DATA
COMMUNICATION
Lecture-
Recap of Lecture 26
Guided Media
Optical Fiber Cable
Unguided Media
Radio Frequency Allocation
Propagation of Radio Waves
Frequency Ranges
The type of propagation used in radio
transmission depends upon the frequency of the signal
Very Low Frequency (VLF)
Middle Frequency (MF)
High Frequency (HF)
Ultra High Frequency (UHF)
Ultra High Frequency (UHF)
Extremely High Frequency
(EHF)
Terrestrial Microwave
Microwaves do not follow the curvature of earth
Line-of-sight transmission
Height allows the signal to travel farther
Terrestrial Microwave
Antennas
Satellite Communication
Line-of-sight microwave
communication using satellite
Satellite acts as a very tall antenna
and a repeater
Geosynchronous Satellites
Satellite Frequency Bands
Each satellite sends and receives over two bands
- Uplink: From the earth to the satellite
- Downlink: From the satellite to the earth
