Case Study
Engr Design
Potato Sorting Machine
- Optyx® WPS for whole potatoes
achieves a three-way sort using a
combination of air ejectors to
remove foreign material (FM) and a
unique deflector system to
separate potatoes for rework from
good potatoes. Maximizing the
removal of foreign material and
providing extremely gentle
handling to avoid potato bruising,
Optyx WPS improves product
quality and protects downstream
equipment while reducing labor
costs and increasing yields.
http://www.key.net/products/optyx/optyx-wps-sorter/default.html
Custom
Designed
DSP Card
Enclosure
(front)
Custom
Designed
DSP Card
Enclosure
(back)
Cooling Fans in Bottom Tray
Replaceable Cooling Air Filter
Engineering Build Doc Structure
Main Assy DWG(s) & BoM
Sub Assy-1. DWG(s) & BoM
Purchased Parts
Sub Assy-1. DWG(s) & BoM
Purchased
Parts
Designed Fab Parts
Designed Fab Parts
Sub Assy 2. DWG(s) & BoM
Purchased Parts
Designed Fab Parts
Sub Assy 3. DWG(s) & BoM
Purchased Parts
Designed Fab Parts
Purchased Parts
Designed Fab Parts
Sub Assy 4. DWG(s) & BoM
Purchased Parts
Designed Fab Parts
Printing Instructions
- Print White-
BackGround slide
using PURE BLACK
& WHITE print-
setting
Posted to WebPage
Project-Useful Suppliers Bold
Ite
m
Supplier Name Supplier Ph. Supplier Address
1 Arrow Electronics 408.330.4098 Santa Clara, CA
2 MDC Vacuum Products 510-265-3500 23842 Cabot Boulevard * Hayward, CA 94545-
3 MDC Vacuum Products 510-265-3501 23843 Cabot Boulevard * Hayward, CA 94545-
4 E. M. Jorgenson Co. (510) 487 - 2700 31100 Wiegman Rd * Hayward, CA 94544
5 A. M. Castle 209.944.1100 1625 Tillie Lewis Dr * Stockton, CA 65206
6 Golden Gate Baldor 510.785.9900 21056 Forbes Ave* Hayward, CA 94545
7 Tap Plastics 510.357.3755 3011 Alvarado Street * San Leandro, CA 94577
8 McMaster-Carr 562.692.5911 9630 Norwalk Blvd * Santa Fe Springs, CA 90670-
9 OMEGA Engineering, INC. 800.826.6342 One Omega Drive * Stamford, Connecticut 06907-
10 W.W. Grainger, Inc (510) 670-1095 1617 Industrial Pkwy. W.* Hayward, CA 94544-
11 Newark Electronics (650) 812-6300 3032 Bunker Hill Lane #202 * Santa Clara, CA 95054
12 Orchard Supply Hardware (510) 278-7300 177 Lewelling Boulevard * San Lorenzo, CA 94580
13 Motion Industries (510) 266-0200 28976 HOPKINS ST, STE H * HAYWARD, CA 94545
14 Swagelok Sunnyvale^ 408-734-3145^ 929 Weddell Court * Sunnyvale, CA 94089
15 PIC Design Inc. 800-243-6125 86 Benson Rd. * Middlebury, Ct. 06762
Posted to WebPage
- Students to Make Own DWG No. System
Size DWG No. Description Notes
D 967541 Main Assy, 9U VME Card Cage Assy Custom Design per Spec
D 967542 TOP COVER ASSY,W/SWITCH
A 967543 BOTTOM PAN ASSY
D 967544 SIDE PLATE, 9UX12, 6U160, INJ/EJC
D 967545 AIR BAFF,17 X 3/8 X 0.
B 967546 DRIVE CAGE ASSY,SLIDE IN
B 967547 DOOR ASSY,FILTER/FAN
C 967548 FLP,ASSY,REAR,DRIVE BAY
D 967549 FLP-A,6UX4HP,1101.10,1W
D 967550 FLP-A,6UX8HP,1101.10,2W
D 967551 DRIVE CAGE DOOR ASSY
