ECE 250ECE 250 Algorithms and Data StructuresAlgorithms and Data Structures
Douglas Wilhelm Harder, M.Math. LEL Department of Electrical and Computer Engineering University of Waterloo Waterloo, Ontario, Canada ece.uwaterloo.ca [email protected] © 2006-2013 by Douglas Wilhelm Harder. Some rights reserved. Douglas Wilhelm Harder, M.Math. LEL Department of Electrical and Computer Engineering University of Waterloo Waterloo, Ontario, Canada ece.uwaterloo.ca [email protected] © 2006-2013 by Douglas Wilhelm Harder. Some rights reserved.
Stacks Stacks
2 Outline
This topic discusses the concept of a stack:
- (^) Description of an Abstract Stack
- (^) List applications
- (^) Implementation
- (^) Example applications
- (^) Parsing: C++
- (^) Function calls
- (^) Reverse-Polish calculators
- (^) Robert’s Rules
- (^) Standard Template Library
4 Abstract Stack
Also called a last-in–first-out (LIFO) behaviour
- (^) Graphically, we may view these operations as follows:
There are two exceptions associated with abstract stacks:
- (^) It is an undefined operation to call either pop or top on an empty stack
5 Applications
Numerous applications:
- (^) Parsing code:
- (^) Tracking function calls
- (^) Dealing with undo/redo operations
- (^) Reverse-Polish calculators
- (^) Assembly language
The stack is a very simple data structure
- (^) Given any problem, if it is possible to use a stack, this significantly simplifies the solution
7 Linked-List Implementation
Operations at the front of a singly linked list are all Q(1)
The desired behaviour of an Abstract Stack may be reproduced by
performing all operations at the front
Front/ 1 st Back/ n th Find (^) Q(1) Q(1) Insert (^) Q(1) Q(1) Erase (^) Q(1) Q( n )
8 Stack-as-List Class
The stack class using a singly linked list has a single private
member variable:
template class Stack { private: Single_list list; public: bool empty() const; Type top() const; void push( Type const & ); Type pop(); };
10 Stack-as-List Class
The empty and push functions just call the appropriate functions of
the Single_list class
template bool Stack::empty() const { return list.empty(); } template void Stack::push( Type const &obj ) { list.push_front( obj ); }
11 Stack-as-List Class
The top and pop functions, however, must check the boundary case:
template Type Stack::top() const { if ( empty() ) { throw underflow(); } return list.front(); } template Type Stack::pop() { if ( empty() ) { throw underflow(); } return list.pop_front(); }
13 Destructor
We need to store an array:
- (^) In C++, this is done by storing the address of the first entry *Type array;
We need additional information, including:
- (^) The number of objects currently in the stack int stack_size;
- (^) The capacity of the array int array_capacity;
14 Stack-as-Array Class
We need to store an array:
- (^) In C++, this is done by storing the address of the first entry template class Stack { private: int stack_size; int array_capacity; Type *array; public: Stack( int = 10 ); ~Stack(); bool empty() const; Type top() const; void push( Type const & ); Type pop(); };
16 Constructor
Warning: in C++, the variables are initialized in the order in which
they are defined:
template class Stack { private: int stack_size; int array_capacity; Type *array; public: Stack( int = 10 ); ~Stack(); bool empty() const; Type top() const; void push( Type const & ); Type pop(); }; template Stack::Stack( int n ): stack_size( 0 ), array_capacity( std::max( 1, n ) ), array( new Type[array_capacity] ) { // Empty constructor }
17 Destructor
The call to new in the constructor requested memory from the
operating system
- (^) The destructor must return that memory to the operating system: template Stack::~Stack() { delete [] array; }
19 Top
If there are n objects in the stack, the last is located at index n – 1
template Type Stack::top() const { if ( empty() ) { throw underflow(); } return array[stack_size - 1]; }
20 Pop
Removing an object simply involves reducing the size
- (^) It is invalid to assign the last entry to “0”
- (^) By decreasing the size, the previous top of the stack is now at the location stack_size template Type Stack::pop() { if ( empty() ) { throw underflow(); } --stack_size; return array[stack_size]; }
