CS6310 – Software Architecture & Design Assignment #3 [150 points]: Streaming Wars Project – Individual Implementation (v2) Spring Term 2021 – Instructor: Mark Moss Submission Deliverables This assignment must be completed as an individual, not as part of a group. You must submit the following items in Canvas: (1) A ZIP file named 2021-01-A3.zip that includes your source code. The structure of the zip file is shown in more detail below. (2) An updated copy of the UML Design Class Diagram from the earlier assignment reflecting any problem requirement updates as described below, named class_diagram.pdf. (3) A UML Sequence Diagram that captures the sequence of actions described below, named sequence_diagram.pdf. You must notify us via a private post on Canvas and/or Piazza BEFORE the Due Date if you are encountering difficulty submitting your project. You will not be penalized for situations where Canvas is encountering significant technical problems. However, you must alert us before the due date – not well after the fact. You are responsible for submitting your answers on time in all other cases. Please consider that uploading files to Canvas might occasionally take a long time, even in the case of seemingly “relatively small” submissions. Plan accordingly, as submissions outside of the Canvas Availability Date will likely not be accepted. You are permitted to do unlimited submissions, thus we recommend you save, upload and submit often. You should use the same file naming standards for the (optional) “interim submissions” that you do for the final submission. General Intent In the first phase of the Streaming Wars Project, you were required to provide design artifacts to describe your approach to structuring the classes, attributes, operations, methods and relationships needed to simulate the problem. Now, you are required to provide a lightweight implementation of the system in Java that reflects your design. You are required to demonstrate fundamental separation of classes in your source code indicative of a reasonable design. This means that your source code should show some indication of being divided up into classes, files, etc. that match your design. You will lose points if you submit poorly structured code. And don’t panic if you realize that your original design had flaws while working on this assignment – this is common for “agile styles” of development. Make sure that your implementation works per these requirements and specifications and note your earlier design oversights with some brief comments in your code. You’re also being asked to provide improved design artifacts based on your “revised and improved understanding” of the problem space, and especially in light of the problem requirement changes included in this document. We provide some examples of the expected input and output for a few test cases. You must provide the actual Java source code, along with all references to any external packages that you used to develop your system. You must also provide an executable JAR file to support the testing and evaluation of your system. We must also be able to recompile your application from your source code as part of the evaluation process. Problem Scenario Your requirements for the Streaming Wars Project are continued here. Any requirements from the earlier assignments are carried over here unless explicitly modified and/or otherwise cancelled. If you feel that there
are any conflicts between any of the earlier requirements and the more recent requirements, then please seek clarification immediately. In general, though, the newer requirements will take precedence. This assignment involves implementing some of the core architecture and functional capabilities for the Streaming Wars Project that you designed in the earlier assignments. Your system must implement the following functionality: (1) The system must initialize the current month and year as 10 (October) and 2020, respectively. (2) The system must allow the user to create demographic groups, streaming services, movies, Pay-Per-View events, and studios. (3) The system must allow streaming services to offer movies and Pay-Per-View events. (4) The system must allow portions of a demographic group to view a streaming service offering. (5) The system must allow the user to advance the time period to the next month. (6) The system must calculate and display the monies spent by the demographic groups, and the monies collected by the streaming services and studios for: (a) the current time period; (b) the previous month; and, (c) the total since the start of the program run. Your system does not have to produce a graphical display. At this point, we will evaluate your system based on the text-based output and the structure of the source code. You’ll have ample opportunity to develop a more advanced graphical user interface during the group project. Evaluation/Grading Your Submissions Your submission will be evaluated based on four main areas: (1) 20 points for your system’s correctness: source code provided, working JAR file, the capability to recompile your code if necessary, etc. (2) 40 points for correct operation of the system on the selected scenario (test) files (3) 50 points for reasonably structured source code (4) 40 points for your updated Class & Sequence diagrams Don't lose sight of the goal for the course: there are many more potential improvements that you could make to this system, but you really need to think about how you will separate and distribute the complexity of the overall problem across separate classes; and, how the objects instantiated from those classes then communicate and collaborate to solve the problem. Helping you develop a solid structure for your design is the most important aspect of working on this assignment. (1) 20 points for your submission correctness: working JAR file, the capability to recompile your code if necessary, etc. Common issues that cause you to lose points in this category: Not submitting a working JAR file The JAR file doesn’t function properly on the VM during testing – for example, JNI errors, etc. Gross formatting errors – we’ve designed the testing harness to be as robust as possible when processing the submissions, but errors caused by including graphical displays of the space region, diagnostic output, and other random messages will also cause you to lose points. Formatting is important! Syntax is important! Use the matching characters for the output strings, and don’t put extra spaces between elements of the output strings. Strings that do not match the correct output because of formatting (syntax) errors might receive significant penalties. (2) 40 points for correct operation of the system on the selected scenario (test) files
create_event,movie,Mulan,1998,88,disney, This command must create a movie named Mulan that is 88 minutes long and was produced in the year 1998 by the disney studio. Also, any streaming service that wants to offer this movie must pay the studio $1, USD per month as the licensing fee. Similarly, create_event,ppv,30 for 30: Monaco,2020,106,espn, This command must create a PPV event named 30 for 30: Monaco that is 106 minutes long and was produced in the year 2020 by espn studio. Also, any streaming service that wants to offer this PPV event must pay the studio $3,300 USD as the licensing fee. Of course, this is an example – if there is no valid studio for the short name espn, then this PPV event should not be created. [4] create_stream,,, This command must create a streaming service with the given short name, long name and monthly subscription price. The short name must be unique for all streaming services. For example: create_stream,apv,Amazon Prime Video, This command must create a streaming service that can be referenced in later commands using the short name apv, with a long name as shown above and a subscription price of $12 USD per month. [5] offer_movie,,, This command must create a listing for the designated streaming service that allows prospective viewers (i.e., portions of demographic groups) to access and watch the movie. If either the streaming service or movie name reference is invalid, then this command should be considered invalid, and the listing should not be created. For example: offer_movie,apv,Mulan, This command must create a listing that allows viewers to subscribe to the apv streaming service to access and watch the 1998 version of the movie Mulan. Also, from an accounting or billing perspective, this means that the disney studio, which produced the movie, has earned $1,000 USD in licensing fees for that month for this offering. [6] offer_ppv,,<pay-per-view name>, , This command must create a listing for the designated streaming service that allows prospective viewers (i.e., portions of demographic groups) to access and watch the Pay-Per-View event for the designated price. If either the streaming service or pay-per-view name reference is invalid, then this command should be considered invalid, and the listing should not be created. For example: offer_ppv,net,30 for 30: Monaco,2020, This command must create a listing that allows viewers to access and watch the Pay-Per-View event 30 for 30: Monaco via the Netflix (net) streaming service for the cost of $57 USD. Also, from an accounting or billing perspective, this means that the espn studio, which produced the Pay-Per-View event, has earned $3,300 USD in licensing fees for that month for this offering. [7] watch_event,,, ,, This command must create a transaction such that some percentage of the accounts in the designated demographic group have decided to access and watch the movie or Pay-Per-View event being offered on the streaming service. As with most commands, if the references to the demographic, streaming service or event
are invalid, then this command should also be considered invalid. Similarly, if the streaming service is not offering the designated event, then the command should be considered invalid. For example:
watch_event,age_40_50,30,apv,Mulan, This command must create a transaction such that 30% of the accounts in the age_40_50 demographic have accessed and watched the Mulan movie via the apv streaming service. From an accounting or billing perspective, this means that 0.30 * 800 = 240 accounts have had to subscribe to the apv service such that the apv service has earned 240 * $12 USD = $2,880 USD in subscription fees, assuming that this is the first movie for those subscribers during the current month. We are going to make an assumption to make the calculations at this phase of the project a bit simpler. Suppose the age_40_50 demographic decides to watch more movies from the apv streaming service during the current month. Let the next relevant command be: watch_event,age_40_50,50,apv,Beauty and the Beast, We will always make the assumption that the percentage of accounts viewing the movie includes as many previous subscribers as possible. In this case, since 240 accounts (30% of the group) already watched a movie, then we'll assume that they are among the 50% of the movie watcher in this current command. Consequently, we will only need to charge more subscription fees for the "new 20%" of the accounts (50% * 800 – 240 = 160) that are watching this second movie. Just to complete the example, let the next relevant command be: watch_event,age_40_50,40,apv,The Little Mermaid, Once again, we will always make the assumption that the percentage of accounts viewing the movie includes as many previous subscribers as possible. In this case, since 50% of the group has already paid subscriber fees, we will safely assume that the 40% who are watching the third movie have all already subscribed to the apv streaming service, and so there are no new subscription fees to be collected. [8] next_month This command advances the calendar to the next calendar month. If the current time period is 8/2020, then the next time period will be 9/2020. If the current time period is 12/2020, then the next time period will be 1/2021. The system will start with default time period of October 2020 (10/2020). This change in time period has implications for state of the system. All creation actions that have been executed successfully – to include creating demographic groups, streaming services, studios, movies and Pay-Per-View Events – must automatically persist from month to month. They do not need to be recreated each month. The movies and Pay-Per-View events that were offered via the offer_movie and offer_ppv commands must be cancelled automatically at the end of the month. They can and should be recreated as needed by the streaming services. All watch_event commands are "singular actions", and only pertain to viewers watching a designated event during the month where the command was executed. There is no obligation for viewers to watch events from the same streaming service – or any streaming service for that matter – during the following month. This also means that subscriptions are charged month by month: if viewers do not watch any movies from a particular streaming service during the month, then they must not be charged the subscription fee for that streaming service for that month. [9] display_demo, This command displays information about the demographic group that is referenced by the provided short name. The command must display the information in this format:
[12] display_events This command displays all of the movies and Pay-Per-View events that have been produced by the studios. The requests must be listed in the order that they were entered. The command must display the information in this format: ,,,,, ... ,,,,, Consider the following example:
display_events movie,Mulan,1998,88,disney, ppv,30 for 30: Monaco,2020,106,espn, movie,The Little Mermaid,1989,83,disney, movie,Beauty and the Beast,1991,84,disney, ppv,MMA Championship,2020,121,espn, [13] display_offers This command displays all of the license requests made from the streaming services to the studios for various movies and Pay-Per-View events. The requests must be listed in the order that they were entered. The command must display the information in this format: ,,,,<subscription price (only) if ppv> ... ,,,,<subscription price (only) if ppv> Consider the following example: display_offers apv,movie,Mulan, apv,movie,The Little Mermaid, apv,movie,Beauty and the Beast, net,ppv,30 for 30: Monaco,2020, [14] display_time This command displays the month and year for the current time period in this format: time,, Consider the following example: display_time time,1, [15] stop This command simply causes the (otherwise infinite) interactive loop to halt. Additional commands to create, update, delete and display elements of the system will be added during later phases of the project. Sample Code
We've included some sample Java source "shell code" that you may use to better understand the problem space and some of the details in the calculations. The code, though not necessarily well-designed, does perform the required commands correctly.
You are also welcomed to use portions of the code in your own solution, but please note that this code is deliberately not "well designed" by object-oriented standards. If you simply submit this code back to us as your solution, you will most likely forfeit all of the points for having a well-designed solution, and it's also likely you'll lose more points because the code won't match your Class & Sequence Diagrams. Also, use of the provided shell code is 100% optional: you are NOT required/obligated to use this code. If you would like to take a closer look at the shell code, then the best way might be to create a new Java project with blank Main and TestCodeReader files, and then import the provided content. Similarly, you can compile and experiment with the code, and create a new JAR file as well. We've also provided an initial copy of the JAR file that can be executed in two ways: [1] Interactive (Type in the commands yourself one by one): $ java -jar streaming_wars.jar create_demo,age_40_50,Viewers between 40 and 50,
create_demo,age_40_50,Viewers between 40 and 50, display_demo,age_40_ display_demo,age_40_ demo,age_40_50,Viewers between 40 and 50 size, current_period, previous_period, total, ... display_stream,net display_stream,net stream,net,Netflix subscription, current_period, previous_period, total, licensing, stop stop $_ [2] Scripted (Enter the commands into a text file as demonstrated with the provided example): $ java -jar streaming_wars.jar < streaming_wars_test.txt create_demo,age_40_50,Viewers between 40 and 50, display_demo,age_40_ demo,age_40_50,Viewers between 40 and 50 size, current_period, previous_period, total, … display_stream,net stream,net,Netflix subscription, current_period, previous_period, total,
questions or comments contain information that specifically provides an answer for some part of the assignment, then please make your post private first, and we (the OMSCS 6310 Team) will review it and decide if it is suitable to be shared with the larger class. Best of luck on to you this assignment, and please contact us if you have questions or concerns.
