Binary Search Trees

Reflecting on Dictionaries

Cost

 Hash dictionaries are clearly the best implementation

 O(1) lookup and insertion are hard to beat!

or are they?

 It’s O(1) average

o we could be (very) unlucky and incur an O(n) cost

 e.g., if we use a poor hash function

 It’s O(1) amortized

o from time to time, we need to resize the table

 then the operation costs O(n)

 Operations like finding the entry with

the smallest key cost O(n)

o we have to check every entry

Always read

the fine prints!

Always read

the fine prints!

Using hash dictionaries is too risky

or not good enough

for applications that require a

guaranteed (short) response time

But they are great for applications that don’t have such constraints

 Develop a data structure that has guaranteed O(log n)

worst-case complexity for lookup, insert and find_min

 always!

o O(1) would be great but we can’t get that Unsorted array Array sorted by key Linked list Hash Table

lookup O(n) O(log n) O(n) O(1)

average

O(log n)

insert O(1)

amortized

O(n) O(1)

O(1)

average and amortized

O(log n)

find_min O(n) O(1) O(n) O(n) O(log n)

Goal

ExerciseExerciseExerciseExercise

Returns the

entry with the

smallest key

Searching Sorted Data

Searching for a Number

 Consider the following sorted array

 When searching for a number x using binary search,

we always start by looking at the midpoint, index 4

 Then, 3 things can happen

o x = 12 (and we are done) o x < 12 o x > 12

We always look

at this element

0 1 2 3 4 5 6 7 8 9

• 2 0 4 7 12 19 22 42 65 12

Searching for a Number

 Assume x < 12, so we look at 4

o if x = 4, we are done o if x < 4, we necessarily look at 0 o if x > 4, we necessarily look at 7

Then, we may look

at these elements

0 1 2 3 4 5 6 7 8 9

• 2 0 4 7 12 19 22 42 65 if x > 12 if x < 12 if x < 4 if x > 4 0 7

0 1 2 3 4 5 6 7 8 9

• 2 0 4 7 12 19 22 42 65 Searching for a Number

 Assume x < 4, so we look at 0

o if x = 0, we are done o if x < 0, we necessarily look at - 2

Then, we may look

at this element

if x > 12 if x < 12 if x < 4 if x > 4 if x < 0

Searching for a Number

 An array provides direct access to all elements

o This is overkill for binary search o At any point, it needs direct access to at most two elements 0 1 2 3 4 5 6 7 8 9

• 2 0 4 7 12 19 22 42 65

if x > 12 if x < 12 if x < 4 if x > 4 if x < 0

if x < 42 if x > 42 if x < 22

Searching for a Number

 We can achieve the same access pattern by pairing up

each element with two pointers

o one to each of the two elements that may be examined next

 We are losing direct access to arbitrary elements,

o but it retains access to the elements that matter to binary search

Arrays gave us

more power

than needed

Constructing this Tree

 Let’s build the first

few nodes of this

example

tree* T = alloc(tree);

T->data = 12;

T->left = alloc(tree);

T->left->data = 4;

T->right= alloc(tree);

T->right->data = 42;

T->left->left = alloc(tree);

typedef struct tree_node tree; struct tree_node { tree* left; int data; tree* right; }; 12 4 42 22 65 19

left data right

T

The End of the Line

 What should

the blank

left/right

fields

point

to?

o NULL

 each sequence of left/right pointers works like a NULL-terminated list

o a dummy node

 not very useful here

typedef struct tree_node tree; struct tree_node { tree* left; int data; tree* right; }; 12 4 42 22 65 19

left data right  

We used dummy nodes to get

direct access to the end of a list

Searching

 Searching for 5

o 5 < 12: go left o 5 > 4: go right o 5 < 7: go left

 nowhere to go

o not there

 We are doing the same steps as binary search

 Starting from an n-element array, the cost is O(log n)

left data right 

If the tree is obtained

18 as in this example

 Develop a data structure that has guaranteed O(log n)

worst-case complexity for lookup, insert and find_min

 always!

o lookup has cost O(log n) o What about insert and find_min? Target data structure

lookup O(log n)

insert O(log n)

find_min O(log n)

Recall our Goal  in this setup
