DATA MODELING
CONCEPTUAL MODEL
The main aim of this model is to establish the
entities, their attributes, and their relationships.
In this Data modeling level, there is hardly any
detail available of the actual Database structure.
LOGICAL MODEL
(^) Logical data models add further information to the conceptual model elements. It defines the structure of the data elements and set the relationships between them. (^) The advantage of the Logical data model is to provide a foundation to form the base for the Physical model. However, the modeling structure remains generic. (^) At this Data Modeling level, no primary or secondary key is defined. At this Data modeling level, you need to verify and adjust the connector details that were set earlier for relationships.
