Cluster analysis
The basic assumption with these methods is that
measurements made for related samples tend to
be similar.
Overall, the distance between similar samples is
smaller than for unrelated samples.
Clustering methods
We’ll look at three unsupervised clustering methods.
• Univariate clustering
• Evaluates individual variables (raw or scaled).
• Groups samples into homogeneous classes.
• Hierarchical cluster analysis
• Reduction of multiple variables for a sample to a single
‘distance’ value.
• Rank and link samples based on relative distances.
• k-mean clustering.
• Grouping of samples into a set number of classes.
• Use all variables to determine relative distances.
Univariate clustering.
• Creates ‘k’ homogeneous classes.
• Uses within-class variances as measure of
homogeneity.
• Can be used to convert quantitative variable into a
discrete ordinal variable.
• Another use is to simply evaluate if a variable has
any ‘classification’ type information.
Histogram (Petal width)
(^0 5 10) Petal width 15 20 25 30 Relative frequency
Iris dataset
Species Property
I. Setosa Petal width
I.Versicolor Petal length
I.Verginica Sepal width
! Sepal length
We’ll look at a single
property - petal width.
Univariate clustering.
Histogram (Petal width) 0
0 5 10 15 20 25 30 Petal width Relative frequency
The goal is to partition the data so that you have ‘k’
clusters of data.
Iris data
A simple ranking of the data
indicates that we would get
reasonable clustering based
on petal width.
Iris data Iris data
Body Temp (from exam)
Not exactly the best classification. It does show that there is some skew to the results (more men in class one and more women in class two) - and there is a fair amount of overlap.
So what’s it good for?
Really only useful for an initial evaluation of
individual variables.
Only want to use when you have a small number of
classes (or potential classes.
Main use is to convert quantitative (continuous) to
ordinal data.
HCA Distance and similarity
The first step in conducting HCA is to determine the
distance between your samples or variables.
Distance
City block
Euclidean
(most common)
d ij = ^ x ik - x jk h
M
8 B
j = 1
N
1/ M
d ij = ^ x ik - x jk h
8 B
j = 1
N
d ij = x ik - x jk
j = 1
N
! M=
M=
Distance and similarity
Actual distances between your samples will vary based
on the type and number of measurements present.
Similarity values are calculated to normalize the data
to a standard scale.
! For similar samples, sij approaches 1
! For dissimilar samples, sij approaches 0
s ij = 1 -
d max
d ij
Single link
We now have a
three member
cluster.
Lets skip a few
steps.
Single link
Now, our points have been linked into three clusters.
Single link
All points have now been linked.
Other linkage methods
Complete link
Linkage is based on the farthest point in a cluster
- gives a conservative linkage
d ij " C =0.5 d iC +0.5 d jC + d iC - d jC
Other linkage methods
Centroid link (Ward’s Method)
Linkage is based on the center of the cluster.
d ij " C =
ni + n j
ni d iC^2
ni + n j
n j d jC
2
ni + n j
ni n j d ij
2
HCA dendrograms
After conducting your linkage, you need a way to
visualizing the results.
Dendrograms can be used for this purpose and
provide a very simple two dimensional plot that
indicates clustering, similarities and linkages.
Dendrograms We can now see how our samples are linked. The higher the linkage level, the lower the similarity. 1.0 similarity 0. Dendrograms This plot appears to indicate that there are three groups of samples that can only be linked at very low similarity values. A B C D E F G H I J Dendrograms Lets look again at our single linkage example and see what the dendrogram would look like. Example dendrogram 1.0 similarity 0. A real example Substances commonly used as accelerants were assayed by capillary column GC / MS. At present, accelerants are identified based on boiling point range. ! Class assignments: A, B, C, D, E Goal: To determine if multivariate data treatment has the potential for classification of accelerants. Analysis conditions Neat samples were spiked with a known amount an internal standard. ! SP-5 25m x 0.2mm I.D. column ! 1 μl sample, 100:1 split injection ! 50 oC,5 min; 10oC/min ramp; hold at 250oC ! Total run time: 30 minutes ! Mass Range: 50-150 AMU ! ISTD: octadeuteronaphthalene
Raw - centroidal linkage Centroid, Raw e e e e e e e b b a a a a b a b b b b b b b b d d d d d d d d d d d d^ c^ c^ c^ c^ c^ c^ c^ c^ c^ c^ c
Similarity Raw - comparison Centroidal linkage appears to give the best results.
Single, raw
b b b b a a a a b a b b b b b b e e e e e e e d d d d d d d d d d d d^ c^ c^ c^ c^ c^ c^ c^ c^ c^ c^ c
Similarity
Complete, Raw
b b b b b b b b b b a b a a a a c c c c c c c c c c c e e e e e e e d d d d d d d d d d d d
Similarity
Centroid, Raw
e e e e e e e b b a a a a b a b b b b b b b b d d d d d d d d d d d d c c c c c c c c c c c
Similarity
Autoscaled - single link Single, Scaled b b b b b b b b b a a a b a a b e e e e e e e d d d d d d d d d d d d c c c c c c c c c c c
Similarity Autoscaled - complete link Complete, Scaled a a a b a a b b b b b b b b b b^ c^ c^ c^ c^ c^ c^ c^ c^ c^ c^ c e e e e e e d d d d d d d e d d d d d -0. -0. -0. -0.
Similarity Autoscaled - centroid link Centroidal, Scaled e e e e e e e d d d d d d d d d d d d a a a b a a b b b b b b b b b b c c c c c c c c c c c -0. -0.
Similarity Autoscaled - centroid link For this example, a centroid link best reflects what we already know about the data.
Centroidal, Scaled
e e e e e e e d d d d d d d d d d d d a a a b a a b b b b b b b b b b^ c^ c^ c^ c^ c^ c^ c^ c^ c^ c^ c
Similarity
Iris dataset A pretty famous data set published by R.A. Fisher, “The Use of Multiple Measurements in Axonmic Problems.” Anals of Eugenics, 7, 179-188 (1936). He measured four physical properties of iris to see if they could be used to classify any of three different species. Used length and width of the sepal and petal. Iris dataset ! Species Property ! I. Setosa Petal width ! I.Versicolor Petal length ! I.Verginica Sepal width ! Sepal length 150 samples - no missing values HCA analysis was conducted on both raw and scaled data. Both single linkage and complete linkage were evaluated. Autoscaled data, centroidal linkage (^0111111111111111111111111111111111111111111111111133333333333333333333333333333333122222232222222222322222233333332333232222222322323332222222222222222) 5 10 15 20 25 30 35 40 Dissimilarity One class is distinct but the other two overlap. Iris dataset So it should be possible to classify samples. HCA just does not provide as useful a view as we had hoped for. 5 10 15 20 25 15 30 45 60 Petal length P e t a l w i d t h Raw data. Iris dataset So there was useful information in the dataset. HCA - not a good tool. Reducing the four measurements into a single one actually make the data worse. Autoscaling - had little or no effect. The actual numbers were all of a similar range. Moral - just because a method doesn’t work does not mean that there is no useful information. Classification of Mycobacteria Investigators at the CDC wanted to see if it was possible to identify mycobacteria using pattern recognition of an HPLC analysis of mycolic acids. Mycobacteria - include a number of respiratory and non-respiratory pathogens such as M. tuberculosis. C 70 -C 90 α-branched β-hydroxy mycolic acids were selected as they are known to be in the cell walls of these bacteria.
Representative spectra, 47-99 m/e
Sulawesi (^) Costa Rica Ethiopia Sumatra Kenya Columbia
Single linkage
Sulawesi
Costa Rica
Ethiopia
Sumatra
Kenya
Columbia
Complete linkage
Sulawesi
Costa Rica
Ethiopia
Sumatra
Kenya
Columbia
So what’s it good for?
This is a fast method of initial data exploration.
Try all of the options with both raw and scaled data.
The plots can be rapidly evaluated.
You can also use principal component data. This will be covered in
the next unit.
When you get ready to go on to other methods of clustering,
knowing the best methods for linkage will also be useful.
k-mean clustering
• An iterative method where samples are initially partitioned
into ‘k’ classes and a centroid calculated.
• Must use quantitative variables but can be raw, scaled or
PCA based.
• The positions of all samples are then calculated relative to
the centroids and then reassigned to new clusters (if
needed) and the process repeated.
• Classification criteria can include within-class variance,
pooled covariance matrix or total inertia matrix.
• The number of clusters and assignments can vary based on
the initial starting points so several iterations are
commonly used to find a constant solution.
k-mean clustering
Position initial
class centroids
Adjust centroids
Test class
memberships
Retest/repeat
Using XLStat Classification criteria that can be minimized.
- Trace.^ Minimize the within-class variance, giving the most homogeneous clusters. Data should be autoscaled if this is used.
- Determinant.^ Minimize the covariance matrix. More appropriate to use with unscaled data but gives less homogeneous clusters.
- Wilks’ lambda.^ Normalized version of the Determinate approach.
- Trace/median.^ Centroid ends up being based on median not the mean, like other approaches. Better when there is subclustering of data. Using XLStat - XLStat’s version of HCA (Agglomerative Hierarchical Clustering - AHC) will do a k-mean analysis but only the ‘trace’ method - The k-means option provides more clustering control and is faster because no HCA is conducted. - However,^ AHC has an option to allow the routine to automatically set the number of ‘clusters’ that appear to exist. Iris dataset (again). Iris dataset (again). Iris dataset (again). Iris dataset (again). 5 10 15 20 25 15 30 45 60 Petal length P e t a l w i d t h Raw data.
So what’s it good for?
Can be used as a way to subdivide a dataset into related clusters.
Clusters are objectively determined based on similarities in
multidimensional space.
While results can vary based on starting point, the effect can be
minimized by using multiple starting points and repetitions.
Results are easier to see than with HCA. k-mean and HCA
complement each other.
