Download ANSYS Analysis: Turbine Blade Deflection - Static, Dynamic, FSI & Results and more Slides Physics in PDF only on Docsity!

2

Contents

Introduction

Strategy

Static Analysis of Turbine Blade

Dynamic Analysis of Turbine Blade

1

2

3

4

Fluid Structure Interaction

Blade Deflection

5

6

7 Summary

4

Objective

Using ANSYS the deflected blade shape will be obtained and the variation between the designed and deflected shape will be studied

5

Strategy

Strategy adapted to attain the desired objective consists of following steps:  Basic Study of Turbines  Study of Coupled Field Analysis in ANSYS  Blade Profile & Fluid domain Modeling in ANSYS  Static Analysis of Turbine Blade  Dynamic Analysis of Turbine Blade  Coupled field analysis using ANSYS  Study of deflected blade profile

7

Blade Profile Specifications

 Designed blade profile specifications are:

Blade Inlet Angle 21 o Blade Exit Angle 54 o Chord length 2.87 cm Blade Height 3.44 cm Blade Pitch 3.44 cm

ANSYS Analysis

Analysis consists of following steps:

 Modeling  Boundary Conditions  Reference Conditions  Solution  Results

10

Modeling

Passing B Spline

KSEL,S,,,2, BSPLIN,ALL

KSEL,ALL BSPLIN,109,110,115,1,

Cont…

11

Modeling

Blade Area was created using B-Splines

AL,ALL

Cont…

13

Modeling

Fluid Channel was modeled keeping in mind the inlet and exit angle

Cont…

14

Modeling

Blade areas were subtracted from channel area as they were of different materials

Cont…

16

Modeling

The complete geometry was extruded to a depth of same as blade height

Cont…

Static Analysis

Analysis Type:  Steady State  Adiabatic  Compressible  Turbulent

Fluid Properties:  Density : AIR-SI  Conductivity : AIR-SI  Viscosity : AIR-SI  Specific Heat : AIR-SI  Density Variations: Yes

Termination Criteria

 Pressure : 1 x 10-05^ Pa

Temperature : 1 x 10-06^ K

Velocity : 1 x 10-02^ m/sec

Global Iterations: 50

Stability Parameters

 MIR Stabilization

 Turbulence Equation : 0.  Momentum Equation : 0.  Energy Equation : 0.

 Artificial Viscosity : 10 to 0
