Extreme Computing: Parallelism

8/12/

Parallelism

Part 1

Extreme Computing: Parallelism

8/12/

Parallel

• Webster: side by side• Web definitions:
  • Two lines that are equidistant apart at all points– Simultaneous performance of multiple operations– Simultaneous and essentially independent processing in

different central processing units

• Our definitions:
  • “

Executed in parallel

”: executed at exactly the same time

• “

Parallel hardware

:” multiple, usually identical,

hardware, each capable of independent computation

• “

Parallel program

:” Program which divides computation

into steps that might in fact be executed “in parallel” on“parallel hardware”

Extreme Computing: Parallelism

8/12/

Concurrency

• Webster
  • to occur at the same time– to act together
    • Concurrency (web definitions)
      • Execution of two processes or operations simultaneously– Doing several things at once; includes time slicing of

processes as well as parallelism

• More than one process competing for processor time at the

same time, and potentially interacting with each other

• Other
  • “Action occurs

simultaneously

everywhere at same time”

(Lester, The Art of Parallel Programming, 2006, p. 29)

• Our Definition: overlap of operations as seen during

program execution

Extreme Computing: Parallelism

8/12/

Concurrency

• Web definitions
  • Execution of two processes or operations simultaneously– Doing several things at once; includes time slicing of

processes as well as parallelism

• More than one process competing for processor time at the

same time, and potentially interacting with each other

• Our definition: How many different actions can be

in state of computation at the same time

• Related:

degree of concurrency

= # of distinct

actions that are in an active state of execution atsame time

Extreme Computing: Parallelism

8/12/

Scalability

• Merriam-Webster’s Online: capable of being

easily upgraded or upgraded on demand

• The ease with which a system or component can

be modified to fit the problem area.

• Wikipedia:
  • desirable property of a system, a network, or a process,

which indicates its ability to either handle growing amountsof work in a graceful manner, or to be readily enlarged

• property of natural and economic systems … a property

scalable when it is subject to extremes

Extreme Computing: Parallelism

8/12/

Scalability

(Still from Wikipedia)

• A system whose performance improves after

adding hardware, proportionally to the capacityadded, is said to be a

scalable system

• An algorithm, design, networking protocol,

program, or other system is said to scale if– it is suitably efficient and practical when applied to large

situations (e.g. a large input data set or large number ofparticipating nodes in the case of a distributed system).

• If the design fails when the quantity increases

then it does not scale.

Extreme Computing: Parallelism

8/12/

To Scale

• From Wikipedia:
  • To scale up/vertically: add resources to a single node

in a system, typically involving the addition of CPUsor memory to a single computer

• To scale out/horizontally: to add more nodes to a

system, such as adding a new computer to adistributed software application

• Scaling has been discussed in terms of
  • Application performance– Hardware resources– Software

Extreme Computing: Parallelism

8/12/

Work and Performance Metrics

Work

: total number of basic operations

that need to be executed in a program

Performance metric

: measure of work

performed per unit time–

Peak performance metric

: absolute maximum

work per unit time that can be done by a processorfor any algorithm

• Processor specific but not algorithm specific

Sustained performance metric

: work per second

observed when running a specific algorithm

• algorithm and processor specific

Extreme Computing: Parallelism

8/12/

Precise Definitions

• T

A,X

(N,P) = time to solution

• for some algorithm A– when executed on a processor system with

architecture X

• where the size of the problem is N– and the number of processors available is P
  • We term A,X as “the system”
    • And drop subscripts from now on

Extreme Computing: Parallelism

8/12/

Application Scaling Definitions

• Define: T(N,P) = solution time for problem of size

N using P processors

Strong Scaling

: T(N,P) ~ T(N,1)/P

• Given fixed sized problem– Time decreases as P increases–^

Perfect strong scaling

if time decrease = 1/P

• Perfect linear speedup• Problem piece solved per processor also drops as 1/P

Weak Scaling

: T(1,1) ~ T(P,P)

• For a fixed solution time– Solvable problem size increases with processor count–^

Perfect weak scaling

if problem size proportional to P

• Problem piece solved per processor is constant

Extreme Computing: Parallelism

8/12/

Time to Solution Surface:

Single Processor Curve (1,1,1)

T(N,P): Time to Solution

P: # of Processors

N: Problem Size T(N,1)

Sequential time complexity curve

Note: assume log axes,with time normalizedso origin is T(1,1) =

Extreme Computing: Parallelism

8/12/

Perfect Strong Scaling:

T(N,P) = T(N,1)/P

Curve in NxP plane is

reflection of curve

in NxT plane

Lines are 1/P

(1,1,1)

T(N,P): Time to Solution

P: # of Processors

N: Problem Size T(N,1)

When P = T(N,1) T(1,P) = T(P,1)

then

T(N,P) = T(N,1)/P= T(N,1)/T(N,1)

= 1

Enough processorsare used to keep

problem solution time = 1

Less than perfect strong scaling is

in front of

surface

Extreme Computing: Parallelism

8/12/

Weak Scaling

Lines of ConstantExecution Time

(1,1,1)

T(N,P): Time to Solution

P: # of Processors

N: Problem Size T(N,1)

T(X,X)=

Lines of ConstantExecution Time

(1,1,1)

T(N,P): Time to Solution

P: # of Processors

N: Problem Size T(N,1)

T(X,X)=

Extreme Computing: Parallelism

8/12/

Some Weak Scaling Lemmas

If work delivered by a processor to a solution for a

particular system is independent of N and P:

then system exhibits perfect weak scaling if

T(N,1) = N*T(1,1)

i.e. the sequential time complexity is linearin problem size

then if system exhibits perfect weak scalingthen it also exhibits perfect strong scaling

then the scaling surface is represented byT(N,P) = N*T(1,1)
