support\Facades\DB; use Illuminate\Http\Request; use Illuminate\Support\Facades\Auth; use Illuminate\Support\Facades\Validator; class OrderController extends Controller { /**
- Display a listing of the resource.
- @return \Illuminate\Http\Response */ public function index() { $order = Order::all(); return response()->json([ 'success' => true, 'data' => $order, ], 200 ); } public function indexAutoLoadOrders() { // $orders = Order::latest(); $orders = OrderController::getUser()->paginate( 16 ); return view('admin.orders.index', compact('orders')); } public function indexAutoLoad() { // $orders = Order::where('user_ID','=',Auth::user()->id); //check orders and create getOrder to collect data $orders = OrderController::getOrder(Auth::user()->id); return view('profile.order', compact('orders')); }
public function checkout(Request $request) { $user_id = Auth::user()->id; $order['user_ID'] = $user_id; $order['total'] = $request['total']; $order['status'] = 0 ; $cart = Cart::where('user_id', '=', $user_id)->get(); if ($order['total'] != 0 ) { // save order $order = Order::create($order); $cartProducts = CartProduct::where('cart_ID', '=', $cart[ 0 ]->id)->get(); foreach ($cartProducts as $cartProduct) { $orderProduct['order_ID'] = $order['id']; $orderProduct['product_ID'] = $cartProduct['product_ID']; $orderProduct['quantity'] = $cartProduct['quantity']; OrderProduct::create($orderProduct); $cartProduct->delete(); } } return view('cart.detail', compact('cart')); } /**
- Store a newly created resource in storage.
- @param \Illuminate\Http\Request $request
- @return \Illuminate\Http\Response */ public function store(Request $request) { $validator = Validator::make($request->all(), [ 'user_ID' => 'required|exists:users,id', 'total' => 'required|decimal:0,5', 'status' => 'required|decimal:0,5' ]); if ($validator->fails()) { return response()->json([
- Remove the specified resource from storage.
- @param int $id
- @return \Illuminate\Http\Response */ public function destroy(Order $order) { } protected static function getOrder($user_id) { return DB::table('orders')->where('user_id', '=', $user_id)
- >leftJoin('order_product', 'order_product.order_id', '=', 'orders.id')
- >leftJoin('products', 'order_product.product_id', '=', 'products.id')
- >select('order_product.product_id', 'order_product.quantity', 'order_product.order_ID', 'products.name', 'products.price', 'orders.total', 'orders.status')
- >get(); } protected static function getUser() { return DB::table('orders')
- >leftJoin('users', 'orders.user_id', '=', 'users.id')
- >select('orders.id', 'orders.user_ID', 'orders.total', 'orders.status', 'users.address', 'users.phone'); } } In the Order section, I used conditions to check and load related orders. Some tables will use data directly from the database through table concatenation. In addition, in this section, I used to create an item that is checkout, the effect is that after the user clicks on checkout in the author view, all products will be placed in the order. There the order will get important information such as quantity, total price, and create status for the order. B, view order
Back
ID User_ID Address Phone Status {{-- Created At Updated At --}} Action
@foreach ($orders as $order)
{{ $order->id }} {{ $order->user_ID }} {{ $order->address }} {{ $order->phone }}
@if ($order->status == 0 )
Canceled
@endif
@if ($order->status == 0 )
@csrf @method('put')
Confirm Payment
@endif @if ($order->status == 1 )
@csrf @method('put')
Confirm Delivered
@endif
@endforeach
@if ($orders->links())
{{ $orders->links() }}
@endif
After creating the order, the web owner can check to see if there are orders by whom and where. In addition, they can adjust the status and confirm the order has been delivered.
Items: {{ $items }}
Tax (5%): $ {{ $tax = ($total / 100 ) * 5 }}
Total:
{{ $order->total }}
@if ($order->status == 0 )
Pending
@elseif($order->status == 1 )
Accecpted
@elseif($order->status == 2 )
Delivered
@elseif($order->status == 3 )
