Heuristic Function
In a board game, before we make a move when we have various
options How do we know which is the best move?
Information
If I have an algorithm that guides to win the game (truth)
Adaptation
Through learning by trial and error (algedonics or backpropagation)
knowledge
Knowledge
By defining a heuristic function F that gives a sense of evaluation and
comparison between moves, allowing us to use a contingent rule
IF in state i THEN move to stake k /// rule selection
1
Heuristic Function
In a board game, to arrive at that knowledge
- I have to perceive some patterns from the
boards, this is, aspects that show a
comparative value among them
- For example, we believe that the green
option is the best, although this is not an
absolute truth, nevertheless is knowledge
2
How can we define the knowledge behind this opinion?
After some consideration we may come up with something like this:
BoardEvaluation = MyOpenOptions - TheirOpenOptions
Using this function we obtain for the three possible panels that:
BoardEvaluation(Yellow Board) = 8 - 5 = 3
BoardEvaluation( Green Board) = 8 - 4 = 4
BoardEvaluation( Red Board) = 8 - 6 = 2 BoardEvaluation(Black Board) = 8 - 8 = 0
A final note on the heuristic function. As we play further down the game,
the function may be have to be changed according to where in the game
we are.
This is to say at the beginning the strategy of the game may be to achieve a
given position.
In the middle of the game maybe the strategy lies in capturing pieces.
Towards the end of the game it maybe that doing just one move is important.
Should this be the case, then we might have different X terms with
different factors a,p in the formula to accommodate the strategy at hand,
thus having different formulas according a the depth of the game
4
One or many Heuristic Functions
E(t) =∑aXp^ E(t+δt) =∑aXp^ E(t+2δt) =∑aXp
Jumping Ahead
However after I play my move, my opponents will
play theirs and if they are rational players, they will
use a criteria to select the move in order to get a
benefit and reducing the value of the board just
chosen by me.
Therefore I should evaluate not my next move, but a
combination of my move and theirs to determine my
best choice.
In their case I should consider not a maximization of
the formula E =∑aXp^ but rather, the minimization
since by reducing the value of the function from their
perspective they chooses a better board position.
Lets take a look
5
Evaluation
Evaluation
Evaluation Evaluation
Evaluation
MInimization
Evaluation
Evaluation Evaluation
Evaluation Evaluation
Evaluation
Evaluation
Evaluation
Evaluation
Evaluation Evaluation
Evaluation
Evaluation Evaluation
Evaluation
Minimization
Project 2 and Exam 1
• Note the requirements for project 2
- Your E =∑aXp^ must beat the STM
- The E =∑aXp^ must train the the STM, letting play it play first. After playing no more than 500 games. Most likely a set of formulas with various degrees will be necessary
- For all three games: the evaluation should be done using recursive alpha beta (2 ply ) and should do well when playing against a human
• Note the date of the next project:
Monday March 7
7
MiniMax
The algorithm to evaluate the next move will work bottom up as follows:
1. Branch down two levels (known as one ply)
2. Evaluate all the boards
3. Minimize by selecting the board with minimum value
4. Move up one level
5. Maximize by selecting the board with the best value
6. This is the best move
with a given value from the function
It is called MINImize MAXimize (MINIMAX)
8
Selected move
MiniMax
Now in reality one should try branch the tree further down than one ply, the closer
we get to the end of the game the closer to the truth our knowledge will be.
As a matter of fact, many computer games that you play have generally three
levels: novice, medium, expert. Well the expertise mostly likely reflect how far they
branch down, most of the time we deal with 1,2 and 3 ply’s. The further you go
down, the longer it will take to decide.
Nowadays faster machines are able to go as far as down as twelve ply’s. Imagine
just the number of boards to evaluate.
eval = > minimize - maximize - minimize - maximize - minimize -maximize
=> select
10
Applying minimax
11
Big trees
So what do you when you have a tree with many branches you do not
need
You prune it, don ’ t you?
Back in the sixties, A. Samuel did it, he called his algorithm
the α β pruning
The idea behind is that the values in the upper two nodes already selected
might preclude some nodes to be considered
13
α β pruning
14
X
X
X
Max
<=
Min
Eval
<=
does
not go
does not go
does not go
goes up
goes up and stops does^ (α^ >=3) not go
goes up
as β
goes up and stops!
goes up
as α
does not go does not go
<=
An example of Alpha-beta pruning
16
max
max
max
min
min
Source: www.cs.umbc.edu/~ypeng/F02671/lecture-notes/Ch05.pptt Docsity.com
Final tree
17
max
max
max
min
min
Source: www.cs.umbc.edu/~ypeng/F02671/lecture-notes/Ch05.pptt Docsity.com
Pseudo Code α β
public class Minimax with alpha beta pruning int[] BOARD = new int[3] // BOARD[1] is the board number // BOARD[2] is the evaluation of the board //BOARD[3] is the number of possible boards that open from this one int[] POSSIBLE = new int[3] ; int[] MinBOARD = new int[3]; int[] MaxBOARD = new int[3] ; int play, plyLimit, depthGrow ; // define desired board, play and depth
// Recursive MINIMAX public void init() { plyLimit = depth ; game = "playing"; while (Game = "playing") { BOARD = Maximize(BOARD,alpha, beta, 1); display(BOARD); game = EvaluateEnd(BOARD); if game=“playing” {BOARD = otherPlay (BOARD); game = EvaluateEnd(BOARD); } } ; };
19
Maximize method int[] Maximize(BOARD,alpha,beta,depthGrow) { alpha = -infinite; for ( j= 1; j <= BOARD[3] ; j=j+1 ) { MaxBOARD = NextBoard(j,BOARD); POSSIBLE = Minimize(MaxBOARD,alpha,beta,depthGrow); if ( beta > alpha ) alpha = beta; if alpha >= POSSIBLE[2] then BOARD = POSSIBLE }; return BOARD ; }
// Evaluate method float Evaluate(int[3] BOARD) { // determines the value of the function for the board }
// Evaluate End method String EvaluateEnd(int[3] BOARD) { // determines if the games has ended }
// Display Board void display(int[3] BOARD) { // display board over the interface }
// Next Board Method int NextBoard(int j, int[3] BOARD) { // determines the next sequential board }
// Minimize Method int[] Minimize(BOARD,alpha,beta,depthGrow) {depthGrow = depthGrow +1; pruning = "in process" ; beta = + infinite ; for ( j = 1; j <= BOARD[3] AND pruning = "in process" ; j=j+1 ) { MinBOARD = NextBoard(j, BOARD); if ( depthGrow = plyLimit ) POSSIBLE[2] = Evaluate(MinBOARD[1]) else POSSIBLE = Maximize(MinBOARD, alpha, beta, depthGrow); } if ( MinBOARD[2] <= beta ) { BOARD = POSSIBLE ; beta = MinBOARD[2] ; if (beta <= alpha) pruning = "done" ; } } Return BOARD }
Bigger trees?
If you have still a bigger tree you can always do a Crash Cut,
The idea behind this pruning is to cut a complete sub tree
before branching if you do not like a given type of move
For example, in chess, lets say you do not care to
exchange your queens, therefore that whole sub tree is
chopped off
20
