Enterprise IPv

Deployment

Shannon McFarland

CCIE# 5245, VCP

Corporate Consulting Engineer

Office of the CTO

Reference Materials  Deploying IPv6 in Campus Networks: http://www.cisco.com/en/US/docs/solutions/Enterprise/ Campus/CampIPv6.html  Deploying IPv6 in Branch Networks: http://www.cisco.com/en/US/solutions/ns340/ns414/ ns742/ns816/landing_br_ipv6.html  CCO IPv6 Main Page: http://www.cisco.com/go/ipv  Cisco Network Designs: http://www.cisco.com/go/designzone

Agenda  The Need for IPv  Planning and Deployment Summary  Address Considerations  General Concepts  Infrastructure Deployment Campus/Data Center WAN/Branch Remote Access  Provider Considerations

• The Need For IPv

IPv6 Provides Benefits Across the Board Manufacturing Government (Federal/Public Sector) Agriculture/ Transportation Wildlife Health Care Higher Education/Research (^) Consumer

• Set-top boxes
• Internet gaming
• Appliances
• Voice/video
• Security monitoring
• Building sensors
• Media services
• Collaboration
• Mobility
• Embedded devices
• Industrial Ethernet
• IP-enabled components
• DoD
• WIN-T
• FCS
• JTRS
• GIG-BE
• Telematics
• Traffic control
• Hotspots
• Transit services
• Animal tags
• Imagery
• Botanical
• Weather
• Home care
• Wireless asset tracking
• Imaging
• Mobility

Dramatic Increase in Enterprise Activity Why?  Enterprise that is or will be expanding into emerging markets  Enterprise that partners with other companies who may use IPv6 (larger enterprise, located in emerging markets, government, service providers)  Adoption of Windows 7, Windows 2008, DirectAccess  Frequent M&A activity  Energy – High density IP-enabled endpoints (SmartGrid)

Enterprise Adoption Spectrum Preliminary Research Pilot/Early Deployment Production/ Looking for parity and beyond

• Is it real?
• Do I need to deploy everywhere?
• Equipment status?
• SP support?
• Addressing
• What does it cost?
  • Mostly or completely past the “why?” phase
  • Assessment (e2e)
  • Weeding out vendors (features and $)
  • Focus on training and filling gaps
    • Still fighting vendors
    • Content and wide-scale app deployment
    • Review operational cost of 2 stacks
    • Competitive/Strategic advantages of new environment

IPv6 Integration Outline

• Establish the network

starting point

• Importance of a network

assessment and available tools

• Defining early IPv6 security

guidelines and requirements

• Additional IPv6 “pre-

deployment” tasks needing

consideration

Pre-Deployment Phases Deployment Phases

• Transport considerations

for integration

• Campus IPv6 integration

options

• WAN IPv6 integration options
• Advanced IPv

services options

Address Considerations

Hierarchical Addressing and Aggregation  Default is /48 – can be larger – “End-user Additional Assignment” https://www.arin.net/resources/request/ipv6_add_assign.html  Provider independent – See Number Resource Policy Manual (NRPM) - https://www.arin.net/policy/nrpm.html

ISP

2001:DB8::/

Site 2

IPv6 Internet

2001:DB8:0002::/

2001:DB8:0001::/

Site 1

Only

Announces

the /32 Prefix

2001:DB8:0001:0001::/

2001:DB8:0001:0002::/

2001:DB8:0002:0001::/

2001:DB8:0002:0002::/

ULA, ULA + Global or Global  What type of addressing should I deploy internal to my network? It depends: ULA-only—Today, no IPv6 NAT is useable in production so using ULA-only will not work externally to your network ULA + Global allows for the best of both worlds but at a price— much more address management with DHCP, DNS, routing and security—SAS does not always work as it should Global-only—Recommended approach but the old-school security folks that believe topology hiding is essential in security will bark at this option  Let’s explore these options…

Unique-Local Addressing (RFC4193)

 Used for internal communications, inter-site VPNs

Not routable on the internet—basically RFC1918 for IPv6 only better—less likelihood of collisions

 Default prefix is /

/48 limits use in large organizations that will need more space Semi-random generator prohibits generating sequentially ‘useable’ prefixes—no easy way to have aggregation when using multiple /48s Why not hack the generator to produce something larger than a /48 or even sequential /48s? Is it ‘legal’ to use something other than a /48? Perhaps the entire space? Forget legal, is it practical? Probably, but with dangers—remember the idea for ULA; internal addressing with a slim likelihood of address collisions with M&A. By consuming a larger space or the entire ULA space you will significantly increase the chances of pain in the future with M&A

 Routing/security control

You must always implement filters/ACLs to block any packets going in or out of your network (at the Internet perimeter) that contain a SA/DA that is in the ULA range— today this is the only way the ULA scope can be enforced

 Generate your own ULA: http://www.sixxs.net/tools/grh/ula/

Generated ULA= fd9c:58ed:7d73::/

• MAC address=00:0D:9D:93:A0:C3 (Hewlett Packard)
• EUI64 address=020D9Dfffe93A0C
• NTP date=cc5ff71943807789 cc5ff71976b28d

Corporate

Backbone

Branch 2

Branch 1

Corp HQ

ULA + Global

 Both ULA and Global are used internally except for internal-only hosts

 Source Address Selection (SAS) is used to determine which address to use when

communicating with other nodes internally or externally

 In theory, ULA talks to ULA and Global talks to Global—SAS ‘should’ work this out

 ULA-only and Global-only hosts can talk to one another internal to the network

 Define a filter/policy that ensures your ULA prefix does not ‘leak’ out onto the

Internet and ensure that no traffic can come in or out that has a ULA prefix in the

SA/DA fields

 Management overhead for DHCP, DNS, routing, security, etc…

ULA Space FD9C:58ED:7D73::/ Global – 2001:DB8:CAFE::/

FD9C:58ED:7D73: 2800 ::/

2001:DB8:CAFE: 2800 ::/

Internet

FD9C:58ED:7D73: 3000 ::/

2001:DB8:CAFE: 3000 ::/

FD9C:58ED:7D73::2::/

2001:DB8:CAFE: 2 ::/

Global – 2001:DB8:CAFE::/

Not Recommended

Considerations—ULA + Global

 Use DHCPv6 for ULA and Global—apply different policies for both (lifetimes, options,

etc..)

 Check routability for both—can you reach an AD/DNS server regardless of which address

you have?

 Any policy using IPv6 addresses must be configured for the appropriate range (QoS,

ACL, load-balancers, PBR, etc.)

 If using SLAAC for both—Microsoft Windows allows you to enable/disable privacy

extensions globally—this means you are either using them for both or not at all!!!

 One option is to use SLAAC for the Global range and enable privacy extensions and then

use DHCPv6 for ULA with another IID value (EUI-64, reserved/admin defined, etc.)

 Unlike Global and link-local scopes ULA is not automatically controlled at the appropriate

boundary—you must prevent ULA prefix from going out or in at your perimeter

 SAS behavior is OS dependent and there have been issues with it working reliably

Temporary Preferred 6d23h59m55s 23h59m55s 2001:db8:cafe:2:cd22:7629:f726:6a6b Dhcp Preferred 13d1h33m55s 6d1h33m55s fd9c:58ed:7d73:1002:8828:723c:275e:846d Other Preferred infinite infinite fe80::8828:723c:275e:846d%
