Registration of patient o Pre condition: you have to login first. o Use case: Registration of patient o Actors: Medical Receptionist o Purpose: To have a Complete record of Patient. o Overview: o Type: Primary o Post Condition: No Typical Course of Events: Step 1: Actor action: click on login option/ if not regester then regester first. System Response : login page wil be open. Step2: o Actor action: enter info of Medical Receptionist System Response: no Step3: Actor action; press ok System Response: save info. Step Actor actionClick registration of patient System Response:page is open View record of Patient o Pre condition: login o Use case: View record of Patient o Actors: Medical receptionist o Purpose: view personal information of Patient o Overview: You can see all information of patient e.g personal and all medical history of Patient o Type: Primary o Post Condition:
