‘Dynamic’ kernel patching

How you could add your own system-calls to Linux without editing and recompiling the kernel

System calls

• System Calls are the basic OS mechanism for providing privileged kernel services to application programs (e.g., fork(), clone(), execve(), read(), write(), signal(), getpid(), waitpid(), gettimeofday(), setitimer(), etc.)
• Linux implements over 300 system calls
• To understand how system calls work, we can try creating one of our own design

Alternative to edit/recompile

• Linux modules offer an alternative method for modifying the OS kernel’s functionality
• It’s safer -- and vastly more convenient – since error-recovery only needs a reboot, and minimal system knowledge suffices
• The main hurdle to be overcome concerns the issue of ‘linking’ module code to some non-exported Linux kernel data-structures

Invoking kernel services

application program

user-mode (restricted privileges) (^) (unrestricted privileges)kernel-mode

standard runtime libraries

call ret

Linux kernel

int 0x iret

installable module

call ret

Assembly language (.data)

.section .data

sys_call_table:

.long sys_restart_syscall .long sys_exit .long sys_fork .long sys_read .long sys_write // …etc (from ‘arch/i386/kernel/entry.S’)

The ‘jump-table’ idea

sys_restart_syscall sys_exit sys_fork sys_read sys_write sys_open sys_close

…etc…

sys_call_table 0 .section .text

1 2 3 4 5 6 7

Changing the jump-table

• To install our own system-call function, we just need to change an entry in the Linux ‘sys_call_table[]’ array, so it points to our own module function, but save the former entry somewhere (so we can restore it if we remove our module from the kernel)
• But we first need to find ‘sys_call_table[]’ -- and there are two easy ways to do that

Finding the jump-table

• Older versions of Linux (prior to 2.4.18) used to ‘export’ the ‘sys_call_table[]’ as a global symbol, but current versions keep this table’s address private (for security)
• But often during kernel-installation there is a ‘System.map’ file that gets put into the ‘/boot’ directory and – assuming it matches your compiled kernel – it holds the kernel address for the ‘sys_call_table[]’ array

The ‘vmlinux’ file

• Your compiled kernel (uncompressed) is left in the ‘/usr/src/linux’ directory
• It is an ELF-format (executable) file
• It contains .text and .data sections
• You can examine your ‘vmlinux’ kernel with the ‘objdump’ system-utility
• You can pipe the output through the ‘grep’ utility to locate the ‘sys_call_table’ symbol

Section-Header Table (optional)

Executable versus Linkable

ELF Header

Section 2 Data Section 3 Data … Section n Data

Segment 1 Data Segment 2 Data Segment 3 Data … Segment n Data

Linkable File Executable File

Section-Header Table

Program-Header Table (optional)

Program-Header Table

ELF Header

Section 1 Data

Exporting ‘sys_call_table’

• Once you know the address of your kernel’s ‘sys_call_table[]’, you can write a module to export that address to other modules, e.g.:

// declare global variable unsigned long *sys_call_table; EXPORT_SYMBOL(sys_call_table); int init_module( void) { sys_call_table = (unsigned long *)0xC0251500; return 0; }

Avoid hard-coded constant

• You probably don’t want to ‘hard code’ the sys_call_table’s value in your module – if you ever recompile your kernel, or use a differently configured kernel, you’d have to remember to edit your module and then recompile it – or risk a corrupted system!
• There’s a way to suply the required value as a module-parameter during ‘insmod’

simple_strtoul()

• There is a kernel function you can use, in your ‘init_module()’ function, that will convert a string of hexadecimal digits into an ‘unsigned long’’: int init_module( void ) { unsigned long myval; myval = simple_strtoul( svctable, NULL, 16 ); sys_call_table = (unsigned long *)myval; return 0; }

Shell scripts

• It’s inconvenient – and risks typing errors – if you must manually search ‘vmlinux’ and then type in the sys_call_table[]’s address every time you want to install your module
• Fortunately this sequence of steps can be readily automated – by using a shell-script
• We have created an example: ‘myscript’
