EE321 – Fall 2002
Homework 8
Due October 21, 2002
1. Problem 4.23.
2. Problem 4.26.
3. Problem 4.29.
4. Problem 4.38.
•When the problem asks “What happens if the transistor is replaced with another having
β= 100?”, it wants you to find the value of VCusing the value of RCyou found for
β= 50.
5. Problem 4.40.
•The answers to Part (b) of 4.40 are
–V1= 0.837 V
–V2= 1.54 V
–V3=−2.22 V
–V4= 2.86 V
–V5=−1.52 V
